Silicon carbide precision cut-off wheels

• for non-ferrous metals

Thickness

Arbor Size

Bond

95017765

100 mm

0.5 mm

12.7 mm

Resin

5 pcs

95017766

150 mm

0.8 mm

12.7 mm

Resin

5 pcs

92004998

150 mm

1 mm

12.7 mm

Resin

5 pcs

92004155

200 mm

1.5 mm

12.7 mm

Resin

5 pcs

* 1 reduction ring for each order

Reduction ring

Aluminum oxide precision cut-off wheels

Fine-grained
• for universal application of materials of higher hardness
• precise cuts and high surface quality
• optimal for delicate samples and sensitive materials

Thickness

Arbor Size

Bond

Grain

92002643

100 mm

0.25 mm

12.7 mm

Rubber

Fine grid

5 pcs

92002645

100 mm

0.4 mm

12.7 mm

Rubber

Fine grid

5 pcs

92002644

125 mm

0.45 mm

12.7 mm

Rubber

Fine grid

5 pcs

92002769

150 mm

0.45 mm

12.7 mm

Rubber

Fine grid

5 pcs

95014126

200 mm

0.45 mm

12.7 mm

Rubber

Fine grid

5 pcs

Coarse-grained
• for universal use with lower hardness materials
• ideal for rough geometries and mounted sample material
• fast and efficient cuts

Thickness

Arbor Size

Bond

Grain

92002646

125 mm

0.8 mm

12.7 mm

Rubber

Coarse grid

5 pcs

92002770

150 mm

0.6 mm

12.7 mm

Rubber

Coarse grid

5 pcs

92002647

200 mm

0.8 mm

12.7 mm

Rubber

Coarse grid

5 pcs

92004159

150 mm

1 mm

12.7 mm

Resin

Coarse grid

5 pcs

Diamond precision cut-off wheels
Bond: Bronze

• for universal application and carbides

Thickness

Arbor Size

Bond

Grain

92002397

75 mm

0.3 mm

12.7 mm

Bronze

D181

1 pc

92002401

100 mm

0.3 mm

12.7 mm

Bronze

D181

1 pc

92002405

125 mm

0.5 mm

12.7 mm

Bronze

D213

1 pc

92002409

150 mm

0.5 mm

12.7 mm

Bronze

D213

1 pc

95016591

175 mm

0.65 mm

12.7 mm

Bronze

D213

1 pc

95004814

200 mm

0.5 mm

12.7 mm

Bronze

D213

1 pc

• for glass, minerals, rock as well as brittle and hard ceramic materials

Thickness

Arbor Size

Bond

Grain

92002398

75 mm

0.3 mm

12.7 mm

Bronze

D181

1 pc

92002402

100 mm

0.3 mm

12.7 mm

Bronze

D181

1 pc

92002406

125 mm

0.5 mm

12.7 mm

Bronze

D213

1 pc

92002410

150 mm

0.5 mm

12.7 mm

Bronze

D213

1 pc

92006368

200 mm

0.6 mm

12.7 mm

Bronze

D213

1 pc

• for hard metals and hard ceramic materials

Thickness

Arbor Size

Bond

Grain

95010518

150 mm

0.5 mm

12.7 mm

Bronze

D213

1 pc

95008773

150 mm

0.5 mm

12.7 mm

Resin

D213

1 pc

95015121

200 mm

1.0 mm

12.7 mm

Bronze

D151

1 pc

• for assembled printed circuit boards and filigree component geometries

Thickness

Arbor Size

Bond

Grain

92002400

75 mm

0.3 mm

12.7 mm

Bronze

D91/107

1 pc

92002404

100 mm

0.3 mm

12.7 mm

Bronze

D91/107

1 pc

92002408

125 mm

0.5 mm

12.7 mm

Bronze

D91/107

1 pc

92002412

150 mm

0.5 mm

12.7 mm

Bronze

D91/107

1 pc

• for mounted samples, composites, CFRP, GFRP and plastics

Thickness

Arbor Size

Bond

Grain

95012928

200 mm

1.0 mm

12.7 mm

Galvanic

D64

1 pc

95007077

200 mm

1.2 mm

12.7 mm

Galvanic

D126

1 pc

CBN precision cut-off wheels
Bond: Bronze

• for composites and rigid materials

Thickness

Arbor Size

92002444

125 mm

0.5 mm

12.7 mm

1 pc

92002445

150 mm

0.65 mm

12.7 mm

1 pc

92002446

175 mm

0.9 mm

12.7 mm

1 pc

92006419

200 mm

0.5 mm

12.7 mm

1 pc

other diameters on request

Saw blade precision cut-off wheel

• for plastics, non-ferrous metals

Thickness

Arbor Size

95009083

150 mm

1.4 mm

12.7 mm

Silicon carbide cut-off wheels
Bond: Resin

Type NF-A, Purple
• for non-ferrous metals (30-300HV)

Thickness

Arbor Size

Bond

95012531

250 mm

1.5 mm

32 mm

Resin

10 pcs

95012538

300 mm

2.0 mm

32 mm

Resin

10 pcs

95012545

350 mm

2.5 mm

32 mm

Resin

10 pcs

95012552

400 mm

3.0 mm

32 mm

Resin

10 pcs

95012566

500 mm

4.0 mm

32 mm

Resin

5 pcs

95012573

600 mm

4.5 mm

32 mm

Resin

5 pcs

Type Ti-A, Pink
• for titanium and alloys, refractory metals (30-300 HV)

Thickness

Arbor Size

Bond

92002417

230 mm

1.5 mm

32 mm

Resin

10 pcs

95012530

250 mm

1.5 mm

32 mm

Resin

10 pcs

95012537

300 mm

2.0 mm

32 mm

Resin

10 pcs

92002427

350 mm

2.5 mm

32 mm

Resin

10 pcs

92002428

400 mm

3.0 mm

32 mm

Resin

10 pcs

95018054

500 mm

4.0 mm

32 mm

Resin

5 Pcs.

95018055

600 mm

4.5 mm

32 mm

Resin

5 Pcs.

for cut-off wheels with Ø 230 mm and 400 mm for titanium and titanium alloys, see type F aluminum oxide cut-off wheels

Aluminum oxide cut-off wheels
Bond: Resin

Type FS-A, Red
• for soft steel (30-300HV), non-ferrous metals, polymer (e.g., PMMA, PEEK, PTFE) due to hard bonding

Thickness

Arbor Size

Bond

95012529

250 mm

1.5 mm

32 mm

Resin

10 pcs

95012536

300 mm

2.0 mm

32 mm

Resin

10 pcs

95012543

350 mm

2.5 mm

32 mm

Resin

10 pcs

95012550

400 mm

3.0 mm

32 mm

Resin

10 pcs

95012564

500 mm

4.0 mm

32 mm

Resin

5 pcs

95012571

600 mm

4.5 mm

32 mm

Resin

5 pcs

Type I
• ideal for cutting structural steel (e.g., S235JR, S355J2, C45) and cast materials (e.g., ductile iron, gray cast iron, cast steel) (60-350 HV)

Thickness

Arbor Size

Bond

92006066

250 mm

1.6 mm

32 mm

Resin

10 pcs

92005863

300 mm

2 mm

32 mm

Resin

10 pcs

92005862

350 mm

2.5 mm

32 mm

Resin

10 pcs

92008504

400 mm

3 mm

32 mm

Resin

10 pcs

Type FS-B, Orange
• for medium soft steel (200-450HV) e.g. unalloyed structural steels and low-alloy steels

Thickness

Arbor Size

Bond

95012528

250 mm

1.5 mm

32 mm

Resin

10 pcs

95012535

300 mm

2.0 mm

32 mm

Resin

10 pcs

95012542

350 mm

2.5 mm

32 mm

Resin

10 pcs

95012549

400 mm

3.0 mm

32 mm

Resin

10 pcs

95012563

500 mm

4.0 mm

32 mm

Resin

5 pcs

95012570

600 mm

4.5 mm

32 mm

Resin

5 pcs

Type FS-C, Yellow
• for medium hard steel (300-550HV), case hardened, nitrided steels

Thickness

Arbor Size

Bond

95012527

250 mm

1.5 mm

32 mm

Resin

10 pcs

95012534

300 mm

2.2 mm

32 mm

Resin

10 pcs

95012541

350 mm

2.2 mm

32 mm

Resin

10 pcs

95012548

400 mm

3.0 mm

32 mm

Resin

10 pcs

95012562

500 mm

4.0 mm

32 mm

Resin

5 pcs

95012569

600 mm

4.5 mm

32 mm

Resin

5 pcs

Type D
• universally applicable for medium material hardness and case-hardened steels (350-600 HV), e.g., tempered steel 42CrMo4, CuSn8

Thickness

Arbor Size

Bond

92001555

250 mm

1.5 mm

32 mm

Resin

10 pcs

92001559

300 mm

2 mm

32 mm

Resin

10 pcs

92001670

350 mm

2 mm

32 mm

Resin

10 pcs

92001784

400 mm

3 mm

32 mm

Resin

10 pcs

Type FS-D, Green
• for hard steels (400-700HV), annealed, carburised steels

Thickness

Arbor Size

Bond

95012526

250 mm

1.5 mm

32 mm

Resin

10 pcs

95012533

300 mm

2.0 mm

32 mm

Resin

10 pcs

95012540

350 mm

2.5 mm

32 mm

Resin

10 pcs

95012547

400 mm

3.0 mm

32 mm

Resin

10 pcs

95012561

500 mm

4.0 mm

32 mm

Resin

5 pcs

95012568

600 mm

4.5 mm

32 mm

Resin

5 pcs

Type C
• universally applicable for materials of high and very high hardness (>600 HV), e.g., martensitic stainless steels, WC-Co, carbide

Thickness

Arbor Size

Bond

92001554

250 mm

1.5 mm

32 mm

Resin

10 pcs

92001558

300 mm

2 mm

32 mm

Resin

10 pcs

92001669

350 mm

2 mm

32 mm

Resin

10 pcs

92001783

400 mm

3 mm

32 mm

Resin

10 pcs

Type FS-E, Blue
• for very hard steels (>650 HV), e.g., CrV, manganese steel

Thickness

Arbor Size

Bond

95012525

250 mm

1.5 mm

32 mm

Resin

10 pcs

95012532

300 mm

2.0 mm

32 mm

Resin

10 pcs

95012539

350 mm

2.5 mm

32 mm

Resin

10 pcs

95012546

400 mm

3.0 mm

32 mm

Resin

10 pcs

95012560

500 mm

4.0 mm

32 mm

Resin

5 pcs

95012567

600 mm

4.5 mm

40 mm

Resin

5 pcs

Type A, Brown
• universal wheel, soft and hard metals, superalloys (50-500 HV)

Thickness

Arbor Size

Bond

92002413

230 mm

0.8 mm

32 mm

Rubber

10 pcs

92002599

250 mm

1.0 mm

32 mm

Rubber

10 pcs

92002441

300 mm

1.0 mm

32 mm

Rubber

10 pcs

92002436

350 mm

1.6 mm

32 mm

Rubber

10 pcs

92002439

400 mm

1.6 mm

32 mm

Rubber

10 pcs

92008537

500 mm

2.4 mm

32 mm

Rubber

5 pcs

92004007

600 mm

4.3 mm

40 mm

Rubber

5 pcs

Type B, Black
• for high-speed steels, heat-treated steels, non-corrosive steels (400-700 HV)

Thickness

Arbor Size

Bond

92002414

230 mm

1.6 mm

32 mm

Rubber

10 pcs

92002600

250 mm

1.6 mm

32 mm

Rubber

10 pcs

92002434

300 mm

1.6 mm

32 mm

Rubber

10 pcs

92002437

350 mm

2.4 mm

32 mm

Rubber

10 pcs

92002440

400 mm

2.4 mm

32 mm

Rubber

10 pcs

92008874

500 mm

3.0 mm

32 mm

Rubber

5 pcs

95018035

600 mm

4.3 mm

40 mm

Rubber

5 pcs

Fabric reinforced premium aluminum oxide cut-off wheels
Bond: Resin

Type FS-FR, fabric reinforced
• for medium soft to hard steels (250-600 HV)
• > 30% wear reduction
• ideal for manual cutting

Thickness

Arbor Size

Bond

95017540

250 mm

1.5 mm

32 mm

Resin

10 pcs

95017541

300 mm

2.0 mm

32 mm

Resin

10 pcs

95017542

350 mm

2.5 mm

32 mm

Resin

10 pcs

95017543

400 mm

3.0 mm

32 mm

Resin

10 pcs

Premium diamond cut-off wheels
Bond: Bronze

• for ceramic materials

Thickness

Arbor Size

Bond

Grain

92002452

250 mm

1.2 mm

32 mm

Bronze

D181

1 pc

92002453

300 mm

1.6 mm

32 mm

Bronze

D181

1 pc

95003433

350 mm

1.6 mm

32 mm

Bronze

D181

1 pc

92008751

400 mm

2.4 mm

32 mm

Bronze

D181/213

1 pc

• for composite materials (hard/soft combinations)

Thickness

Arbor Size

Bond

Grain

95002102

250 mm

1.3 mm

32 mm

Bronze

D126/151

1 pc

92004719

300 mm

1.3 mm

32 mm

Bronze

D126/151

1 pc

92008619

350 mm

1.3 mm

32 mm

Bronze

D126/151

1 pc

95006793

400 mm

1.3 mm

32 mm

Bronze

D126/151

1 pc

other diameters on request

Premium diamond cut-off wheels
Bond: Resin

• for hard metals, for materials with high hardness (>700 HV)

Thickness

Arbor Size

Bond

Grain

92002451

250 mm

1.2 mm

32 mm

Resin

D126/151

1 pc

92002454

300 mm

1.6 mm

32 mm

Resin

D126

1 pc

95003049

350 mm

1.6 mm

32 mm

Resin

D126

1 pc

95010131

400 mm

1.6 mm

32 mm

Resin

D126

1 pc

other diameters on request

Premium CBN cut-off wheels
Bond: Bronze

• for Nickel and Cobald based alloys

Thickness

Arbor Size

Bond

92002456

250 mm

1.6 mm

32 mm

Bronze

1 pc

92002457

300 mm

1.6 mm

32 mm

Bronze

1 pc

95005025

350 mm

1.6 mm

32 mm

Bronze

1 pc

92004473

400 mm

1.6 mm

32 mm

Bronze

1 pc

ATM-CoolCut, environment- and user-friendly

Mixing ratio 1:25 (4%) – 1:17 (6%) / refractometer: 2.0%/°Bx

• for steel, cast iron, light and non-ferrous metal, glass and ceramics, composites
• free of oil, boron, nitride and formaldehyde
• optimized anti-corrosion protection and cutting properties

95004145

ATM-CoolCut, concentrate

1 l

95004146

ATM-CoolCut, concentrate

5 l

95004147

ATM-CoolCut, concentrate

10 l

Anti corrosion coolant for polymers and composites

Mixing ratio: 1:66 (1.5%) - 1:33 (3%) / refractometer: 2.4%/°Bx

• optimized for polymers and composites
• free of nitride and oil
• also suitable for steels, non-ferrous metals, ceramics and glasses

95007864

Concentrate

1 l

Anti corrosion coolant, standard

Mixing ratio 1:35 / refractometer: 1.4%/°Bx

• for steel, cast iron, non-ferrous metal

95014280

Concentrate

1 l

95014281

Concentrate

5 l

95014282

Concentrate

10 l

Cooling agent additives

ATM-CoolAdd CU

95008731

ATM-CoolAdd CU, additive for Cu/non-ferrous metal processing. Use concentration in water-mixed coolant and anti-corrosion agent approx. 0.05 - 0.2%
• reduces heavy metal ions concentration, protects surfaces, promotes filterability
• supports machine functionality	1 l

Defoaming agent

95014584 Defoaming agent, additive for water-based coolants
Mixing concentration in aqueous coolant approx. 0.005 - 0.05%

95014583 Defoaming agent, additive for water-based coolants
Mixing concentration in aqueous coolant approx. 0.005 - 0.05%

ATM-PreClean

92006502 ATM-PreClean, cleaning concentrate/system cleaner for circulating cooling units and cutting machines

Accessories for maintenance and care of coolants

Maintenance and testing set

95007866

Maintenance and testing set for anti-corrosion coolant (case with handheld refractometer, plastic cup for extraction of sample, test strips, thermometer)

1 pc

Accessories for maintenance and testing set

92005616

pH test strips

100 pcs

92005613

Nitrate test strips

100 pcs

92005614

Nitrite test strips

100 pcs

95007865

Water hardness test strips

100 pcs

Accessories for maintenance and care of cut-off machines

Corrosion protection- and care spray

95016408

Corrosion protection- and care spray, fully synthetical, silicon-free corrosion protection oil, for metal surfaces (e.g. clamping vices)

400 ml

Anti-fog spray

95008900

Anti-fog spray (prevents steaming up the viewing window by splash water)

100 ml

Accessories for cut-off wheels

Dressing stone

92002460

Dressing stone for diamond cut-off wheels, CBN cut-off wheels and cup wheels

1 pc

Filter inserts for recirculation cooling system for floor-standing cut-off machines, 140 Ltr.

for Brillant 255 / Qcut 400 A (Brillant 265) / Brillant 270 / Qcut 500 A (Brillant 275) / Brillant 280

Dimensions

Mesh size

95017301

Filter cloth and fleece

490 x 290 x 190 mm

60 µm

5 pcs

95017302

Filter cloth and fleece

490 x 290 x 190 mm

100 µm

5 pcs

95017303

Filter cloth and fleece

490 x 290 x 190 mm

800 µm

5 pcs

for recirculation cooling system for benchtop cut-off machines, 45 Ltr.
(until year of construction 2012)

Dimensions

Mesh size

95017304

Filter cloth and fleece

290 x 150 x 190 mm

60 µm

(until year of construction 2012)

5 pcs

95017305

Filter cloth and fleece

290 x 150 x 190 mm

100 µm

(until year of construction 2012)

5 pcs

95017306

Filter cloth and fleece

290 x 150 x 190 mm

800 µm

(until year of construction 2012)

5 pcs

for recirculation cooling system for benchtop cut-off machines, 45 Ltr.
(from year of construction 2013)

Dimensions

Mesh size

95017307

Filter cloth and fleece

250 x 200 x 155 mm

60 µm

(as of year of construction 2013)

5 pcs

95017308

Filter cloth and fleece

250 x 200 x 155 mm

100 µm

(as of year of construction 2013)

5 pcs

95017309

Filter cloth

250 x 200 x 155 mm

800 µm

(as of year of construction 2013)

5 pcs

Filter Basket

hanging basket made of stainless steel for the collection of the chip abrasion
• can be hooked into 45 liter recirculating cooling unit

Dimensions (WxHxD)

Z5800008

Filter Basket

140 x 80 x 200 mm

1 pc

Filter fleece for belt filter systems

for belt filter system BFA 285

Length x Width

92008780

Filter fleece roll

100 m x 710 mm

1 pc

95017825

Filter fleece roll

100 m x 710 mm

1 pc

95017826

Filter fleece roll

100 m x 750 mm

1 pc

95017827

Filter fleece roll

100 m x 800 mm

1 pc

for belt filter system BFA 100/130

Length x Width

95001696

Filter fleece roll

100 m x 420 mm

1 pc

other sizes on request

for Qcut 600 A (Brillant 285)

Length x Width

95016231

Filter fleece mat

724 x 720 mm

5 pcs

for recirculation cooling system 15 Ltr.

Length x Width

95017314

Filter fleece mat

235 x 148 mm

5 pcs

Mounting Consumables

10 kg

Hot mounting accessories

92002660

Silicon paste, anti-stick agent

90 ml

92002661

Silicon spray, anti-stick agent

200 ml

92004441

Brass brush for cleaning of hot mounting press

1 pc

95017752

Flat brush, size 20, for cleaning the hot mounting press

1 pc

95017753

Pointed angled tweezers, 160 mm, for positioning small samples

1 pc

92002658

Funnel for hot mounting material

1 pc

92002715

Square bottle with screw-top for approx. 1 ltr. mounting material

1 pc

92002657

Angle adapter for angled polishing, 10°

100 pcs

92001716

Dosing spoon for hot and cold mounting material, 13 ml

10 pcs

Clip for aligning thin samples in mould

92002662

Steel

100 pcs

92002663

Plastic, transparent

100 pcs

92002707

Plastic, black

100 pcs

92002708

Plastic, red

100 pcs

92002709

Plastic, grey

100 pcs

Accessories for Hot Mounting presses

for Hot Mounting Press Qpress 40

95017793

Vacuum cleaner bags for Qpress 40 vacuum cleaner

10 Pcs.

95017797

HEPA fine dust filter for Qpress 40 vacuum cleaner

1 Pcs.

95016887

Descaling tablets

3 Pcs.

for Hot Mounting Press Qpress 50

95014506

Filter mat, 230 x 230 mm

1 Pcs.

95014507

Particle filter, 250 x 250 x 190 mm, seal on both sides

1 Pcs.

95016887

Descaling tablets

3 Pcs.

Cold mounting material

Cold mounting material KEM 15 PLUS

Basis: Methyl methacrylate (MMA)

• blue, opaque
• 2-component system: powder + liquid (1.5:1 [Vol.-%])

95012019

1 kg powder, 500 ml liquid,
40 mixing cups, 40 mixing sticks, 2 dosing spoons: 13 ml and 20 ml	1 Set

95011628

Powder

1 kg

95011629

Liquid

500 ml

Cold mounting material KEM 20

Basis: Methyl methacrylate (MMA)

• feasibility of transparent embeddings by means of pressure unit
• 2-component system: powder + liquid (2:1 [Vol.-%])

95013990

1 kg powder, 500 ml liquid,
40 mixing cups, 40 mixing sticks, 2 dosing spoons	1 Set

95013939

Powder

1 kg

95013940

Powder

5 kg

95013941

Powder

10 kg

95013942

Liquid

500 ml

95013943

Liquid

1 l

Cold mounting material KEM 30

Basis: Methyl methacrylate (MMA)

• green, semi-transparent
• 2-component system: powder + liquid (2:1 [Vol.-%])

95012021

1 kg powder, 500 ml liquid,
40 mixing cups, 40 mixing sticks, 2 dosing spoons: 13 ml, oval	1 pc

92004080

Powder

1 kg

92004082

Powder

5 kg

92004081

Liquid

500 ml

92004083

Liquid

1 l

92002540

Liquid

2.5 l

Cold mounting material KEM 35

Basis: Methyl methacrylate (MMA)

• light green, opaque
• 2-component system: powder + liquid (1.5:1 [Vol.-%])

95012022

1 kg powder, 500 ml liquid,
40 mixing cups, 40 mixing sticks, 2 dosing spoons: 13 ml and 20 ml	1 Set

92002473

Powder

1 kg

92002474

Powder

5 kg

92002512

Powder

10 kg

92002475

Liquid

500 ml

92002476

Liquid

1 l

92002477

Liquid

2.5 l

Cold mounting material Qprep SEM 5000

Basis: Modified MMA compound

• copper-brown, free of blowholes by using a pressure device
• 2-component system: powder + liquid (20 g : 13 g)

95004058

Powder

1 kg

95004059

Liquid

500 ml

Cold mounting material KEM 60, 1 l

Basis: THFMA

• red, MMA-free
• 2-component system: powder + liquid (2:0.9 [weight-%])

95014004

1 kg powder, 500 ml liquid,
40 mixing cups, 40 mixing sticks, 2 dosing spoons: 13 ml, oval	1 Set

95013184

Powder

1 kg

95013185

Powder

5 kg

95013187

Liquid

500 ml

Cold mounting material Qpox 90

Basis: Epoxy resin

• transparent, suitable for vacuum infiltration
• 2-components-system: resin + hardener (2:1 [weight-%])

95017315

500 ml resin, 250 ml hardener
40 mixing cups, 40 mixing sticks	1 Set

92002484

Resin

500 ml

92002485

Hardener

250 ml

Cold mounting material Qpox 92

Basis: Epoxy resin

• transparent, suitable for vacuum infiltration
• 2-components-system: resin + hardener (100:23.2 [weight-%])

95017316

1 l Resin, 250 ml Hardener
40 mixing cups, 40 mixing sticks	1 Set

95016854

Resin

1 l

95016855

Hardener

250 ml

Cold mounting material Qpox 93

Basis: Epoxy resin

• transparent, suitable for vacuum infiltration
•2-components-system: resin + hardener (100:26 [weight-%])

95017916 1 l resin, 250 ml hardener
40 mixing cups, 40 mixing sticks

95017810 Resin

95017809 Hardener

Cold mounting material Qpox 94

Basis: Epoxy resin

• transparent, suitable for vacuum infiltration
• 2-components-system: resin + hardener (2:1 [weight-%])

95017538 1 l resin, 500 ml hardener
40 mixing cups, 40 mixing sticks

95017496 Resin

95017497 Hardener

Cold mounting material Qpox 96 Rapid

Basis: Epoxy resin

• transparent, suitable for vacuum infiltration
• 2-components-system: resin + hardener for 40 mm = 100/50, for ≤ 30 mm 100/56 [weight-%]

95018001 1 l resin, 500 ml hardener
40 mixing cups, 40 mixing sticks

95017944 Resin

95017945 Hardener

Vacuum infiltration and pressure device

Infiltration unit

• for cold mounting, pouring and hardening using vacuum
• recommended for Qpox epoxy resins

M6500001

infiltration unit, 230 V/50 Hz, vacuum pressure 0.8 bar,
W 330 x H 270 x D 300 mm
(including desiccator with mechanic dosing and vacuum pump, rotating disc for 8 silicon mounting cups Ø 50 mm or 9 PTFE-mounting cups Ø 40 mm, 10 mixing cups)	1 pc

Infiltration unit 110 V/60 Hz on request

Pressure equipment

95016569

Pressure Equipment Qprep Pressure, dimensions: B, 340 x W340 x H255 mm

1 pc

UV mounting material

UV mounting material Qprep UV 50

Basis: Modified methacrylate

• transparent
• 1-component system

95016840

All-in-one liquid

1 l

UV mounting resin Qprep UV 55

• transparent
• 1-component system

95017495 All-in-one liquid

Cold mounting moulds for UV mounting

Qmould Clear mounting moulds

• suitable for light curing
• with exchangeable bottom

95017575

Ø 40 mm / H 25 mm

5 pcs

95017576

Ø 50 mm / H 25 mm

5 pcs

Polypropylene round, without chamfer

• suitable for light curing
• with exchangeable bottom

95017317

Ø 25 mm / H 27 mm

5 pcs

95017318

Ø 30 mm / H 27 mm

5 pcs

Mounting

UV mounting material

95017319

Ø 40 mm / H 27 mm (will be replaced by Qmould Clear 95017575)

5 pcs

Cold & UV mounting accessories

92001715

Mixing cups, disposable, 180 ml

100 pcs

92004360

Silicon mixing cup, reusable

1 pc

92001717

Mixing sticks (wood)

100 pcs

92002657

Angle adapter for angled polishing, 10°

100 pcs

92001716

Dosing spoon for hot and cold mounting material, 13 ml

10 pcs

92001779

Dosing spoon for cold mounting material, 20 ml

10 pcs

92001781

Dosing spoon for cold mounting material, 13 ml

10 pcs

Clip for aligning thin samples in mould

92002662

Steel

100 pcs

92002663

Plastic, transparent

100 pcs

92002707

Plastic, black

100 pcs

92002708

Plastic, red

100 pcs

92002709

Plastic, grey

100 pcs

Plastic mounting aid

92002623

Ø 30 mm, for 4 samples, sample thickness <1 mm, blue

100 pcs

92002625

Ø 30 mm, for 4 samples, sample thickness <2 mm, gray

100 pcs

92002624

Ø 30 mm, for 3 samples, sample thickness <3 mm, white

100 pcs

Transparent mounting aid

95016787

Ø 35 mm, for 4 samples, sample thickness <1 mm

10 pcs

95016788

Ø 35 mm, for 4 samples, sample thickness <1 mm

50 pcs

95016789

Ø 35 mm, for 4 samples, sample thickness <1 mm

100 pcs

95016790

Ø 35 mm, for 4 samples, sample thickness 1-2 mm

10 pcs

95016791

Ø 35 mm, for 4 samples, sample thickness 1-2 mm

50 pcs

95016792

Ø 35 mm, for 4 samples, sample thickness 1-2 mm

100 pcs

95016793

Ø 35 mm, for 3 samples, sample thickness 2-3 mm

10 pcs

95016794

Ø 35 mm, for 3 samples, sample thickness 2-3 mm

50 pcs

95016795

Ø 35 mm, for 3 samples, sample thickness 2-3 mm

100 pcs

95016796

Ø 35 mm, for 2 samples, sample thickness 3-4 mm

10 pcs

95016797

95017026

Ø 25 mm / H 23 mm

5 pcs

95017027

Ø 30 mm / H 25 mm

5 pcs

95017028

Ø 32 mm / H 25 mm

5 pcs

95017029

Ø 38 mm / H 25 mm

5 pcs

95017030

Ø 40 mm / H 30 mm

5 pcs

95017031

Ø 50 mm / H 30 mm

5 pcs

Silicon rubber square, beveled edge

• not suitable for light curing

92002509

55 x 30 mm / H 22 mm

1 pc

95017032

55 x 30 mm / H 22 mm

5 pcs

92002510

70 x 40 mm / H 22 mm

1 pc

95017033

70 x 40 mm / H 22 mm

5 pcs

Polypropylene round, without chamfer

• suitable for light curing
• with exchangeable bottom

95017317

Ø 25 mm / H 27 mm

5 pcs

95017318

Ø 30 mm / H 27 mm

5 pcs

95017319

Ø 40 mm / H 27 mm (will be replaced by Qmould Clear 95017575)

5 pcs

Polyethylene round

• not suitable for light curing
• with exchangeable bottom

95017037

Ø 25 mm / H 25 mm

5 pcs

95017038

Ø 30 mm / H 25 mm

5 pcs

PTFE round, beveled edge

• not suitable for light curing
• with exchangeable bottom

95017041 Ø 25 mm / H 23 mm, 3 pcs

95017042 Ø 30 mm / H 25 mm, 3 pcs

95017043 Ø 32 mm / H 25 mm, 3 pcs

95017044 Ø 38 mm / H 25 mm, 3 pcs

95017045 Ø 40 mm / H 30 mm, 3 pcs

95017046 Ø 50 mm / H 30 mm, 3 pcs

95017047 Ø 70 mm / H 30 mm, 3 pcs

Solution Boxes, Solution Boxes

Solution Boxes

Grinding Consumables

Planar grinding stones

Planar grinding stones for Qgrind XL

White corundum grinding stone
• for tool steel (hardened and not hardened), stainless steel, steel and cast iron

Grain Size	Outer Ø	Inner Ø	Abor Size Ø
FEPA standard

95016741

100

356 mm

126 mm

38 mm

1 pc

95017565

150

356 mm

126 mm

38 mm

1 pc

SIC grinding stone
• for sintered materials (low- and unalloyed), aluminum, chilled cast iron, copper

Grain Size	Outer Ø	Inner Ø	Abor Size Ø
FEPA standard

95016746

356 mm

126 mm

38 mm

1 pc

95016747

150

356 mm

126 mm

38 mm

1 pc

Multi point dressing diamond for dressing face grinding stones

95016897

Multi point dressing diamond

1 pc

Planar grinding stones for Saphir 375

White corundum grinding stone
• for tool steel (hardened and not hardened), stainless steel, steel and cast iron
• glued on metal carrier plate

Grain Size	Outer Ø	Inner Ø	Abor Size Ø
FEPA standard

95000180

100

350 mm

90 mm

40 mm

1 pc

95000210

150

350 mm

90 mm

40 mm

1 pc

95002034

180

350 mm

90 mm

40 mm

1 pc

SIC grinding stone
• for sintered materials (low- and unalloyed), aluminum, chilled cast iron, copper
• glued on metal carrier plate

Grain Size	Outer Ø	Inner Ø	Abor Size Ø
FEPA standard

95002223

350 mm

90 mm

40 mm

1 pc

Inner diameter 120 mm on request

Multi point dressing diamond for dressing face grinding stones

92008759

Multi point dressing diamond

1 pc

Diamond cup grinder

• for glass fiber reinforced plastics and printed circuit boards
• with galvanic bond

Thickness

Height

Arbor Size

Grain

95017782

150 mm

8 mm

21.7 mm

12.7 mm

D120

1 pc

95017784

150 mm

8 mm

21.7 mm

12.7 mm

D213

1 pc

• for glass, ceramics, rocks, hard metal
• with resin bond

Thickness

Height

Arbor Size

Grain

95017564

150 mm

8 mm

21.5 mm

12.7 mm

D252

1 pc

95015123

150 mm

8 mm

21.5 mm

12.7 mm

D151

1 pc

95017562

150 mm

8 mm

21.5 mm

12.7 mm

D126

1 pc

95015122

150 mm

8 mm

21.5 mm

12.7 mm

D64

1 pc

95017563

150 mm

8 mm

21.5 mm

12.7 mm

D126

1 pc

Magnetic foil, self-adhesive

Magnetic foil, normal adhesion
• to apply on working wheel

Thickness

92008528

200 mm

1 mm

1 pc

92005820

250 mm

1 mm

1 pc

92005822

300 mm

1 mm

1 pc

Magnetic foil, strong adhesion
• to apply on working wheel

Thickness

95016345

200 mm

1 mm

1 pc

95018002

230 mm

1 mm

1 pc

95016346

250 mm

1 mm

1 pc

95012161

300 mm

1 mm

1 pc

95014137

350 mm

1 mm

1 pc

Magnetic foil, strongest adhesion
• to apply on working wheel
• increased magnetic adhesion by higher material thickness

Thickness

95016298

200 mm

2 mm

1 pc

95018003

230 mm

2 mm

1 pc

95016300

250 mm

2 mm

1 pc

95016301

300 mm

2 mm

1 pc

95016302

350 mm

2 mm

1 pc

GALAXY diamond grinding discs
Bond: Resin

• incl. dressing stone No.95015076
• for medium to hard materials
• planar grinding: grey (P80-P100)
• Fixation system: Magnetic foil

Description

Fixation

95005505

GALAXY diamond grinding disc grey

200 mm

Adhesion carrier/Magnet carrier

1 pc

95004279

GALAXY diamond grinding disc grey

250 mm

Adhesion carrier/Magnet carrier

1 pc

95004280

GALAXY diamond grinding disc grey

300 mm

Adhesion carrier/Magnet carrier

1 pc

95013917

GALAXY diamond grinding disc grey

350 mm

Adhesion carrier/Magnet carrier

1 pc

• incl. dressing stone No.95015076
• for medium to hard materials
• planar grinding: red (P100-P120)
• Fixation system: Magnetic foil

Description

Fixation

95005521

GALAXY diamond grinding disc red

200 mm

Adhesion carrier/Magnet carrier

1 pc

95004310

GALAXY diamond grinding disc red

250 mm

Adhesion carrier/Magnet carrier

1 pc

95004314

GALAXY diamond grinding disc red

300 mm

Adhesion carrier/Magnet carrier

1 pc

95013918

GALAXY diamond grinding disc red

350 mm

Adhesion carrier/Magnet carrier

1 pc

• incl. dressing stone No.95015076
• for medium to hard materials
• fine grinding: green (P180-P320)
• Fixation system: Magnetic foil

Description

Fixation

95005522

GALAXY diamond grinding disc green

200 mm

Adhesion carrier/Magnet carrier

1 pc

95004311

GALAXY diamond grinding disc green

250 mm

Adhesion carrier/Magnet carrier

1 pc

95004315

GALAXY diamond grinding disc green

300 mm

Adhesion carrier/Magnet carrier

1 pc

95013919

GALAXY diamond grinding disc green

350 mm

Adhesion carrier/Magnet carrier

1 pc

• incl. dressing stone No.95015076
• for medium to hard materials
• fine grinding: green (P400-P600)
• Fixation system: Magnetic foil

Description

Fixation

95005523

GALAXY diamond grinding disc blue

200 mm

Adhesion carrier/Magnet carrier

1 pc

95004312

GALAXY diamond grinding disc blue

250 mm

Adhesion carrier/Magnet carrier

1 pc

95004316

GALAXY diamond grinding disc blue

300 mm

Adhesion carrier/Magnet carrier

1 pc

95013920

GALAXY diamond grinding disc blue

350 mm

Adhesion carrier/Magnet carrier

1 pc

• incl. dressing stone No.95015076
• for medium to hard materials
• fine grinding: yellow (P800-P1000)
• Fixation system: Magnetic foil

Description

Fixation

95005524

GALAXY diamond grinding disc yellow

200 mm

Adhesion carrier/Magnet carrier

1 pc

95004313

GALAXY diamond grinding disc yellow

250 mm

Adhesion carrier/Magnet carrier

1 pc

95004317

GALAXY diamond grinding disc yellow

300 mm

Adhesion carrier/Magnet carrier

1 pc

95013921

GALAXY diamond grinding disc yellow

350 mm

Adhesion carrier/Magnet carrier

1 pc

Dressing/cleaning stones

for dressing and cleaning of GALAXY diamond grinding discs

Description

95006603

SiC dressing/cleaning stone

1 pc

95015076

Corundum dressing/cleaning stone

1 pc

POLARIS M diamond grinding discs

for medium-hard materials
• incl. cleaning stone No. (95015077)
• Fixation system: Magnetic foil

250 mm Ø

Description

Grain

95015016

POLARIS M diamond grinding disc

60 µm

1 pc

95015017

POLARIS M diamond grinding disc

30 µm

1 pc

95015018

POLARIS M diamond grinding disc

15 µm

1 pc

95015019

POLARIS M diamond grinding disc

6 µm

1 pc

95015020

POLARIS M diamond grinding disc

3 µm

1 pc

300 mm Ø

Description

Grain

95015041

POLARIS M diamond grinding disc

60 µm

1 pc

95015042

POLARIS M diamond grinding disc

30 µm

1 pc

95015043

POLARIS M diamond grinding disc

15 µm

1 pc

95015044

POLARIS M diamond grinding disc

6 µm

1 pc

95015045

POLARIS M diamond grinding disc

3 µm

1 pc

• for cleaning of POLARIS diamond grinding discs

95015077

Corundum cleaning stone

1 pc

POLARIS H diamond grinding discs

for hard materials
• incl. cleaning stone No. (95015077)
• Fixation system: Magnetic foil

250 mm Ø

Description

Grain

95015010

POLARIS H diamond grinding disc

125 µm

1 pc

95015011

POLARIS H diamond grinding disc

60 µm

1 pc

95015012

POLARIS H diamond grinding disc

30 µm

1 pc

95015013

POLARIS H diamond grinding disc

15 µm

1 pc

95015014

POLARIS H diamond grinding disc

6 µm

1 pc

95015015

POLARIS H diamond grinding disc

3 µm

1 pc

300 mm Ø

Description

Grain

95015035

POLARIS H diamond grinding disc

125 µm

1 pc

95015036

POLARIS H diamond grinding disc

60 µm

1 pc

95015037

POLARIS H diamond grinding disc

30 µm

1 pc

95015038

POLARIS H diamond grinding disc

15 µm

1 pc

95015039

POLARIS H diamond grinding disc

6 µm

1 pc

95015040

POLARIS H diamond grinding disc

3 µm

1 pc

• for cleaning of POLARIS diamond grinding discs

95015077

Corundum cleaning stone

1 pc

QUASAR diamond grinding discs

for hard materials
• incl. dressing stone No. (95015076)
• Fixation system: Magnetic foil

250 mm Ø

Description

Grain

95015006

QUASAR diamond grinding disc

252 µm

1 pc

95015007

QUASAR diamond grinding disc

125 µm

1 pc

95015008

QUASAR diamond grinding disc

91 µm

1 pc

95015009

QUASAR diamond grinding disc

46 µm

1 pc

300 mm Ø

Description

Grain

95015031

QUASAR diamond grinding disc

252 µm

1 pc

95015032

QUASAR diamond grinding disc

125 µm

1 pc

95015033

QUASAR diamond grinding disc

91 µm

1 pc

95015034

QUASAR diamond grinding disc

46 µm

1 pc

• for cleaning of QUASAR and VEGA diamond grinding discs

95015076

Corundum dressing/cleaning stone

1 pc

VEGA diamond grinding discs

for hard materials, for planar and pre-grinding
• incl. cleaning stone (95015076)
• Fixation system: Magnetic foil

200 mm Ø

Description

Grain

95017836

VEGA diamond grinding disc

250 µm

1 pc

Grinding

Grinding discs

Diamond

200 mm

VEGA

250 µm

Magnetic foil

95015001

VEGA diamond grinding disc

125 µm

1 pc

95015002

VEGA diamond grinding disc

75 µm

1 pc

95015003

VEGA diamond grinding disc

54 µm

1 pc

95015004

VEGA diamond grinding disc

25 µm

1 pc

95015005

VEGA diamond grinding disc

10 µm

1 pc

250 mm Ø

Description

Grain

95017837

VEGA diamond grinding disc

250 µm

1 pc

Grinding

Grinding discs

Diamond

250 mm

VEGA

250 µm

Magnetic foil

95015026

VEGA diamond grinding disc

125 µm

1 pc

95015027

VEGA diamond grinding disc

75 µm

1 pc

95015028

VEGA diamond grinding disc

54 µm

1 pc

95015029

VEGA diamond grinding disc

25 µm

1 pc

95015030

VEGA diamond grinding disc

10 µm

1 pc

300 mm Ø

Description

Grain

95017838

VEGA diamond grinding disc

250 µm

1 pc

Grinding

Grinding discs

Diamond

300 mm

VEGA

250 µm

Magnetic foil

95015051

VEGA diamond grinding disc

125 µm

1 pc

95015052

VEGA diamond grinding disc

75 µm

1 pc

95015053

VEGA diamond grinding disc

54 µm

1 pc

95015054

VEGA diamond grinding disc

25 µm

1 pc

95015055

VEGA diamond grinding disc

10 µm

1 pc

350 mm Ø

Description

Grain

95017839

VEGA diamond grinding disc

250 µm

1 pc

Grinding

Grinding discs

Diamond

350 mm

VEGA

250 µm

Magnetic foil

95016235

VEGA diamond grinding disc

125 µm

1 pc

95016236

VEGA diamond grinding disc

75 µm

1 pc

95016237

VEGA diamond grinding disc

54 µm

1 pc

95016238

VEGA diamond grinding disc

25 µm

1 pc

95016239

VEGA diamond grinding disc

10 µm

1 pc

Contero S fine grinding/lapping discs

for soft to medium hard materials
• Fixation system: Magnetic foil

Description

95013194

Contero S fine grinding/lapping disc

250 mm

1 pc

95013196

Contero S fine grinding/lapping disc

300 mm

1 pc

Contero H fine grinding/lapping discs

for medium to hard materials
• Fixation system: Magnetic foil

Description

95017605

Contero H fine grinding/lapping disc

250 mm

1 pc

95017606

Contero H fine grinding/lapping disc

300 mm

1 pc

95013923

Contero H fine grinding/lapping disc

350 mm

1 pc

Cleaning brushes

• for cleaning of ginding and fine grinding discs

Description

95016623

Nylon brush

1 pc

92004441

Brass brush

1 pc

Adhesive carrier discs, double-sided

95003607

250 mm

1 pc

95003608

300 mm

1 pc

before initial use please remove protective foil on both sides

Silicon carbide grinding foils

• Fixation system: Adhesive carrier disc

250 mm Ø

Description

Grain FEPA-Standard

92008557

SiC grinding foil

P120

100 pcs

92008558

SiC grinding foil

P180

100 pcs

95000899

SiC grinding foil

P240

100 pcs

92006305

SiC grinding foil

P320

100 pcs

92006304

SiC grinding foil

P600

100 pcs

95000900

SiC grinding foil

P800

100 pcs

92008559

SiC grinding foil

P1200

100 pcs

92008639

SiC grinding foil

P2500

100 pcs

300 mm Ø

Description

Grain FEPA-Standard

92008561

SiC grinding foil

P120

100 pcs

92008658

SiC grinding foil

P180

100 pcs

95000902

SiC grinding foil

P240

100 pcs

92006303

SiC grinding foil

P320

100 pcs

92006302

SiC grinding foil

P600

100 pcs

95000903

SiC grinding foil

P800

100 pcs

92008562

SiC grinding foil

P1200

100 pcs

92008621

SiC grinding foil

P2500

100 pcs

Silicon carbide grinding paper
with foil backing

• Fixation system: Adhesive carrier disc

250 mm Ø

Description

Grain FEPA-Standard

95011928

SiC grinding paper with foil backing

P80

100 pcs

95011929

SiC grinding paper with foil backing

P120

100 pcs

95011930

SiC grinding paper with foil backing

P180

100 pcs

95011931

SiC grinding paper with foil backing

P240

100 pcs

95011932

SiC grinding paper with foil backing

P320

100 pcs

95011933

SiC grinding paper with foil backing

P400

100 pcs

95011934

SiC grinding paper with foil backing

P500

100 pcs

95011935

SiC grinding paper with foil backing

P600

100 pcs

95011936

SiC grinding paper with foil backing

P800

100 pcs

95011937

SiC grinding paper with foil backing

P1000

100 pcs

95011938

SiC grinding paper with foil backing

P1200

100 pcs

95011939

SiC grinding paper with foil backing

P2500

100 pcs

300 mm Ø

Description

Grain FEPA-Standard

95011943

SiC grinding paper with foil backing

P80

100 pcs

95011944

SiC grinding paper with foil backing

P120

100 pcs

95011945

SiC grinding paper with foil backing

P180

100 pcs

95011946

SiC grinding paper with foil backing

P240

100 pcs

95011947

SiC grinding paper with foil backing

P320

100 pcs

95011948

SiC grinding paper with foil backing

P400

100 pcs

95011949

SiC grinding paper with foil backing

P500

100 pcs

95011950

SiC grinding paper with foil backing

P600

100 pcs

95011951

SiC grinding paper with foil backing

P800

100 pcs

95011952

SiC grinding paper with foil backing

P1000

100 pcs

95011953

SiC grinding paper with foil backing

P1200

100 pcs

95011954

SiC grinding paper with foil backing

P2500

100 pcs

X-Tap

X-Tap (self-adhesive to stick on the working wheel)

GALAXY-X-Tap (for using with magnetic foil)

95017019

200 mm

1 pc

95018004

230 mm

1 pc

95017020

250 mm

1 pc

95017021

300 mm

1 pc

95017022

350 mm

1 pc

Silicon carbide grinding papers, self-adhesive

• Fixation system: X-Tap

200 mm Ø

Description

Grain FEPA-Standard

92002544

SiC grinding paper

P80

100 pcs

92002545

SiC grinding paper

P120

100 pcs

92002546

SiC grinding paper

P180

100 pcs

92002547

SiC grinding paper

P240

100 pcs

92002548

SiC grinding paper

P320

100 pcs

92002549

SiC grinding paper

P400

100 pcs

92004516

SiC grinding paper

P600

100 pcs

92002550

SiC grinding paper

P800

100 pcs

92002551

SiC grinding paper

P1000

100 pcs

92002638

SiC grinding paper

P1200

100 pcs

92002761

SiC grinding paper

2400**

100 pcs

95018057

SiC grinding paper

2400**

100 pcs

92004561

SiC grinding paper

P2500

100 pcs

92002762

SiC grinding paper

4000**

100 pcs

95018058

SiC grinding paper

4000**

100 pcs

*slurried (uniform orientation of the abrasive particles), for a finer grinding pattern

**static (electrostatically directed abrasive grains with homogeneous distribution), for a high cutting effect

250 mm Ø

Description

Grain FEPA-Standard

92001643

SiC grinding paper

P80

100 pcs

92001644

SiC grinding paper

P120

100 pcs

92001645

SiC grinding paper

P180

100 pcs

92004953

SiC grinding paper

P240

100 pcs

92001647

SiC grinding paper

P320

100 pcs

92001648

SiC grinding paper

P400

100 pcs

92001649

SiC grinding paper

P600

100 pcs

92001650

SiC grinding paper

P800

100 pcs

92001651

SiC grinding paper

P1000

100 pcs

92001652

SiC grinding paper

P1200

100 pcs

92002763

SiC grinding paper

2400**

100 pcs

95018059

SiC grinding paper

2400**

100 pcs

92004563

SiC grinding paper

P2500

100 pcs

92002764

SiC grinding paper

4000**

100 pcs

95018060

SiC grinding paper

4000**

100 pcs

*slurried (uniform orientation of the abrasive particles), for a finer grinding pattern

**static (electrostatically directed abrasive grains with homogeneous distribution), for a high cutting effect

300 mm Ø

Description

Grain FEPA-Standard

92001654

SiC grinding paper

P80

100 pcs

92001655

SiC grinding paper

P120

100 pcs

92001657

SiC grinding paper

P180

100 pcs

92001658

SiC grinding paper

P240

100 pcs

92001659

SiC grinding paper

P320

100 pcs

92001660

SiC grinding paper

P400

100 pcs

92001661

SiC grinding paper

P600

100 pcs

92001662

SiC grinding paper

P800

100 pcs

92001663

SiC grinding paper

P1000

100 pcs

92001664

SiC grinding paper

P1200

100 pcs

92002765

SiC grinding paper

2400**

100 pcs

95018061

SiC grinding paper

2400**

100 pcs

92004564

SiC grinding paper

P2500

100 pcs

92002766

SiC grinding paper

4000**

100 pcs

95018062

SiC grinding paper

4000**

100 pcs

*slurried (uniform orientation of the abrasive particles), for a finer grinding pattern

**static (electrostatically directed abrasive grains with homogeneous distribution), for a high cutting effect

350 mm Ø

Description

Grain FEPA-Standard

95017771

SiC grinding paper

P80

100 pcs

95017772

SiC grinding paper

P120

100 pcs

95017773

SiC grinding paper

P180

100 pcs

95017774

SiC grinding paper

P240

100 pcs

95017775

SiC grinding paper

P320

100 pcs

95017776

SiC grinding paper

P400

100 pcs

95017777

SiC grinding paper

P600

100 pcs

95017778

SiC grinding paper

P800

100 pcs

95017779

SiC grinding paper

P1000

100 pcs

95017780

SiC grinding paper

P1200

100 pcs

95017781

SiC grinding paper

P2500

100 pcs

Zirconia alumina grinding papers, self-adhesive

• Fixation system: X-Tap

250 mm Ø

Description

Grain FEPA-Standard

92002382

Zirconia alumina grinding paper

P60

25 pcs

92002383

Zirconia alumina grinding paper

P120

25 pcs

300 mm Ø

Description

Grain FEPA-Standard

92002386

Zirconia alumina grinding paper

P60

25 pcs

92002387

Zirconia alumina grinding paper

P120

25 pcs

GALAXY Quick-Tap

GALAXY Quick-Tap (for using with magnetic foil)

95017587

200 mm

1 pc

95017484

250 mm

1 pc

95017485

300 mm

1 pc

Silicon carbide grinding papers
without adhesive/foil backing

• Fixation system: Quick-Tap or clamping ring

200 mm Ø

Description

Grain FEPA-Standard

92001811

SiC grinding paper

P80

100 pcs

92001812

SiC grinding paper

P120

100 pcs

92001813

SiC grinding paper

P180

100 pcs

92001814

SiC grinding paper

P240

100 pcs

92001815

SiC grinding paper

P320

100 pcs

92001816

SiC grinding paper

P400

100 pcs

92001817

SiC grinding paper

P500

100 pcs

92001818

SiC grinding paper

P600

100 pcs

92001819

SiC grinding paper

P800

100 pcs

92001820

SiC grinding paper

P1000

100 pcs

92001821

SiC grinding paper

P1200

100 pcs

92002634

SiC grinding paper

2400**

100 pcs

95018063

SiC grinding paper

2400**

100 pcs

92004557

SiC grinding paper

P2500

100 pcs

92002640

SiC grinding paper

4000**

100 pcs

95018067

SiC grinding paper

4000**

100 pcs

*slurried (uniform orientation of the abrasive particles), for a finer grinding pattern

**static (electrostatically directed abrasive grains with homogeneous distribution), for a high cutting effect

230 mm Ø

Description

Grain FEPA-Standard

92001568

SiC grinding paper

P80

100 pcs

92001569

SiC grinding paper

P120

100 pcs

92001570

SiC grinding paper

P180

100 pcs

92001571

SiC grinding paper

P240

100 pcs

92001572

SiC grinding paper

P320

100 pcs

92001573

SiC grinding paper

P400

100 pcs

92001574

SiC grinding paper

P500

100 pcs

92001575

SiC grinding paper

P600

100 pcs

92001576

SiC grinding paper

P800

100 pcs

92001577

SiC grinding paper

P1000

100 pcs

92001578

SiC grinding paper

P1200

100 pcs

92002635

SiC grinding paper, plain backed

2400**

100 pcs

95018064

SiC grinding paper, plain backed

2400**

100 pcs

92004558

SiC grinding paper

P2500

100 pcs

92001579

SiC grinding paper

4000**

100 pcs

95018068

SiC grinding paper, plain backed

4000**

100 pcs

*slurried (uniform orientation of the abrasive particles), for a finer grinding pattern

**static (electrostatically directed abrasive grains with homogeneous distribution), for a high cutting effect

250 mm Ø

Description

Grain FEPA-Standard

92001581

SiC grinding paper

P80

100 pcs

92001582

SiC grinding paper

P120

100 pcs

92001583

SiC grinding paper

P180

100 pcs

92002369

SiC grinding paper

P240

100 pcs

92001585

SiC grinding paper

P320

100 pcs

92001586

SiC grinding paper

P400

100 pcs

92001587

SiC grinding paper

P500

100 pcs

92001588

SiC grinding paper

P600

100 pcs

92001589

SiC grinding paper

P800

100 pcs

92001590

SiC grinding paper

P1000

100 pcs

92001591

SiC grinding paper

P1200

100 pcs

92002636

SiC grinding paper

2400**

100 pcs

95018065

SiC grinding paper, plain backed

2400**

100 pcs

92004559

SiC grinding paper

P2500

100 pcs

92001592

SiC grinding paper

4000**

100 pcs

95018069

SiC grinding paper, plain backed

4000**

100 pcs

*slurried (uniform orientation of the abrasive particles), for a finer grinding pattern

**static (electrostatically directed abrasive grains with homogeneous distribution), for a high cutting effect

300 mm Ø

Description

Grain FEPA-Standard

92001593

SiC grinding paper

P60

100 pcs

92001594

SiC grinding paper

P80

100 pcs

92001595

SiC grinding paper

P120

100 pcs

92001596

SiC grinding paper

P180

100 pcs

92001597

SiC grinding paper

P240

100 pcs

92001598

SiC grinding paper

P320

100 pcs

92001599

SiC grinding paper

P400

100 pcs

92001600

SiC grinding paper

P500

100 pcs

92001601

SiC grinding paper

P600

100 pcs

92001602

SiC grinding paper

P800

100 pcs

92001603

SiC grinding paper

P1000

100 pcs

92001604

SiC grinding paper

P1200

100 pcs

92002637

SiC grinding paper

2400**

100 pcs

95018066

SiC grinding paper, plain backed

2400**

100 pcs

92004560

SiC grinding paper

P2500

100 pcs

92002154

SiC grinding paper

4000**

100 pcs

95018070

SiC grinding paper, plain backed

4000**

100 pcs

*slurried (uniform orientation of the abrasive particles), for a finer grinding pattern

**static (electrostatically directed abrasive grains with homogeneous distribution), for a high cutting effect

Grinding papers for mobile grinder and polisher Qpol 30

Corundum grinding papers with hook-and-loop fastener backing

Grain FEPA-Standard

92004285

30 mm

P60

100 pcs

92004286

30 mm

P180

100 pcs

92004288

30 mm

P240

100 pcs

92004287

30 mm

P320

100 pcs

Silicon grinding papers with adhesive backing

Grain FEPA-Standard

92004498

30 mm

P400

100 pcs

92004499

30 mm

P600

100 pcs

92004631

30 mm

P1000

100 pcs

Self-adhesive polishing cloths: view chapter polishing

Grinding belts for Qgrind 100

Aluminum oxide grinding belts, water resistant

Dimensions

Grain FEPA-Standard

92002528

100 x 920 mm

P80

5 pcs

92002529

100 x 920 mm

P120

5 pcs

92002530

100 x 920 mm

P180

5 pcs

92002531

100 x 920 mm

P240

5 pcs

92004505

100 x 920 mm

P320

5 pcs

Silcon carbide grinding belts, water-resistant

Dimensions

Grain FEPA-Standard

92002664

100 x 915 mm

P80

5 pcs

92002665

100 x 915 mm

P120

5 pcs

92002666

100 x 915 mm

P180

5 pcs

92002667

100 x 915 mm

P240

5 pcs

92004613

100 x 915 mm

P320

5 pcs

92002394

100 x 915 mm

P400

5 pcs

Polishing Consumables

Dia-COMPLETE Poly,
All-In-One diamond suspension

Combined product of diamond suspension and lubricant

Grain Size

95011833

0.25 µm

500 ml

95011839

0.25 µm

1 l

95011845

0.25 µm

2.5 l

95016023

0.25 µm

5 l

95011834

1 µm

500 ml

95011840

1 µm

1 l

95011846

1 µm

2.5 l

95015394

1 µm

5 l

95011835

3 µm

500 ml

95011841

3 µm

1 l

95011847

3 µm

2.5 l

95015395

3 µm

5 l

95011836

6 µm

500 ml

95011842

6 µm

1 l

95011848

6 µm

2.5 l

95015396

6 µm

5 l

95011837

9 µm

500 ml

95011843

9 µm

1 l

95011849

9 µm

2.5 l

95015397

9 µm

5 l

95011844

15 µm

1 l

Dia-COMPLETE Mono,
All-In-One diamond suspension

Combined product of diamond suspension and lubricant

Grain Size

95011815

1 µm

500 ml

95011820

1 µm

1 l

95011825

1 µm

2.5 l

95015404

1 µm

5 l

95011816

3 µm

500 ml

95011821

3 µm

1 l

95011826

3 µm

2.5 l

95015405

3 µm

5 l

95011817

6 µm

500 ml

95011822

6 µm

1 l

95011827

6 µm

2.5 l

95015406

6 µm

5 l

95011818

9 µm

500 ml

95011823

9 µm

1 l

95011828

9 µm

2.5 l

95015407

9 µm

5 l

Diamond suspension polycrystalline

Grain Size

92002353

1 µm

250 ml

95016017

1 µm

500 ml

92004798

1 µm

1 l

95002761

1 µm

2.5 l

95014519

1 µm

5 l

92002354

3 µm

250 ml

95016018

3 µm

500 ml

92004799

3 µm

1 l

95002762

3 µm

2.5 l

95014520

3 µm

5 l

92002355

6 µm

250 ml

95016019

6 µm

500 ml

92004800

6 µm

1 l

95002763

6 µm

2.5 l

95014521

6 µm

5 l

92002356

9 µm

250 ml

95016020

9 µm

500 ml

92004801

9 µm

1 l

95002764

9 µm

2.5 l

95014522

9 µm

5 l

95005738

15 µm

1 l

Diamond suspension monocrystalline

Grain Size

92002346

1 µm

250 ml

95016012

1 µm

500 ml

92004791

1 µm

1 l

95002755

1 µm

2.5 l

95014514

1 µm

5 l

92002347

3 µm

250 ml

95016013

3 µm

500 ml

92004792

3 µm

1 l

95002756

3 µm

2.5 l

95014515

3 µm

5 l

92002348

6 µm

250 ml

95016014

6 µm

500 ml

92004793

6 µm

1 l

95002757

6 µm

2.5 l

95014516

6 µm

5 l

92002349

9 µm

250 ml

95016015

9 µm

500 ml

92004794

9 µm

1 l

95002758

9 µm

2.5 l

95014517

9 µm

5 l

Diamond suspension (alcohol-based)
polycrystalline

Grain Size

95003494

1 µm

1 l

95003495

3 µm

1 l

95003496

6 µm

1 l

95003497

9 µm

1 l

Diamond suspension (alcohol-based)
monocrystalline

Grain Size (µm)

95003490

1 µm

1 l

95003491

3 µm

1 l

95003492

6 µm

1 l

95003493

9 µm

1 l

Diamond suspension (oil-based)
polycrystalline

Grain Size

95002792

1 µm

1 pc

95002793

3 µm

1 pc

95002794

6 µm

1 pc

95002795

9 µm

1 pc

Accessories

Spray nozzle

• for diamond suspensions of all grain sizes
• for 250 ml, 500 ml and 1 L bottles

95016723 Spray nozzle

Qdoser ONE dosing system for suspensions

Qdoser ONE basic module

Z5631014 Qdoser ONE holder

Z5631016 Qdoser ONE stand

Diamond spray polycrystalline

CFC-free

Grain Size

95016025

1 µm

200 ml

95016026

3 µm

200 ml

95016027

6 µm

200 ml

95016028

9 µm

200 ml

Diamond paste polycrystalline

10 g syringe

Grain Size

92002340

1 µm

10 g

92002341

3 µm

10 g

92002342

6 µm

10 g

92002343

9 µm

10 g

92002344

15 µm

10 g

Diamond paste monocrystalline

10 g syringe

Grain Size

92002333

1 µm

10 g

92002316

3 µm

10 g

92002335

6 µm

10 g

92002336

9 µm

10 g

92002337

15 µm

10 g

Diamond lubricant, additive for diamond suspension/paste

Color

Characteristics

92005509

Yellow

- water-based -

uniform lubricating film

1 l

92004925

Yellow

- water-based -

uniform lubricating film

2.5 l

92005510

Yellow

- water-based -

uniform lubricating film

5 l

95016174

Yellow

- water-based -

uniform lubricating film

10 l

95000901

Blue

- alcohol-based -

for water-free preparation

1 l

95000911

Blue

- alcohol-based -

for water-free preparation

2,5 l

95001194

Blue

- alcohol-based -

for water-free preparation

5 l

95001759

Red

- oil-based -

for water-free preparation

1 l

95001772

Red

- oil-based -

for water-free preparation

2.5 l

95001784

Red

- oil-based -

for water-free preparation

5 l

Diamond lubrication concentrate

• for manual dosing with diamond suspension

Color, Characteristics

95016362 Blue, - for alcohol-based lubricant -
for 10 L lubricant, mix with 9 parts of ethanol, , , 1 l

Ethanol

95004662

Ethanol, 99% denatured

1 l

95004663

Ethanol, 99% denatured

5 l

95004664

Ethanol, 99% denatured

10 l

Fine polishing suspensions

Fine polishing suspension (Al2O3)
• does not crystallize
•for ferrous materials, polymers, composites, PCB, rocks and minerals

Description

ph-value

Grain Size

92002534

Eposal

pH≈8.0

0.06 µm

1 l

Colloidal silica
• for polishing, also mixable with diluted etchant
•

Description

ph-value

Grain Size

92002536

Eposil F

pH≈9.5

0.1 µm

1 l

95013858

Eposil Non Dry

pH≈9.5

0.05 µm

1 l

95013958

Eposil Non Dry

pH≈9.5

0.05 µm

10 l

92002541

Eposil M

pH≈9.5

0.06 µm

1 l

Colloidal silica
• for titanium, nickel, tin and its alloys

Description

ph-value

Grain Size

95001206

Eposil M11

pH≈11.0

0.06 µm

1 l

Water-free fine polishing suspension
• e.g. for magnesium, zinc

Description

ph-value

Grain Size

95005033

Etosil E

pH≈7.0

0.06 µm

1 l

Alumina suspension, calcinated

Aqueous concentrate, to dilute, 3-5 part of dest. water

Description

Grain Size

92002533

Alumina suspension

0.3 µm

1 l

92002532

Alumina suspension

0.6 µm

1 l

92004950

Alumina suspension

1 µm

1 l

Magnetic foil, self-adhesive

Magnetic foil, normal adhesion
• to apply on working wheel

Thickness

92008528

200 mm

1 mm

1 pc

92005820

250 mm

1 mm

1 pc

92005822

300 mm

1 mm

1 pc

Magnetic foil, strong adhesion
• to apply on working wheel

Thickness

95016345

200 mm

1 mm

1 pc

95018002

230 mm

1 mm

1 pc

95016346

250 mm

1 mm

1 pc

95012161

300 mm

1 mm

1 pc

95014137

350 mm

1 mm

1 pc

Magnetic foil, strongest adhesion
• to apply on working wheel
• increased magnetic adhesion by higher material thickness

Thickness

95016298

200 mm

2 mm

1 pc

95018003

230 mm

2 mm

1 pc

95016300

250 mm

2 mm

1 pc

95016301

300 mm

2 mm

1 pc

95016302

350 mm

2 mm

1 pc

GALAXY Polishing cloth with metal back

GALAXY – ALPHA
• Suitable for pre-polishing
• Very hard, perforated chemical fiber cloth
• For ceramics, hard metal, steel, grey cast iron, aluminum
• High lifetime and planarity
• For use with diamond grain size: 15/9 µm
• Fixation system: Magnetic foil

Description

95001407

ALPHA

200 mm

5 pcs

95001408

ALPHA

250 mm

5 pcs

95001409

ALPHA

300 mm

5 pcs

95013994

ALPHA

350 mm

5 pcs

GALAXY – BETA
• Suitable for pre-polishing
• Hard synthetic cloth
• Materials with high hardness, steel, grey cast iron, hard metal, ceramics
• High removal rate
• For use with diamond grain size: 15/9/6 µm
• Fixation system: Magnetic foil

Description

Fixation

95001410

BETA

200 mm

5 pcs

95001411

BETA

250 mm

5 pcs

95001412

BETA

300 mm

5 pcs

95013995

BETA

350 mm

5 pcs

GALAXY – DELTA
• Suitable for pre- & intermediate polishing
• Medium hard silk cloth
• C-steels, precious metal, plastics [CFK, GFK], coatings, aluminum
• For use with diamond grain size: 9/6/3 µm
• Fixation system: Magnetic foil

Description

95001413

DELTA

200 mm

5 pcs

95001414

DELTA

250 mm

5 pcs

95001415

DELTA

300 mm

5 pcs

95013996

DELTA

350 mm

5 pcs

GALAXY - GAMMA
• Suitable for pre- & intermediate polishing
• Medium hard silk cloth
• C-steels, precious metal, coatings, plastics [CFK, GFK]
• For use with diamond grain size: 9/6/3 µm
• Fixation system: Magnetic foil

Description

95017588

GAMMA

200 mm

5 pcs

95017589

GAMMA

250 mm

5 pcs

95017590

GAMMA

300 mm

5 pcs

GALAXY – PHI
• Suitable for pre-, intermediate-, and end polishing
• Medium hard chemical fiber cloth
• For iron, non – ferrous metals, minerals, ceramics, composite materials
• For use with diamond grain size: 9/6/3/1 µm
• Fixation system: Magnetic foil

Description

95012739

PHI

200 mm

5 pcs

95012740

PHI

250 mm

5 pcs

95012741

PHI

300 mm

5 pcs

95014002

PHI

350 mm

5 pcs

GALAXY – SIGMA
• Suitable for intermediate and end polishing
• Soft wool cloth
• For all materials
• For use with diamond grain size: 6/3/1 µm
• Fixation system: Magnetic foil

Description

95001416

SIGMA

200 mm

5 pcs

95001417

SIGMA

250 mm

5 pcs

95001418

SIGMA

300 mm

5 pcs

95013997

SIGMA

350 mm

5 pcs

GALAXY – ETA
• Suitable for end polishing
• Short flocked, medium hard synthetic cloth
• For all materials of medium and high hardness
• For use with diamond grain size: 3/1 µm
• Fixation system: Magnetic foil

Description

95016832

ETA

200 mm

5 pcs

95016833

ETA

250 mm

5 pcs

95016834

ETA

300 mm

5 pcs

95016835

ETA

350 mm

5 pcs

GALAXY – IOTA
• Suitable for end polishing as well as fine polishing with fine polishing suspension
• Long flocked, soft synthetic cloth
• For all materials, especially hard materials
• For use with diamond grain size: 3/1 μm
• Suitable for oxide suspensions
• Fixation system: Magnetic foil

Description

95001419

IOTA

200 mm

5 pcs

95001420

IOTA

250 mm

5 pcs

95001421

IOTA

300 mm

5 pcs

95013998

IOTA

350 mm

5 pcs

GALAXY – ZETA
• Suitable for end polishing as well as fine polishing with fine polishing suspension
• Short flocked, soft synthetic cloth
• For all materials
• For use with diamond grain size: 3/1 µm
•, Suitable for oxide suspensions as well as alumina
• Fixation system: Magnetic foil

Description

95005776

ZETA

200 mm

5 pcs

95005777

ZETA

250 mm

5 pcs

95005778

ZETA

300 mm

5 pcs

95013999

ZETA

350 mm

5 pcs

GALAXY – OMEGA
• Suitable for fine polishing with fine polishing suspension
• Soft synthetic cloth (chemical resistant)
•, For all materials
•, Suitable for oxide suspensions
• Fixation system: Magnetic foil

Description

95005779

OMEGA

200 mm

5 pcs

95005780

OMEGA

250 mm

5 pcs

95005781

OMEGA

300 mm

5 pcs

95014000

OMEGA

350 mm

5 pcs

GALAXY – LAMBDA
• Suitable for fine polishing with fine polishing suspension
• Brushed, structured synthetic cloth (chemical resistant)
• For all materials
•, Suitable for oxide suspensions as well as alumina
• Fixation system: Magnetic foil

Description

95005782

LAMBDA

200 mm

5 pcs

95005783

LAMBDA

250 mm

5 pcs

95005784

LAMBDA

300 mm

5 pcs

95014001

LAMBDA

350 mm

5 pcs

X-Tap

X-Tap (self-adhesive to stick on the working wheel)

GALAXY-X-Tap (for using with magnetic foil)

95017019

200 mm

1 pc

92008802

DELTA

250 mm

5 pcs

92008803

DELTA

300 mm

5 pcs

GAMMA – Polishing cloth
• Suitable for pre- & intermediate polishing
• Medium hard silk cloth
• C-steels, precious metal, coatings, plastics [CFK, GFK],
• For use with diamond grain size: 9/6/3 µm
• Fixation system: X-Tap

Description

92002567

GAMMA

250 mm

5 pcs

92002576

GAMMA

300 mm

5 pcs

PHI – Polishing cloth
• Suitable for pre-, intermediate-, and end polishing
• Medium-hard chemical fiber cloth
• For iron, non-ferrous metals, minerals, ceramics, composite materials
• For use with diamond grain size: 9/6/3/1 μm
• Fixation system: GALAXY X-Tap

Description

92005679

PHI

250 mm

5 pcs

92005680

PHI

300 mm

5 pcs

SIGMA – Polishing cloth
• Suitable for pre- & intermediate polishing
• Soft wool cloth
• For all materials
• For use with diamond grain size: 6/3/1 µm
• Fixation system: X-Tap

Description

92008811

SIGMA

250 mm

5 pcs

92008812

SIGMA

300 mm

5 pcs

ETA – Polishing cloth
•Suitable for end polishing
• Short flocked, medium-hard synthetic cloth
• For all materials of medium and high hardness
• For use with diamond grain size: 3/1 µm
• Fixation system: GALAXY X-Tap

Description

95016829

ETA

250 mm

5 pcs

95016830

ETA

300 mm

5 pcs

IOTA – Polishing cloth
• Suitable for end polishing as well as fine polishing with fine polishing suspension
• Long flocked, soft synthetic cloth
• for all materials, especially hard materials
• For use with diamond grain size: 3/1 µm
• Suitable for oxide suspensions
• Fixation system: X-Tap

Description

95002394

IOTA

250 mm

5 pcs

95002395

IOTA

300 mm

5 pcs

ZETA – Polishing cloth
• Suitable for end polishing as well as fine polishing with fine polishing suspension
• Short flocked, soft synthetic cloth
• for all materials
• For use with diamond grain size: 3/1 µm
• Suitable for oxide suspensions as well as alumina
• Fixation system: X-Tap

Description

92005683

ZETA

250 mm

5 pcs

92005684

ZETA

300 mm

5 pcs

KAPPA – Polishing cloth
• Suitable for fine polishing with fine polishing suspension
• Soft polishing felt
• For all materials
• Suitable for alumina
• Fixation system: X-Tap

Description

92002572

KAPPA

250 mm

5 pcs

92002581

KAPPA

300 mm

5 pcs

OMEGA – Polishing cloth
• Suitable for fine polishing with fine polishing suspension
• Soft synthetic cloth (chemical resistant)
• For all materials
• Suitable for oxide suspensions
• Fixation system: X-Tap

Description

92002571

OMEGA

250 mm

5 pcs

92002580

OMEGA

300 mm

5 pcs

LAMBDA – Polishing cloth
• Suitable for fine polishing with fine polishing suspension
• Brushed, structured synthetic cloth (chemical resistant)
• For all materials
• Suitable for oxide suspensions as well as alumina
• Fixation system: GALAXY X-Tap

Description

95003598

LAMBDA

250 mm

5 pcs

95003599

LAMBDA

300 mm

5 pcs

Media carrier plate for Qpol 250 BOT

• for grinding and polishing robot Qpol 250 BOT (SAPHIR X-Change)

95005867

250 mm

1 pc

Filter inserts

Filter inserts for settling tank
(until year of construction 2012)

Dimensions

Mesh size

95017310

Fleece

290 x 150 x 190 mm

40 µm

95017311

Fleece

290 x 150 x 190 mm

60 µm

Filter inserts for settling tank
(from year of construction 2013)

Dimensions

Mesh size

95017312

Fleece

250 x 200 x 155 mm

60 µm

95017313

Fleece

250 x 200 x 155 mm

100 µm

Filter cartridges for Qpol 300 BOT

Filter cartridge for circulation filter system of the ultrasonic cleaning tank

Filter fineness

Height

Inner-Ø

Outer-Ø

92007119

5 µm

248 mm

28 mm

64 mm

1 pc

92007120

150 µm

248 mm

28 mm

62 mm

1 pc

Polishing Consumables

Accessories for Geology and mineralogy

Bonding jig
• Special pressure transducers for the simultaneous processing of four samples
• For traditional mounting media and adhesives

95017722

Bonding jig

1 pc

Slides

95017713

Slide 48x28 mm, cutted edges, clear

50 pcs

95017714

Slide 48x28 mm, ground edges, clear

50 pcs

95017715

Slide 48x28 mm, cutted edges, matted

50 pcs

95017716

Slide 48x28 mm, ground edges, matted

50 pcs

Coverslip

95017717

Coverslip 24x24 mm

100 pcs

95017718

Coverslip 24x40 mm

100 pcs

Slide boxes

95017719

Slide box for 25 slides, wood

1 pc

95017720

Slide box for 50 slides, wood

1 pc

95017721

Slide box for 100 slides, wood

1 pc

Cover medium

95017723

Cover medium, xylene free

100 ml

Holder for slides

95017724

Hand sample holder for 48x28 mm slides cast aluminum, ergonomic working on manual grinding machines, 56x36x20 mm

1 pc

95017725

Holder for microscope slides 76x32 to 48x28 mm for microscopy, for the use of all microscope slides, 2.0 mm thick

1 pc

Sample holders

Z5446091

Sample holder Geology, single pressure,
incl. 3x sample holder insert ‘Giessener format‘ 48x28 mm					1 pc

Z5651021

Sample holder Qpol Vibro for thin sections,
'Giessener format' 48x28 mm					1 pc

Polishing Consumables

Etching / Analyzing Consumables

F1 - Part B (perchloric acid), equals 1 litre in combination with Part A

1 pc

• Shipping of hazardous materials will be charged extra
• Download of Safety Data Sheets at www.qatm.com

1-component electrolytic etchant

95017935

Oxalic acid 10%, electrolytic etchant for Cr and CrNi steels,
for carbide precipitation at grain boundaries in ferritic and austenitic alloys	1 l

95006393

Barker reagent (for Aluminum grain boundaries)

1 l

Accessories for Qetch 100 M (Kristall 650)

Electrolyte-bottle with screw top

95003955

Volume 1 litre

1 pc

Accessories set for Qetch 100 M (Kristall 650) in suitcase

Z6201001

Suitcase (single-order No.):
• 5 pcs V-ring (Order No.: 95003606)
• 1 pc profile ring material, appr. 150 mm (Order No.: 06201052)
• 1 pc flexible end piece for profile ring (Order No.: 06201051)
• 1 pc tube cutter (Order No.: 95004030)
• 10 pcs filter pads Ø 40.5 mm (Order No.: 95003985)
• 1 pc dolphin clamp (Order No.: 82000374)	1 pc

Etchants

95014346

VisiPro-I Etchant for visualizing the former austenitic grain boundaries (for quenched or tempered low-alloy quenched and tempered steels and case-hardened steels)

500 ml

95014347

VisiPro-I Etchant for visualizing the former austenitic grain boundaries (for quenched or tempered low-alloy quenched and tempered steels and case-hardened steels)

1 l

95017581

VisiPro-I Fast etchant for visualization of former austenite grain boundaries on quenched and tempered unalloyed and low alloy steels through bearing steels (e.g. 102Cr6). Etching time: approximately 2 to 6 minutes, depending on the material.

500 ml

95017582

1 l

95014348

VisiPro-II Etchant for visualizing the former austenitic grain boundaries (for quenched or tempered low-alloy quenched, tempered case hardening steels and anti-friction bearing steels)

500 ml

95014349

VisiPro-II Etchant for visualizing the former austenitic grain boundaries (for quenched or tempered low-alloy quenched, tempered case hardening steels and anti-friction bearing steels)

1 l

92002601

Heyn Etchant (for steel, phoshorous segregations, macro etching, copper alloys, brass)

1 kg

95000508

Copper A, chloride version (for Cu, Cu-alloys, brass and bronze)

500 ml

92002602

Adler Etchant (for steel, weldings, macro etching)

1 kg

92002603

Alcoholic picric acid, 5% Picral (for steel, martensite)

1 l

92006878

Alcoholic Nitric Acid 5% Nital (for unalloyed and low alloyed steels)

1 l

92002597

Alcoholic nitric acid, 3% Nital (for unalloyed and low alloyed steels)

1 l

92002596

Alcoholic nitric acid, 1% Nital (for unalloyed and low alloyed steels)

1 l

92002605

V2A etchant (for austenitic steels), applied at approximately 60°C, contains the additive Dr. Vogel's economy etchant, which acts as an inhibitor and optimizes etching performance

1 kg

92002678

Sodium hydroxide solution (for aluminum alloys)

1 kg

92004240

Oberhoffer Etchant (for steel, segregations, flow-lines, macro/micro etching)

1 kg

92004492

Kroll Etchant (for aluminum alloys, titanium)

1 kg

92004493

Fry Etchant (for steel, macro/micro etching, flow lines)

1 kg

92004222

CU2 etching fluid (copper, copper with sulfide and oxide inclusions)

1 kg

92002750

Sodium picrate (for cementite detection in steel)

1 kg

95002313

Kalling 1 Etchant (for martensitic stainless steel)

1 l

95002347

Kalling 2 Etchant (for nickel, nickel alloys, stainless steels, nickel-copper alloys)

1 kg

95002434

Color etching according to Klemm I (for low carbon steels), stock solution

1 l

95002390

Potassium bisulfite for Klemm I

20 g

95002435

Color etching according to Klemm II (copper, solder joints), stock solution

1 l

95002391

Potassium bislufite for Klemm II

50 g

95002436

Bechet-Beaujard Etchant, prior austenite grain boundaries

1 l

95002408

Murakami Etchant (for hard metals, molybdenum/molybdenum alloys, chromium alloys, tungsten and tungsten alloys)

1 kg

Find the safety data sheets here

Storage bottle for used etchant

95017528

Storage bottle for used etchant

1 pc

Accessories for Etching

Etching bowl, DURAN® glass with cover, heat-resistant

92002629

Ø 60/H 40 mm

1 pc

92002628

Ø 80/H 50 mm

1 pc

92002430

Ø 100/H 60 mm

1 pc

92002626

Ø 150/H 80 mm

1 pc

Etching bowl, polyethylene (PE),

95012078

Ø 90/H 40mm

1 pc

95012079

Ø 110/H 55mm

1 pc

95012080

Ø 110/H 75mm

1 pc

Etching bowl, polypropylene (PP), with screw coupling

95012081

Ø 60/H 60mm

1 pc

95012082

Ø 115/H 70mm

1 pc

Crucible tong

92002431

Crucible tong, stainless

1 pc

95008097

Crucible tong, stainless with insulated handle

Nitrile disposable gloves, blue, size M

100 pcs

95007658

Nitrile disposable gloves, blue, size L

100 pcs

95008208

Nitrile disposable gloves, blue, size XL

100 pcs

Nitrile disposable gloves, green
(conforms to EN 374, EN 455)

95017880

Nitrile disposable gloves, green, size M

100 pcs

95017881

Nitrile disposable gloves, green, size L

100 pcs

95017882

Nitrile disposable gloves, green, size XL

100 pcs

Nitrile disposable gloves, orange
(conforms to EN 21420, EN 374, EN 455)

95017911

Nitrile disposable gloves, orange, size M

50 pcs

95017912

Nitrile disposable gloves, orange, size L

50 pcs

95017913

Nitrile disposable gloves, orange, size XL

50 pcs

Protective gloves black, comply with standard EN 388, EN 374

95003208

Protective gloves, black, size L
- high resistance to water-soluble chemicals
- very durable	1 pair

Spray bottle, 500 ml

1 pc

92004491

Washing bottle with narrow neck, 500 ml

1 pc

Measuring cylinder

92004302

Measuring cylinder, 50 ml

1 pc

92004303

Measuring cylinder, 100 ml

1 pc

Specimen drying unit
• Hot air blower with push button
• Frame made of HPL solid material
• Stainless steel tray made of perforated sheet for placing specimens
• With underlying water protection mat
• Dimensions W x H x D: 350 x 670 x 370 mm

A5810355

Specimen drying unit for set up on table

1 pc

A5810419

Specimen drying unit, with wall bracket

1 pc

ULTRASONIC CLEANING DEVICES

Ultrasonic cleaning device 100
Interior approx. W x H x D: 240 x 140 x 100 mm, capacity: 3 liters
HF power: 80 W, connection: 230 V/50 Hz (1 Ph/N/PE)

92002613

US 100, rotary knob operation

1 pc

92008794

DT 100, digital push-button operation

1 pc

92002609

Perforated hanging basket

1 pc

95017798

Lid

1 pc

Ultrasonic cleaning device 106
Internal diameter/height: 240/130 mm, capacity: 5.6 liters
HF power: 120 W, connection: 230 V/50 Hz (1 Ph/N/PE)

92005839

US 106, rotary knob operation

1 pc

95001285

DT 106, digital push-button operation

1 pc

92005840

Perforated hanging basket

1 pc

92005841

Lid VA

1 pc

Additional ultrasonic cleaning devices available upon request

Cleaning concentrate, alkaline
• for universal use and intensive cleaning
• use 1 – 5%, pH 10 at 2%, removes oils, fats, silicon oil residues, pigments, ink and proteins

92002614

Tickopur R 33

1 l

Cleaning aids
• individually applicable for intensive cleaning

95004662

Ethanol, 99% denatured

1 l

95004663

Ethanol, 99% denatured

5 l

95004664

Ethanol, 99% denatured

10 l

92004510

Aceton, chemically pure, for degreasing of sample surfaces

1 l

Pane cleaning for fume cupboard

Z7510002

Pane cleaning set in suitcase
• Pane wiper magnet
• 2x 30 pcs. cleaning cloths	1 pc

Electric engraving device

95006339

Electric engraving device for marking metal, glass, and plastic with 6 different tips

1 pc

Z5690032

Replacement tip set

1 pc

Replication set

Replica system for non-destructive analyzing of microstructures
quick cured 2 components compound for applying to surfaces;
the cured replica can be removed easily and analysed directly

92006498

2-components-compound

2x50 ml

92006609

Dosing gun

1 pc

92008692

Mixing tube

48 pcs

Assembly cleaner
• for sample preparation, for replication set, in spray can

92004376

Assembly cleaner spray

500 ml

Precision replication material

Replica system
• for surface structures (metallic or mineral),
for surface roughness inspection (R, Ra)

95001664

2-components compound standard

900 ml

Analyzing Consumables

Accessories for microscopy

Supporting accessories

92004109

Plasticine

1 kg

92002943

Microscope slides, metal, 76x26 mm

5 pcs

92004243

Microscope slides, glas, 32x24 mm

100 pcs

92004256

Microscope slides, glas, 40x24 mm

100 pcs

M1321000

Specimen press
• for parallel fixation of specimen on microscope slide
• comfortable operation with minimal effort
• compact, robust and durable
• made of aluminum with anodised surface	1 pc

Storage of samples

Storage systems for readily prepared samples

92002898

Disc cabinet 320 x 320 mm, for discs Ø 300 mm
with 6 drawers	1 pc

92002717

Disc cabinet, 290 x 290 mm, for discs Ø 200 and 250 mm
with 5 drawers	1 pc

95012025

Desiccator cabinet 310 x 525 x 375 mm

1 pc

95012026

Shelf for desiccator cabinet

1 pc

92002868

KC-drying pearls, for use with desiccator

1 pc

A7500417

Sample box, 320 x 320 x 58 mm for 56 Samples Ø 25-32 mm

1 pc

A7500418

Sample box, 320 x 320 x 58 mm for 25 Samples Ø 38-50 mm

1 kg

Literature

Expert Guide Materialography/Metallography
QATM Academy

95016622

Expert Guide Materialography/Metallography, German

1 pc

95016686

Expert Guide Materialography/Metallography, English

1 pc

Metallographie,
Autor: Hermann Schumann

92005114

Metallographie

1 pc

Metallographisches, keramographisches und plastographisches Ätzen,
Autor: Günter Petzow

92004667

Metallographisches, keramographisches und plastographisches Ätzen

1 pc

Metallographische Anleitung zum Farbätzen nach dem Tauchverfahren,
Autoren: E. Weck, E. Leistner

95001841

Nichteisenmetalle, Hartmetalle und Eisenwerkstoffe, Nickel-Basis- und Kobalt-Basis-Legierungen

1 pc

Hardness Testing, Hardness Testing, Hardness test blocks

Hardness Testing

Options

QH00014010 Grid for hardness test block

QH0002401A Additional calibration of a hardness test block

Hardness test blocks Rockwell
(EN ISO 6508-3, ASTM E18)

Material

Value

Dim. (mm)

HRA

QH1110022B

Rockwell

HRA

Aluminum

22 ±1 HR

Ø65x15

QH1110026B

Rockwell

HRA

Aluminum

26 ±1 HR

Ø65x15

QH1110031B

Rockwell

HRA

Aluminum

31 ±1 HR

Ø65x15

QH1110035B

Rockwell

HRA

Aluminum

35 ±1 HR

Ø65x15

QH1110040B

Rockwell

HRA

Aluminum

40 ±1 HR

Ø65x15

QH1110045B

Rockwell

HRA

Aluminum

45 ±1 HR

Ø65x15

QH1110047B

Rockwell

HRA

Aluminum

47 ±1 HR

Ø65x15

QH1110050B

Rockwell

HRA

Aluminum

50 ±1 HR

Ø65x15

QH1110053B

Rockwell

HRA

Aluminum

53 ±1 HR

Ø65x15

QH1110055B

Rockwell

HRA

Steel

55 ±1 HR

Ø65x15

QH1110059B

Rockwell

HRA

Steel

59 ±1 HR

Ø65x15

QH1110060B

Rockwell

HRA

Steel

60 ±1 HR

Ø65x15

QH1110062B

Rockwell

HRA

Steel

62 ±1 HR

Ø65x15

QH1110063B

Rockwell

HRA

Steel

63 ±1 HR

Ø65x15

QH1110065B

Rockwell

HRA

Steel

65 ±1 HR

Ø65x15

QH1110068B

Rockwell

HRA

Steel

68 ±1 HR

Ø65x15

QH1110070B

Rockwell

HRA

Steel

70 ±1 HR

Ø65x15

QH1110073B

Rockwell

HRA

Steel

73 ±1 HR

Ø65x15

QH1110076B

Rockwell

HRA

Steel

76 ±1 HR

Ø65x15

QH1110078B

Rockwell

HRA

Steel

78 ±1 HR

Ø65x15

QH1110081B

Rockwell

HRA

Steel

81 ±1 HR

Ø65x15

QH1110083B

Rockwell

HRA

Steel

83 ±1 HR

Ø65x15

QH1110084B

Rockwell

HRA

Steel

84 ±1 HR

Ø65x15

QH1110085B

Rockwell

HRA

Steel

85 ±1 HR

Ø65x15

QH1110086B

Rockwell

HRA

Steel

86 ±1 HR

Ø65x15

QH1110087B

Rockwell

HRA

Steel

87 ±1 HR

Ø65x15

QH1110088D

Rockwell

HRA

Carbide

88 ±1 HR

25x25x6

QH1110089D

Rockwell

HRA

Carbide

89 ±1 HR

25x25x6

QH1110090D

Rockwell

HRA

Carbide

90 ±1 HR

25x25x6

QH1110091D

Rockwell

HRA

Carbide

91 ±1 HR

25x25x6

QH1110092D

Rockwell

HRA

Carbide

92 ±1 HR

25x25x6

HRB

QH1210020B

Rockwell

HRB

Aluminum

20 ±4 HR

Ø65x15

QH1210025B

Rockwell

HRB

Aluminum

25 ±4 HR

Ø65x15

QH1210030B

Rockwell

HRB

Aluminum

30 ±4 HR

Ø65x15

QH1210035B

Rockwell

HRB

Aluminum

35 ±4 HR

Ø65x15

QH1210040B

Rockwell

HRB

Aluminum

40 ±4 HR

Ø65x15

QH1210045B

Rockwell

HRB

Aluminum

45 ±4 HR

Ø65x15

QH1210050B

Rockwell

HRB

Aluminum

50 ±4 HR

Ø65x15

QH1210055B

Rockwell

HRB

Aluminum

55 ±4 HR

Ø65x15

QH1210060B

Rockwell

HRB

Aluminum

60 ±4 HR

Ø65x15

QH1210065B

Rockwell

HRB

Aluminum

65 ±4 HR

Ø65x15

QH1210070B

Rockwell

HRB

Aluminum

70 ±4 HR

Ø65x15

QH1210075B

Rockwell

HRB

Aluminum

75 ±4 HR

Ø65x15

QH1210080B

Rockwell

HRB

Aluminum

80 ±4 HR

Ø65x15

QH1210085B

Rockwell

HRB

Aluminum

85 ±4 HR

Ø65x15

QH1210090B

Rockwell

HRB

Steel

90 ±4 HR

Ø65x15

QH1210095B

Rockwell

HRB

Steel

95 ±4 HR

Ø65x15

QH1210100B

Rockwell

HRB

Steel

100 ±4 HR

Ø65x15

HRC

QH1120020B

Rockwell

HRC

Steel

20 ±1 HR

Ø65x15

QH1120021B

Rockwell

HRC

Steel

21 ±1 HR

Ø65x15

QH1120022B

Rockwell

HRC

Steel

22 ±1 HR

Ø65x15

QH1120023B

Rockwell

HRC

Steel

23 ±1 HR

Ø65x15

QH1120024B

Rockwell

HRC

Steel

24 ±1 HR

Ø65x15

QH1120025B

Rockwell

HRC

Steel

25 ±1 HR

Ø65x15

QH1120026B

Rockwell

HRC

Steel

26 ±1 HR

Ø65x15

QH1120027B

Rockwell

HRC

Steel

27 ±1 HR

Ø65x15

QH1120028B

Rockwell

HRC

Steel

28 ±1 HR

Ø65x15

QH1120029B

Rockwell

HRC

Steel

29 ±1 HR

Ø65x15

QH1120030B

Rockwell

HRC

Steel

30 ±1 HR

Ø65x15

QH1120031B

Rockwell

HRC

Steel

31 ±1 HR

Ø65x15

QH1120032B

Rockwell

HRC

Steel

32 ±1 HR

Ø65x15

QH1120033B

Rockwell

HRC

Steel

33 ±1 HR

Ø65x15

QH1120034B

Rockwell

HRC

Steel

34 ±1 HR

Ø65x15

QH1120035B

Rockwell

HRC

Steel

35 ±1 HR

Ø65x15

QH1120036B

Rockwell

HRC

Steel

36 ±1 HR

Ø65x15

QH1120037B

Rockwell

HRC

Steel

37 ±1 HR

Ø65x15

QH1120038B

Rockwell

HRC

Steel

38 ±1 HR

Ø65x15

QH1120039B

Rockwell

HRC

Steel

39 ±1 HR

Ø65x15

QH1120040B

Rockwell

HRC

Steel

40 ±1 HR

Ø65x15

QH1120041B

Rockwell

HRC

Steel

41 ±1 HR

Ø65x15

QH1120042B

Rockwell

HRC

Steel

42 ±1 HR

Ø65x15

QH1120043B

Rockwell

HRC

Steel

43 ±1 HR

Ø65x15

QH1120044B

Rockwell

HRC

Steel

44 ±1 HR

Ø65x15

QH1120045B

Rockwell

HRC

Steel

45 ±1 HR

Ø65x15

QH1120046B

Rockwell

HRC

Steel

46 ±1 HR

Ø65x15

QH1120047B

Rockwell

HRC

Steel

47 ±1 HR

Ø65x15

QH1120048B

Rockwell

HRC

Steel

48 ±1 HR

Ø65x15

QH1120049B

Rockwell

HRC

Steel

49 ±1 HR

Ø65x15

QH1120050B

Rockwell

HRC

Steel

50 ±1 HR

Ø65x15

QH1120051B

Rockwell

HRC

Steel

51 ±1 HR

Ø65x15

QH1120052B

Rockwell

HRC

Steel

52 ±1 HR

Ø65x15

QH1120053B

Rockwell

HRC

Steel

53 ±1 HR

Ø65x15

QH1120054B

Rockwell

HRC

Steel

54 ±1 HR

Ø65x15

QH1120055B

Rockwell

HRC

Steel

55 ±1 HR

Ø65x15

QH1120056B

Rockwell

HRC

Steel

56 ±1 HR

Ø65x15

QH1120057B

Rockwell

HRC

Steel

57 ±1 HR

Ø65x15

QH1120058B

Rockwell

HRC

Steel

58 ±1 HR

Ø65x15

QH1120059B

Rockwell

HRC

Steel

59 ±1 HR

Ø65x15

QH1120060B

Rockwell

HRC

Steel

60 ±1 HR

Ø65x15

QH1120061B

Rockwell

HRC

Steel

61 ±1 HR

Ø65x15

QH1120062B

Rockwell

HRC

Steel

62 ±1 HR

Ø65x15

QH1120063B

Rockwell

HRC

Steel

63 ±1 HR

Ø65x15

QH1120064B

Rockwell

HRC

Steel

64 ±1 HR

Ø65x15

QH1120065B

Rockwell

HRC

Steel

65 ±1 HR

Ø65x15

QH1120066B

Rockwell

HRC

Steel

66 ±1 HR

Ø65x15

QH1120067B

Rockwell

HRC

Steel

67 ±1 HR

Ø65x15

QH1120068B

Rockwell

HRC

Steel

68 ±1 HR

Ø65x15

QH1120069B

Rockwell

HRC

Steel

69 ±1 HR

Ø65x15

QH1120070B

Rockwell

HRC

Steel

70 ±1 HR

Ø65x15

QH1120071B

Rockwell

HRC

Steel

71 ±1 HR

Ø65x15

HRD

QH1130040B

Rockwell

HRD

Steel

40 ±2 HR

Ø65x15

QH1130044B

Rockwell

HRD

Steel

44 ±2 HR

Ø65x15

QH1130048B

Rockwell

HRD

Steel

48 ±2 HR

Ø65x15

QH1130052B

Rockwell

HRD

Steel

52 ±2 HR

Ø65x15

QH1130056B

Rockwell

HRD

Steel

56 ±2 HR

Ø65x15

QH1130060B

Rockwell

HRD

Steel

60 ±2 HR

Ø65x15

QH1130064B

Rockwell

HRD

Steel

64 ±2 HR

Ø65x15

QH1130067B

Rockwell

HRD

Steel

67 ±2 HR

Ø65x15

QH1130071B

Rockwell

HRD

Steel

71 ±2 HR

Ø65x15

QH1130073B

Rockwell

HRD

Steel

73 ±2 HR

Ø65x15

QH1130074B

Rockwell

HRD

Steel

74 ±2 HR

Ø65x15

QH1130077B

Rockwell

HRD

Steel

77 ±2 HR

Ø65x15

QH1130078B

Rockwell

HRD

Steel

78 ±2 HR

Ø65x15

QH1130079B

Rockwell

HRD

Steel

79 ±2 HR

Ø65x15

HRE

QH1310075B

Rockwell

HRE

Aluminum

75 ±4 HR

Ø65x15

QH1310081B

Rockwell

HRE

Aluminum

81 ±4 HR

Ø65x15

QH1310087B

Rockwell

HRE

Aluminum

87 ±4 HR

Ø65x15

QH1310093B

Rockwell

HRE

Aluminum

93 ±4 HR

Ø65x15

QH1310100B

Rockwell

HRE

Aluminum

100 ±4 HR

Ø65x15

HRF

QH1220074B

Rockwell

HRF

Aluminum

74 ±4 HR

Ø65x15

QH1220080B

Rockwell

HRF

Aluminum

80 ±4 HR

Ø65x15

QH1220086B

Rockwell

HRF

Aluminum

86 ±4 HR

Ø65x15

QH1220091B

Rockwell

HRF

Aluminum

91 ±4 HR

Ø65x15

QH1220097B

Rockwell

HRF

Aluminum

97 ±4 HR

Ø65x15

QH1220100B

Rockwell

HRF

Aluminum

100 ±4 HR

Ø65x15

HRG

QH1230003B

Rockwell

HRG

Aluminum

3 ±4 HR

Ø65x15

QH1230018B

Rockwell

HRG

Aluminum

18 ±4 HR

Ø65x15

QH1230033B

Rockwell

HRG

Aluminum

33 ±4 HR

Ø65x15

QH1230041B

Rockwell

HRG

Aluminum

41 ±4 HR

Ø65x15

QH1230049B

Rockwell

HRG

Aluminum

49 ±4 HR

Ø65x15

QH1230058B

Rockwell

HRG

Aluminum

58 ±4 HR

Ø65x15

QH1230066B

Rockwell

HRG

Steel

66 ±4 HR

Ø65x15

QH1230074B

Rockwell

HRG

Steel

74 ±4 HR

Ø65x15

QH1230083B

Rockwell

HRG

Steel

83 ±4 HR

Ø65x15

HRH

QH1320087B

Rockwell

HRH

Aluminum

87 ±4 HR

Ø65x15

QH1320094B

Rockwell

HRH

Aluminum

94 ±4 HR

Ø65x15

QH1320098B

Rockwell

HRH

Aluminum

98 ±4 HR

Ø65x15

HRK

QH1330038B

Rockwell

HRK

Aluminum

38 ±4 HR

Ø65x15

QH1330047B

Rockwell

HRK

Aluminum

47 ±4 HR

Ø65x15

QH1330056B

Rockwell

HRK

Aluminum

56 ±4 HR

Ø65x15

QH1330065B

Rockwell

HRK

Aluminum

65 ±4 HR

Ø65x15

QH1330073B

Rockwell

HRK

Aluminum

73 ±4 HR

Ø65x15

QH1330081B

Rockwell

HRK

Aluminum

81 ±4 HR

Ø65x15

QH1330086B

Rockwell

HRK

Aluminum

86 ±4 HR

Ø65x15

QH1330091B

Rockwell

HRK

Aluminum

91 ±4 HR

Ø65x15

QH1330095B

Rockwell

HRK

Aluminum

95 ±4 HR

Ø65x15

QH1330099B

Rockwell

HRK

Steel

99 ±4 HR

Ø65x15

HRL

QH1410092B

Rockwell

HRL

Aluminum

92 ±4 HR

Ø65x15

QH1410118B

Rockwell

HRL

Aluminum

118 ±4 HR

Ø65x15

QH1410123B

Rockwell

HRL

Aluminum

123 ±4 HR

Ø65x15

HRM

QH1420067B

Rockwell

HRM

Aluminum

67 ±4 HR

Ø65x15

QH1420107B

Rockwell

HRM

Aluminum

107 ±4 HR

Ø65x15

QH1420118B

Rockwell

HRM

Aluminum

118 ±4 HR

Ø65x15

HRP

QH1430086B

Rockwell

HRP

Aluminum

86 ±4 HR

Ø65x15

QH1430094B

Rockwell

HRP

Aluminum

94 ±4 HR

Ø65x15

QH1430112B

Rockwell

HRP

Aluminum

112 ±4 HR

Ø65x15

HRR

QH1510105B

Rockwell

HRR

Aluminum

105 ±4 HR

Ø65x15

QH1510123B

Rockwell

HRR

Aluminum

123 ±4 HR

Ø65x15

QH1510126B

Rockwell

HRR

Aluminum

126 ±4 HR

Ø65x15

HRS

QH1520115B

Rockwell

HRS

Aluminum

115 ±4 HR

Ø65x15

QH1520117B

Rockwell

HRS

Aluminum

117 ±4 HR

Ø65x15

QH1520123B

Rockwell

HRS

Aluminum

123 ±4 HR

Ø65x15

HRV

QH1530107B

Rockwell

HRV

Aluminum

107 ±4 HR

Ø65x15

QH1530109B

Rockwell

HRV

Aluminum

109 ±4 HR

Ø65x15

QH1530120B

Rockwell

HRV

Aluminum

120 ±4 HR

Ø65x15

HR15N

QH1140069B

Rockwell

HR 15N

Steel

69 ±2 HR

Ø65x15

QH1140072B

Rockwell

HR 15N

Steel

72 ±2 HR

Ø65x15

QH1140075B

Rockwell

HR 15N

Steel

75 ±2 HR

Ø65x15

QH1140078B

Rockwell

HR 15N

Steel

78 ±2 HR

Ø65x15

QH1140081B

Rockwell

HR 15N

Steel

81 ±2 HR

Ø65x15

QH1140083B

Rockwell

HR 15N

Steel

83 ±2 HR

Ø65x15

QH1140085B

Rockwell

HR 15N

Steel

85 ±2 HR

Ø65x15

QH1140088B

Rockwell

HR 15N

Steel

88 ±2 HR

Ø65x15

QH1140090B

Rockwell

HR 15N

Steel

90 ±2 HR

Ø65x15

QH1140091B

Rockwell

HR 15N

Steel

91 ±2 HR

Ø65x15

QH1140092B

Rockwell

HR 15N

Steel

92 ±2 HR

Ø65x15

QH1140093B

Rockwell

HR 15N

Steel

93 ±2 HR

Ø65x15

QH1140094B

Rockwell

HR 15N

Steel

94 ±2 HR

Ø65x15

HR30N

QH1150041B

Rockwell

HR 30N

Steel

41 ±2 HR

Ø65x15

QH1150046B

Rockwell

HR 30N

Steel

46 ±2 HR

Ø65x15

QH1150050B

Rockwell

HR 30N

Steel

50 ±2 HR

Ø65x15

QH1150055B

Rockwell

HR 30N

Steel

55 ±2 HR

Ø65x15

QH1150059B

Rockwell

HR 30N

Steel

59 ±2 HR

Ø65x15

QH1150064B

Rockwell

HR 30N

Steel

64 ±2 HR

Ø65x15

QH1150068B

Rockwell

HR 30N

Steel

68 ±2 HR

Ø65x15

QH1150073B

Rockwell

HR 30N

Steel

73 ±2 HR

Ø65x15

QH1150077B

Rockwell

HR 30N

Steel

77 ±2 HR

Ø65x15

QH1150080B

Rockwell

HR 30N

Steel

80 ±2 HR

Ø65x15

QH1150082B

Rockwell

HR 30N

Steel

82 ±2 HR

Ø65x15

QH1150083B

Rockwell

HR 30N

Steel

83 ±2 HR

Ø65x15

QH1150084B

Rockwell

HR 30N

Steel

84 ±2 HR

Ø65x15

QH1150085B

Rockwell

HR 30N

Steel

85 ±2 HR

Ø65x15

QH1150086B

Rockwell

HR 30N

Steel

86 ±2 HR

Ø65x15

HR45N

QH1160019B

Rockwell

HR 45N

Steel

19 ±2 HR

Ø65x15

QH1160025B

Rockwell

HR 45N

Steel

25 ±2 HR

Ø65x15

QH1160031B

Rockwell

HR 45N

Steel

31 ±2 HR

Ø65x15

QH1160037B

Rockwell

HR 45N

Steel

37 ±2 HR

Ø65x15

QH1160043B

Rockwell

HR 45N

Steel

43 ±2 HR

Ø65x15

QH1160049B

Rockwell

HR 45N

Steel

49 ±2 HR

Ø65x15

QH1160055B

Rockwell

HR 45N

Steel

55 ±2 HR

Ø65x15

QH1160061B

Rockwell

HR 45N

Steel

61 ±2 HR

Ø65x15

QH1160066B

Rockwell

HR 45N

Steel

66 ±2 HR

Ø65x15

QH1160070B

Rockwell

HR 45N

Steel

70 ±2 HR

Ø65x15

QH1160072B

Rockwell

HR 45N

Steel

72 ±2 HR

Ø65x15

QH1160074B

Rockwell

HR 45N

Steel

74 ±2 HR

Ø65x15

QH1160075B

Rockwell

HR 45N

Steel

75 ±2 HR

Ø65x15

QH1160076B

Rockwell

HR 45N

Steel

76 ±2 HR

Ø65x15

QH1160077B

Rockwell

HR 45N

Steel

77 ±2 HR

Ø65x15

QH1160078B

Rockwell

HR 45N

Steel

78 ±2 HR

Ø65x15

HR15T

QH1240067B

Rockwell

HR 15T

Aluminum

67 ±4 HR

Ø65x15

QH1240070B

Rockwell

HR 15T

Aluminum

70 ±4 HR

Ø65x15

QH1240073B

Rockwell

HR 15T

Aluminum

73 ±4 HR

Ø65x15

QH1240077B

Rockwell

HR 15T

Aluminum

77 ±4 HR

Ø65x15

QH1240080B

Rockwell

HR 15T

Aluminum

80 ±4 HR

Ø65x15

QH1240083B

Rockwell

HR 15T

Aluminum

83 ±4 HR

Ø65x15

QH1240085B

Rockwell

HR 15T

Aluminum

85 ±4 HR

Ø65x15

QH1240086B

Rockwell

HR 15T

Aluminum

86 ±4 HR

Ø65x15

QH1240088B

Rockwell

HR 15T

Aluminum

88 ±4 HR

Ø65x15

QH1240090B

Rockwell

HR 15T

Steel

90 ±4 HR

Ø65x15

QH1240091B

Rockwell

HR 15T

Steel

91 ±4 HR

Ø65x15

QH1240093B

Rockwell

HR 15T

Steel

93 ±4 HR

Ø65x15

HR30T

QH1250029B

Rockwell

HR 30T

Aluminum

29 ±4 HR

Ø65x15

QH1250036B

Rockwell

HR 30T

Aluminum

36 ±4 HR

Ø65x15

QH1250043B

Rockwell

HR 30T

Aluminum

43 ±4 HR

Ø65x15

QH1250049B

Rockwell

HR 30T

Aluminum

49 ±4 HR

Ø65x15

QH1250056B

Rockwell

HR 30T

Aluminum

56 ±4 HR

Ø65x15

QH1250063B

Rockwell

HR 30T

Aluminum

63 ±4 HR

Ø65x15

QH1250066B

Rockwell

HR 30T

Aluminum

66 ±4 HR

Ø65x15

QH1250069B

Rockwell

HR 30T

Aluminum

69 ±4 HR

Ø65x15

QH1250073B

Rockwell

HR 30T

Aluminum

73 ±4 HR

Ø65x15

QH1250076B

Rockwell

HR 30T

Steel

76 ±4 HR

Ø65x15

QH1250080B

Rockwell

HR 30T

Steel

80 ±4 HR

Ø65x15

QH1250083B

Rockwell

HR 30T

Steel

83 ±4 HR

Ø65x15

HR45T

QH1260002B

Rockwell

HR 45T

Aluminum

2 ±4 HR

Ø65x15

QH1260012B

Rockwell

HR 45T

Aluminum

12 ±4 HR

Ø65x15

QH1260022B

Rockwell

HR 45T

Aluminum

22 ±4 HR

Ø65x15

QH1260032B

Rockwell

HR 45T

Aluminum

32 ±4 HR

Ø65x15

QH1260043B

Rockwell

HR 45T

Aluminum

43 ±4 HR

Ø65x15

QH1260048B

Rockwell

HR 45T

Aluminum

48 ±4 HR

Ø65x15

QH1260053B

Rockwell

HR 45T

Aluminum

53 ±4 HR

Ø65x15

QH1260058B

Rockwell

HR 45T

Aluminum

58 ±4 HR

Ø65x15

QH1260063B

Rockwell

HR 45T

Steel

63 ±4 HR

Ø65x15

QH1260068B

Rockwell

HR 45T

Steel

68 ±4 HR

Ø65x15

QH1260073B

Rockwell

HR 45T

Steel

73 ±4 HR

Ø65x15

HR15W

QH1340084B

Rockwell

HR 15W

Aluminum

84 ±4 HR

Ø65x15

QH1340087B

Rockwell

HR 15W

Aluminum

87 ±4 HR

Ø65x15

QH1340094B

Rockwell

HR 15W

Aluminum

94 ±4 HR

Ø65x15

HR30W

QH1350067B

Rockwell

HR 30W

Aluminum

67 ±4 HR

Ø65x15

QH1350073B

Rockwell

HR 30W

Aluminum

73 ±4 HR

Ø65x15

QH1350087B

Rockwell

HR 30W

Aluminum

87 ±4 HR

Ø65x15

HR45W

QH1360050B

Rockwell

HR 45W

Aluminum

50 ±4 HR

Ø65x15

QH1360059B

Rockwell

HR 45W

Aluminum

59 ±4 HR

Ø65x15

QH1360080B

Rockwell

HR 45W

Aluminum

80 ±4 HR

Ø65x15

HR15X

QH1440092B

Rockwell

HR 15X

Aluminum

92 ±4 HR

Ø65x15

QH1440093B

Rockwell

HR 15X

Aluminum

93 ±4 HR

Ø65x15

QH1440096B

Rockwell

HR 15X

Aluminum

96 ±4 HR

Ø65x15

HR30X

QH1450082B

Rockwell

HR 30X

Aluminum

82 ±4 HR

Ø65x15

QH1450084B

Rockwell

HR 30X

Aluminum

84 ±4 HR

Ø65x15

QH1450092B

Rockwell

HR 30X

Aluminum

92 ±4 HR

Ø65x15

HR45X

QH1460072B

Rockwell

HR 45X

Aluminum

72 ±4 HR

Ø65x15

QH1460076B

Rockwell

HR 45X

Aluminum

76 ±4 HR

Ø65x15

QH1460085B

Rockwell

HR 45X

Aluminum

85 ±4 HR

Ø65x15

HR15Y

QH1540095B

Rockwell

HR 15Y

Aluminum

95 ±4 HR

Ø65x15

QH1540096B

Rockwell

HR 15Y

Aluminum

96 ±4 HR

Ø65x15

QH1540098B

Rockwell

HR 15Y

Aluminum

98 ±4 HR

Ø65x15

HR30Y

QH1550090B

Rockwell

HR 30Y

Aluminum

90 ±4 HR

Ø65x15

QH1550091B

Rockwell

HR 30Y

Aluminum

91 ±4 HR

Ø65x15

QH1550095B

Rockwell

HR 30Y

Aluminum

95 ±4 HR

Ø65x15

HR45Y

QH1560085B

Rockwell

HR 45Y

Aluminum

85 ±4 HR

Ø65x15

QH1560087B

Rockwell

HR 45Y

Aluminum

87 ±4 HR

Ø65x15

QH1560094B

Rockwell

HR 45Y

Aluminum

94 ±4 HR

Ø65x15

Hardness test blocks Brinell
(EN ISO 6506-3, ASTM E10)

HBW

Material

Value

Dim. (mm)

HBW 10/500

QH2440070C

Brinell

HBW 10/500

Aluminum

70 ±15 HB

150x125x16-20

QH2440100C

Brinell

HBW 10/500

Aluminum

100 ±15 HB

150x125x16-20

HBW 10/1000

QH2450070C

Brinell

HBW 10/1000

Aluminum

70 ±15 HB

150x125x16-20

QH2450100C

Brinell

HBW 10/1000

Aluminum

100 ±15 HB

150x125x16-20

QH2450130C

Brinell

HBW 10/1000

Aluminum

130 ±15 HB

150x125x16-20

QH2450150C

Brinell

HBW 10/1000

Aluminum

150 ±15 HB

150x125x16-20

QH2450170C

Brinell

HBW 10/1000

Aluminum

170 ±15 HB

150x125x16-20

QH2450200C

Brinell

HBW 10/1000

Steel

200 ±15 HB

150x125x16-20

HBW 10/1500

QH2460070C

Brinell

HBW 10/1500

Aluminum

70 ±15 HB

150x125x16-20

QH2460100C

Brinell

HBW 10/1500

Aluminum

100 ±15 HB

150x125x16-20

QH2460130C

Brinell

HBW 10/1500

Aluminum

130 ±15 HB

150x125x16-20

QH2460150C

Brinell

HBW 10/1500

Aluminum

150 ±15 HB

150x125x16-20

QH2460170C

Brinell

HBW 10/1500

Aluminum

170 ±15 HB

150x125x16-20

QH2460200C

Brinell

HBW 10/1500

Steel

200 ±15 HB

150x125x16-20

QH2460250C

Brinell

HBW 10/1500

Steel

250 ±15 HB

150x125x16-20

QH2460300C

Brinell

HBW 10/1500

Steel

300 ±15 HB

150x125x16-20

HBW 10/3000

QH2470070C

Brinell

HBW 10/3000

Aluminum

70 ±15 HB

150x125x16-20

QH2470100C

Brinell

HBW 10/3000

Aluminum

100 ±15 HB

150x125x16-20

QH2470130C

Brinell

HBW 10/3000

Aluminum

130 ±15 HB

150x125x16-20

QH2470150C

Brinell

HBW 10/3000

Aluminum

150 ±15 HB

150x125x16-20

QH2470170C

Brinell

HBW 10/3000

Aluminum

170 ±15 HB

150x125x16-20

QH2470200C

Brinell

HBW 10/3000

Steel

200 ±15 HB

150x125x16-20

QH2470250C

Brinell

HBW 10/3000

Steel

250 ±15 HB

150x125x16-20

QH2470300C

Brinell

HBW 10/3000

Steel

300 ±15 HB

150x125x16-20

QH2470350C

Brinell

HBW 10/3000

Steel

350 ±15 HB

150x125x16-20

QH2470400C

Brinell

HBW 10/3000

Steel

400 ±15 HB

150x125x16-20

QH2470450C

Brinell

HBW 10/3000

Steel

450 ±15 HB

150x125x16-20

QH2470500C

Brinell

HBW 10/3000

Steel

500 ±15 HB

150x125x16-20

QH2470550C

Brinell

HBW 10/3000

Steel

550 ±15 HB

150x125x16-20

QH2470600C

Brinell

HBW 10/3000

Steel

600 ±15 HB

150x125x16-20

QH2470650C

Brinell

HBW 10/3000

Steel

650 ±15 HB

150x125x16-20

HBW 5/62.5

QH2330040B

Brinell

HBW 5/62.5

Aluminum

40 ±15 HB

Ø65x15

HBW 5/125

QH2340040B

Brinell

HBW 5/125

Aluminum

40 ±15 HB

Ø65x15

QH2340070B

Brinell

HBW 5/125

Aluminum

70 ±15 HB

Ø65x15

QH2340100B

Brinell

HBW 5/125

Aluminum

100 ±15 HB

Ø65x15

HBW 5/250

QH2350070C

Brinell

HBW 5/250

Aluminum

70 ±15 HB

150x125x16-20

QH2350100C

Brinell

HBW 5/250

Aluminum

100 ±15 HB

150x125x16-20

QH2350130C

Brinell

HBW 5/250

Aluminum

130 ±15 HB

150x125x16-20

QH2350150C

Brinell

HBW 5/250

Aluminum

150 ±15 HB

150x125x16-20

QH2350170C

Brinell

HBW 5/250

Aluminum

170 ±15 HB

150x125x16-20

QH2350200C

Brinell

HBW 5/250

Steel

200 ±15 HB

150x125x16-20

HBW 5/750

QH2360070C

Brinell

HBW 5/750

Aluminum

70 ±15 HB

150x125x16-20

QH2360100C

Brinell

HBW 5/750

Aluminum

100 ±15 HB

150x125x16-20

QH2360130C

Brinell

HBW 5/750

Aluminum

130 ±15 HB

150x125x16-20

QH2360150C

Brinell

HBW 5/750

Aluminum

150 ±15 HB

150x125x16-20

QH2360170C

Brinell

HBW 5/750

Aluminum

170 ±15 HB

150x125x16-20

QH2360200C

Brinell

HBW 5/750

Steel

200 ±15 HB

150x125x16-20

QH2360250C

Brinell

HBW 5/750

Steel

250 ±15 HB

150x125x16-20

QH2360300C

Brinell

HBW 5/750

Steel

300 ±15 HB

150x125x16-20

QH2360350C

Brinell

HBW 5/750

Steel

350 ±15 HB

150x125x16-20

QH2360400C

Brinell

HBW 5/750

Steel

400 ±15 HB

150x125x16-20

QH2360450C

Brinell

HBW 5/750

Steel

450 ±15 HB

150x125x16-20

QH2360500C

Brinell

HBW 5/750

Steel

500 ±15 HB

150x125x16-20

QH2360550C

Brinell

HBW 5/750

Steel

550 ±15 HB

150x125x16-20

QH2360600C

Brinell

HBW 5/750

Steel

600 ±15 HB

150x125x16-20

QH2360650C

Brinell

HBW 5/750

Steel

650 ±15 HB

150x125x16-20

HBW 2.5/62.5

QH2250040B

Brinell

HBW 2.5/62.5

Aluminum

40 ±15 HB

Ø65x15

QH2250070B

Brinell

HBW 2.5/62.5

Aluminum

70 ±15 HB

Ø65x15

QH2250100B

Brinell

HBW 2.5/62.5

Aluminum

100 ±15 HB

Ø65x15

QH2250130B

Brinell

HBW 2.5/62.5

Aluminum

130 ±15 HB

Ø65x15

QH2250150B

Brinell

HBW 2.5/62.5

Aluminum

150 ±15 HB

Ø65x15

QH2250170B

Brinell

HBW 2.5/62.5

Aluminum

170 ±15 HB

Ø65x15

QH2250200B

Brinell

HBW 2.5/62.5

Steel

200 ±15 HB

Ø65x15

HBW 2.5/187.5

QH2260100B

Brinell

HBW 2.5/187.5

Aluminum

100 ±15 HB

Ø65x15

QH2260130B

Brinell

HBW 2.5/187.5

Aluminum

130 ±15 HB

Ø65x15

QH2260150B

Brinell

HBW 2.5/187.5

Aluminum

150 ±15 HB

Ø65x15

QH2260170B

Brinell

HBW 2.5/187.5

Aluminum

170 ±15 HB

Ø65x15

QH2260200B

Brinell

HBW 2.5/187.5

Steel

200 ±15 HB

Ø65x15

QH2260250B

Brinell

HBW 2.5/187.5

Steel

250 ±15 HB

Ø65x15

QH2260300B

Brinell

HBW 2.5/187.5

Steel

300 ±15 HB

Ø65x15

QH2260350B

Brinell

HBW 2.5/187.5

Steel

350 ±15 HB

Ø65x15

QH2260400B

Brinell

HBW 2.5/187.5

Steel

400 ±15 HB

Ø65x15

QH2260450B

Brinell

HBW 2.5/187.5

Steel

450 ±15 HB

Ø65x15

QH2260500B

Brinell

HBW 2.5/187.5

Steel

500 ±15 HB

Ø65x15

QH2260550B

Brinell

HBW 2.5/187.5

Steel

550 ±15 HB

Ø65x15

QH2260600B

Brinell

HBW 2.5/187.5

Steel

600 ±15 HB

Ø65x15

HBW 1/2.5

QH2130040B

Brinell

HBW 1/2.5

Aluminum

40 ±15 HB

Ø65x15

HBW 1/5

QH2140040B

Brinell

HBW 1/5

Aluminum

40 ±15 HB

Ø65x15

QH2140070B

Brinell

HBW 1/5

Aluminum

70 ±15 HB

Ø65x15

QH2140100B

Brinell

HBW 1/5

Aluminum

100 ±15 HB

Ø65x15

HBW 1/10

QH2150040B

Brinell

HBW 1/10

Aluminum

40 ±15 HB

Ø65x15

QH2150070B

Brinell

HBW 1/10

Aluminum

70 ±15 HB

Ø65x15

QH2150100B

Brinell

HBW 1/10

Aluminum

100 ±15 HB

Ø65x15

QH2150130B

Brinell

HBW 1/10

Aluminum

130 ±15 HB

Ø65x15

QH2150150B

Brinell

HBW 1/10

Aluminum

150 ±15 HB

Ø65x15

QH2150170B

Brinell

HBW 1/10

Aluminum

170 ±15 HB

Ø65x15

QH2150200B

Brinell

HBW 1/10

Steel

200 ±15 HB

Ø65x15

HBW 1/30

QH2160100B

Brinell

HBW 1/30

Aluminum

100 ±15 HB

Ø65x15

QH2160130B

Brinell

HBW 1/30

Aluminum

130 ±15 HB

Ø65x15

QH2160150B

Brinell

HBW 1/30

Aluminum

150 ±15 HB

Ø65x15

QH2160170B

Brinell

HBW 1/30

Aluminum

170 ±15 HB

Ø65x15

QH2160200B

Brinell

HBW 1/30

Steel

200 ±15 HB

Ø65x15

QH2160250B

Brinell

HBW 1/30

Steel

250 ±15 HB

Ø65x15

QH2160300B

Brinell

HBW 1/30

Steel

300 ±15 HB

Ø65x15

QH2160350B

Brinell

HBW 1/30

Steel

350 ±15 HB

Ø65x15

QH2160400B

Brinell

HBW 1/30

Steel

400 ±15 HB

Ø65x15

QH2160450B

Brinell

HBW 1/30

Steel

450 ±15 HB

Ø65x15

QH2160500B

Brinell

HBW 1/30

Steel

500 ±15 HB

Ø65x15

QH2160550B

Brinell

HBW 1/30

Steel

550 ±15 HB

Ø65x15

QH2160600B

Brinell

HBW 1/30

Steel

600 ±15 HB

Ø65x15

Hardness test blocks Vickers
(EN ISO 6507-3, ASTM E92)

Material

Value

Dim. (mm)

HV 0.01

QH3050040A

Vickers

HV 0.01

Aluminum

40 ±25 HV

Ø30x10

HV 0.025

QH3080040A

Vickers

HV 0.025

Aluminum

40 ±25 HV

Ø30x10

QH3080070A

Vickers

HV 0.025

Aluminum

70 ±25 HV

Ø30x10

QH3080100A

Vickers

HV 0.025

Aluminum

100 ±25 HV

Ø30x10

HV 0.05

QH3090040A

Vickers

HV 0.05

Aluminum

40 ±25 HV

Ø30x10

QH3090070A

Vickers

HV 0.05

Aluminum

70 ±25 HV

Ø30x10

QH3090100A

Vickers

HV 0.05

Aluminum

100 ±25 HV

Ø30x10

QH3090150A

Vickers

HV 0.05

Aluminum

150 ±25 HV

Ø30x10

QH3090200A

Vickers

HV 0.05

Steel

200 ±25 HV

Ø30x10

HV 0.1

QH3100040A

Vickers

HV 0.1

Aluminum

40 ±25 HV

Ø30x10

QH3100070A

Vickers

HV 0.1

Aluminum

70 ±25 HV

Ø30x10

QH3100100A

Vickers

HV 0.1

Aluminum

100 ±25 HV

Ø30x10

QH3100150A

Vickers

HV 0.1

Aluminum

150 ±25 HV

Ø30x10

QH3100200A

Vickers

HV 0.1

Steel

200 ±25 HV

Ø30x10

QH3100250A

Vickers

HV 0.1

Steel

250 ±25 HV

Ø30x10

QH3100300A

Vickers

HV 0.1

Steel

300 ±25 HV

Ø30x10

QH3100350A

Vickers

HV 0.1

Steel

350 ±25 HV

Ø30x10

QH3100400A

Vickers

HV 0.1

Steel

400 ±25 HV

Ø30x10

QH3100450A

Vickers

HV 0.1

Steel

450 ±25 HV

Ø30x10

HV 0.2

QH3110040A

Vickers

HV 0.2

Aluminum

40 ±25 HV

Ø30x10

QH3110070A

Vickers

HV 0.2

Aluminum

70 ±25 HV

Ø30x10

QH3110100A

Vickers

HV 0.2

Aluminum

100 ±25 HV

Ø30x10

QH3110150A

Vickers

HV 0.2

Aluminum

150 ±25 HV

Ø30x10

QH3110200A

Vickers

HV 0.2

Steel

200 ±25 HV

Ø30x10

QH3110250A

Vickers

HV 0.2

Steel

250 ±25 HV

Ø30x10

QH3110300A

Vickers

HV 0.2

Steel

300 ±25 HV

Ø30x10

QH3110350A

Vickers

HV 0.2

Steel

350 ±25 HV

Ø30x10

QH3110400A

Vickers

HV 0.2

Steel

400 ±25 HV

Ø30x10

QH3110450A

Vickers

HV 0.2

Steel

450 ±25 HV

Ø30x10

QH3110500A

Vickers

HV 0.2

Steel

500 ±25 HV

Ø30x10

QH3110550A

Vickers

HV 0.2

Steel

550 ±25 HV

Ø30x10

QH3110600A

Vickers

HV 0.2

Steel

600 ±25 HV

Ø30x10

QH3110650A

Vickers

HV 0.2

Steel

650 ±25 HV

Ø30x10

QH3110700A

Vickers

HV 0.2

Steel

700 ±25 HV

Ø30x10

QH3110750A

Vickers

HV 0.2

Steel

750 ±25 HV

Ø30x10

QH3110800A

Vickers

HV 0.2

Steel

800 ±25 HV

Ø30x10

QH3110850A

Vickers

HV 0.2

Steel

850 ±25 HV

Ø30x10

QH3110900A

Vickers

HV 0.2

Steel

900 ±25 HV

Ø30x10

HV 0.3

QH3120040A

Vickers

HV 0.3

Aluminum

40 ±25 HV

Ø30x10

QH3120070A

Vickers

HV 0.3

Aluminum

70 ±25 HV

Ø30x10

QH3120100A

Vickers

HV 0.3

Aluminum

100 ±25 HV

Ø30x10

QH3120150A

Vickers

HV 0.3

Aluminum

150 ±25 HV

Ø30x10

QH3120200A

Vickers

HV 0.3

Steel

200 ±25 HV

Ø30x10

QH3120250A

Vickers

HV 0.3

Steel

250 ±25 HV

Ø30x10

QH3120300A

Vickers

HV 0.3

Steel

300 ±25 HV

Ø30x10

QH3120350A

Vickers

HV 0.3

Steel

350 ±25 HV

Ø30x10

QH3120400A

Vickers

HV 0.3

Steel

400 ±25 HV

Ø30x10

QH3120450A

Vickers

HV 0.3

Steel

450 ±25 HV

Ø30x10

QH3120500A

Vickers

HV 0.3

Steel

500 ±25 HV

Ø30x10

QH3120550A

Vickers

HV 0.3

Steel

550 ±25 HV

Ø30x10

QH3120600A

Vickers

HV 0.3

Steel

600 ±25 HV

Ø30x10

QH3120650A

Vickers

HV 0.3

Steel

650 ±25 HV

Ø30x10

QH3120700A

Vickers

HV 0.3

Steel

700 ±25 HV

Ø30x10

QH3120750A

Vickers

HV 0.3

Steel

750 ±25 HV

Ø30x10

QH3120800A

Vickers

HV 0.3

Steel

800 ±25 HV

Ø30x10

QH3120850A

Vickers

HV 0.3

Steel

850 ±25 HV

Ø30x10

QH3120900A

Vickers

HV 0.3

Steel

900 ±25 HV

Ø30x10

QH3120950A

Vickers

HV 0.3

Steel

950 ±25 HV

Ø30x10

QH3121000A

Vickers

HV 0.3

Steel

1000 ±25 HV

Ø30x10

QH3121050A

Vickers

HV 0.3

Steel

1050 ±25 HV

Ø30x10

QH3121100A

Vickers

HV 0.3

Steel

1100 ±25 HV

Ø30x10

HV 0.5

QH3130040A

Vickers

HV 0.5

Aluminum

40 ±25 HV

Ø30x10

QH3130070A

Vickers

HV 0.5

Aluminum

70 ±25 HV

Ø30x10

QH3130100A

Vickers

HV 0.5

Aluminum

100 ±25 HV

Ø30x10

QH3130150A

Vickers

HV 0.5

Aluminum

150 ±25 HV

Ø30x10

QH3130200A

Vickers

HV 0.5

Steel

200 ±25 HV

Ø30x10

QH3130250A

Vickers

HV 0.5

Steel

250 ±25 HV

Ø30x10

QH3130300A

Vickers

HV 0.5

Steel

300 ±25 HV

Ø30x10

QH3130350A

Vickers

HV 0.5

Steel

350 ±25 HV

Ø30x10

QH3130400A

Vickers

HV 0.5

Steel

400 ±25 HV

Ø30x10

QH3130450A

Vickers

HV 0.5

Steel

450 ±25 HV

Ø30x10

QH3130500A

Vickers

HV 0.5

Steel

500 ±25 HV

Ø30x10

QH3130550A

Vickers

HV 0.5

Steel

550 ±25 HV

Ø30x10

QH3130600A

Vickers

HV 0.5

Steel

600 ±25 HV

Ø30x10

QH3130650A

Vickers

HV 0.5

Steel

650 ±25 HV

Ø30x10

QH3130700A

Vickers

HV 0.5

Steel

700 ±25 HV

Ø30x10

QH3130750A

Vickers

HV 0.5

Steel

750 ±25 HV

Ø30x10

QH3130800A

Vickers

HV 0.5

Steel

800 ±25 HV

Ø30x10

QH3130850A

Vickers

HV 0.5

Steel

850 ±25 HV

Ø30x10

QH3130900A

Vickers

HV 0.5

Steel

900 ±25 HV

Ø30x10

QH3130950A

Vickers

HV 0.5

Steel

950 ±25 HV

Ø30x10

QH3131000A

Vickers

HV 0.5

Steel

1000 ±25 HV

Ø30x10

QH3131050A

Vickers

HV 0.5

Steel

1050 ±25 HV

Ø30x10

QH3131100A

Vickers

HV 0.5

Steel

1100 ±25 HV

Ø30x10

HV 1

QH3140040A

Vickers

HV 1

Aluminum

40 ±25 HV

Ø30x10

QH3140070A

Vickers

HV 1

Aluminum

70 ±25 HV

Ø30x10

QH3140100A

Vickers

HV 1

Aluminum

100 ±25 HV

Ø30x10

QH3140150A

Vickers

HV 1

Aluminum

150 ±25 HV

Ø30x10

QH3140200A

Vickers

HV 1

Steel

200 ±25 HV

Ø30x10

QH3140250A

Vickers

HV 1

Steel

250 ±25 HV

Ø30x10

QH3140300A

Vickers

HV 1

Steel

300 ±25 HV

Ø30x10

QH3140350A

Vickers

HV 1

Steel

350 ±25 HV

Ø30x10

QH3140400A

Vickers

HV 1

Steel

400 ±25 HV

Ø30x10

QH3140450A

Vickers

HV 1

Steel

450 ±25 HV

Ø30x10

QH3140500A

Vickers

HV 1

Steel

500 ±25 HV

Ø30x10

QH3140550A

Vickers

HV 1

Steel

550 ±25 HV

Ø30x10

QH3140600A

Vickers

HV 1

Steel

600 ±25 HV

Ø30x10

QH3140650A

Vickers

HV 1

Steel

650 ±25 HV

Ø30x10

QH3140700A

Vickers

HV 1

Steel

700 ±25 HV

Ø30x10

QH3140750A

Vickers

HV 1

Steel

750 ±25 HV

Ø30x10

QH3140800A

Vickers

HV 1

Steel

800 ±25 HV

Ø30x10

QH3140850A

Vickers

HV 1

Steel

850 ±25 HV

Ø30x10

QH3140900A

Vickers

HV 1

Steel

900 ±25 HV

Ø30x10

QH3140950A

Vickers

HV 1

Steel

950 ±25 HV

Ø30x10

QH3141000A

Vickers

HV 1

Steel

1000 ±25 HV

Ø30x10

QH3141050A

Vickers

HV 1

Steel

1050 ±25 HV

Ø30x10

QH3141100A

Vickers

HV 1

Steel

1100 ±25 HV

Ø30x10

HV 2

QH3150040B

Vickers

HV 2

Aluminum

40 ±25 HV

Ø65x15

QH3150070B

Vickers

HV 2

Aluminum

70 ±25 HV

Ø65x15

QH3150100B

Vickers

HV 2

Aluminum

100 ±25 HV

Ø65x15

QH3150150B

Vickers

HV 2

Aluminum

150 ±25 HV

Ø65x15

QH3150200B

Vickers

HV 2

Steel

200 ±25 HV

Ø65x15

QH3150250B

Vickers

HV 2

Steel

250 ±25 HV

Ø65x15

QH3150300B

Vickers

HV 2

Steel

300 ±25 HV

Ø65x15

QH3150350B

Vickers

HV 2

Steel

350 ±25 HV

Ø65x15

QH3150400B

Vickers

HV 2

Steel

400 ±25 HV

Ø65x15

QH3150450B

Vickers

HV 2

Steel

450 ±25 HV

Ø65x15

QH3150500B

Vickers

HV 2

Steel

500 ±25 HV

Ø65x15

QH3150550B

Vickers

HV 2

Steel

550 ±25 HV

Ø65x15

QH3150600B

Vickers

HV 2

Steel

600 ±25 HV

Ø65x15

QH3150650B

Vickers

HV 2

Steel

650 ±25 HV

Ø65x15

QH3150700B

Vickers

HV 2

Steel

700 ±25 HV

Ø65x15

QH3150750B

Vickers

HV 2

Steel

750 ±25 HV

Ø65x15

QH3150800B

Vickers

HV 2

Steel

800 ±25 HV

Ø65x15

QH3150850B

Vickers

HV 2

Steel

850 ±25 HV

Ø65x15

QH3150900B

Vickers

HV 2

Steel

900 ±25 HV

Ø65x15

QH3150950B

Vickers

HV 2

Steel

950 ±25 HV

Ø65x15

QH3151000B

Vickers

HV 2

Steel

1000 ±25 HV

Ø65x15

QH3151050B

Vickers

HV 2

Steel

1050 ±25 HV

Ø65x15

HV 2.5

QH3160040B

Vickers

HV 2.5

Aluminum

40 ±25 HV

Ø65x15

QH3160070B

Vickers

HV 2.5

Aluminum

70 ±25 HV

Ø65x15

QH3160100B

Vickers

HV 2.5

Aluminum

100 ±25 HV

Ø65x15

QH3160150B

Vickers

HV 2.5

Aluminum

150 ±25 HV

Ø65x15

QH3160200B

Vickers

HV 2.5

Steel

200 ±25 HV

Ø65x15

QH3160250B

Vickers

HV 2.5

Steel

250 ±25 HV

Ø65x15

QH3160300B

Vickers

HV 2.5

Steel

300 ±25 HV

Ø65x15

QH3160350B

Vickers

HV 2.5

Steel

350 ±25 HV

Ø65x15

QH3160400B

Vickers

HV 2.5

Steel

400 ±25 HV

Ø65x15

QH3160450B

Vickers

HV 2.5

Steel

450 ±25 HV

Ø65x15

QH3160500B

Vickers

HV 2.5

Steel

500 ±25 HV

Ø65x15

QH3160550B

Vickers

HV 2.5

Steel

550 ±25 HV

Ø65x15

QH3160600B

Vickers

HV 2.5

Steel

600 ±25 HV

Ø65x15

QH3160650B

Vickers

HV 2.5

Steel

650 ±25 HV

Ø65x15

QH3160700B

Vickers

HV 2.5

Steel

700 ±25 HV

Ø65x15

QH3160750B

Vickers

HV 2.5

Steel

750 ±25 HV

Ø65x15

QH3160800B

Vickers

HV 2.5

Steel

800 ±25 HV

Ø65x15

QH3160850B

Vickers

HV 2.5

Steel

850 ±25 HV

Ø65x15

QH3160900B

Vickers

HV 2.5

Steel

900 ±25 HV

Ø65x15

QH3160950B

Vickers

HV 2.5

Steel

950 ±25 HV

Ø65x15

QH3161000B

Vickers

HV 2.5

Steel

1000 ±25 HV

Ø65x15

QH3161050B

Vickers

HV 2.5

Steel

1050 ±25 HV

Ø65x15

HV 3

QH3170040B

Vickers

HV 3

Aluminum

40 ±25 HV

Ø65x15

QH3170070B

Vickers

HV 3

Aluminum

70 ±25 HV

Ø65x15

QH3170100B

Vickers

HV 3

Aluminum

100 ±25 HV

Ø65x15

QH3170150B

Vickers

HV 3

Aluminum

150 ±25 HV

Ø65x15

QH3170200B

Vickers

HV 3

Steel

200 ±25 HV

Ø65x15

QH3170250B

Vickers

HV 3

Steel

250 ±25 HV

Ø65x15

QH3170300B

Vickers

HV 3

Steel

300 ±25 HV

Ø65x15

QH3170350B

Vickers

HV 3

Steel

350 ±25 HV

Ø65x15

QH3170400B

Vickers

HV 3

Steel

400 ±25 HV

Ø65x15

QH3170450B

Vickers

HV 3

Steel

450 ±25 HV

Ø65x15

QH3170500B

Vickers

HV 3

Steel

500 ±25 HV

Ø65x15

QH3170550B

Vickers

HV 3

Steel

550 ±25 HV

Ø65x15

QH3170600B

Vickers

HV 3

Steel

600 ±25 HV

Ø65x15

QH3170650B

Vickers

HV 3

Steel

650 ±25 HV

Ø65x15

QH3170700B

Vickers

HV 3

Steel

700 ±25 HV

Ø65x15

QH3170750B

Vickers

HV 3

Steel

750 ±25 HV

Ø65x15

QH3170800B

Vickers

HV 3

Steel

800 ±25 HV

Ø65x15

QH3170850B

Vickers

HV 3

Steel

850 ±25 HV

Ø65x15

QH3170900B

Vickers

HV 3

Steel

900 ±25 HV

Ø65x15

QH3170950B

Vickers

HV 3

Steel

950 ±25 HV

Ø65x15

QH3171000B

Vickers

HV 3

Steel

1000 ±25 HV

Ø65x15

QH3171050B

Vickers

HV 3

Steel

1050 ±25 HV

Ø65x15

HV 5

QH3180040B

Vickers

HV 5

Aluminum

40 ±25 HV

Ø65x15

QH3180070B

Vickers

HV 5

Aluminum

70 ±25 HV

Ø65x15

QH3180100B

Vickers

HV 5

Aluminum

100 ±25 HV

Ø65x15

QH3180150B

Vickers

HV 5

Aluminum

150 ±25 HV

Ø65x15

QH3180200B

Vickers

HV 5

Steel

200 ±25 HV

Ø65x15

QH3180250B

Vickers

HV 5

Steel

250 ±25 HV

Ø65x15

QH3180300B

Vickers

HV 5

Steel

300 ±25 HV

Ø65x15

QH3180350B

Vickers

HV 5

Steel

350 ±25 HV

Ø65x15

QH3180400B

Vickers

HV 5

Steel

400 ±25 HV

Ø65x15

QH3180450B

Vickers

HV 5

Steel

450 ±25 HV

Ø65x15

QH3180500B

Vickers

HV 5

Steel

500 ±25 HV

Ø65x15

QH3180550B

Vickers

HV 5

Steel

550 ±25 HV

Ø65x15

QH3180600B

Vickers

HV 5

Steel

600 ±25 HV

Ø65x15

QH3180650B

Vickers

HV 5

Steel

650 ±25 HV

Ø65x15

QH3180700B

Vickers

HV 5

Steel

700 ±25 HV

Ø65x15

QH3180750B

Vickers

HV 5

Steel

750 ±25 HV

Ø65x15

QH3180800B

Vickers

HV 5

Steel

800 ±25 HV

Ø65x15

QH3180850B

Vickers

HV 5

Steel

850 ±25 HV

Ø65x15

QH3180900B

Vickers

HV 5

Steel

900 ±25 HV

Ø65x15

QH3180950B

Vickers

HV 5

Steel

950 ±25 HV

Ø65x15

QH3181000B

Vickers

HV 5

Steel

1000 ±25 HV

Ø65x15

QH3181050B

Vickers

HV 5

Steel

1050 ±25 HV

Ø65x15

HV 10

QH3190040B

Vickers

HV 10

Aluminum

40 ±25 HV

Ø65x15

QH3190070B

Vickers

HV 10

Aluminum

70 ±25 HV

Ø65x15

QH3190100B

Vickers

HV 10

Aluminum

100 ±25 HV

Ø65x15

QH3190150B

Vickers

HV 10

Aluminum

150 ±25 HV

Ø65x15

QH3190200B

Vickers

HV 10

Steel

200 ±25 HV

Ø65x15

QH3190250B

Vickers

HV 10

Steel

250 ±25 HV

Ø65x15

QH3190300B

Vickers

HV 10

Steel

300 ±25 HV

Ø65x15

QH3190350B

Vickers

HV 10

Steel

350 ±25 HV

Ø65x15

QH3190400B

Vickers

HV 10

Steel

400 ±25 HV

Ø65x15

QH3190450B

Vickers

HV 10

Steel

450 ±25 HV

Ø65x15

QH3190500B

Vickers

HV 10

Steel

500 ±25 HV

Ø65x15

QH3190550B

Vickers

HV 10

Steel

550 ±25 HV

Ø65x15

QH3190600B

Vickers

HV 10

Steel

600 ±25 HV

Ø65x15

QH3190650B

Vickers

HV 10

Steel

650 ±25 HV

Ø65x15

QH3190700B

Vickers

HV 10

Steel

700 ±25 HV

Ø65x15

QH3190750B

Vickers

HV 10

Steel

750 ±25 HV

Ø65x15

QH3190800B

Vickers

HV 10

Steel

800 ±25 HV

Ø65x15

QH3190850B

Vickers

HV 10

Steel

850 ±25 HV

Ø65x15

QH3190900B

Vickers

HV 10

Steel

900 ±25 HV

Ø65x15

QH3190950B

Vickers

HV 10

Steel

950 ±25 HV

Ø65x15

QH3191000B

Vickers

HV 10

Steel

1000 ±25 HV

Ø65x15

QH3191050B

Vickers

HV 10

Steel

1050 ±25 HV

Ø65x15

HV 10

QH3191180D

Vickers

HV 10

Carbide

1180 ±25 HV

25x25x6

QH3191300D

Vickers

HV 10

Carbide

1300 ±25 HV

25x25x6

QH3191350D

Vickers

HV 10

Carbide

1350 ±25 HV

25x25x6

QH3191420D

Vickers

HV 10

Carbide

1420 ±25 HV

25x25x6

QH3191500D

Vickers

HV 10

Carbide

1500 ±25 HV

25x25x6

QH3191550D

Vickers

HV 10

Carbide

1550 ±25 HV

25x25x6

QH3191600D

Vickers

HV 10

Carbide

1600 ±25 HV

25x25x6

QH3191640D

Vickers

HV 10

Carbide

1640 ±25 HV

25x25x6

QH3191700D

Vickers

HV 10

Carbide

1700 ±25 HV

25x25x6

QH3191740D

Vickers

HV 10

Carbide

1740 ±25 HV

25x25x6

QH3191820D

Vickers

HV 10

Carbide

1820 ±25 HV

25x25x6

HV 20

QH3200040B

Vickers

HV 20

Aluminum

40 ±25 HV

Ø65x15

QH3200070B

Vickers

HV 20

Aluminum

70 ±25 HV

Ø65x15

QH3200100B

Vickers

HV 20

Aluminum

100 ±25 HV

Ø65x15

QH3200150B

Vickers

HV 20

Aluminum

150 ±25 HV

Ø65x15

QH3200200B

Vickers

HV 20

Steel

200 ±25 HV

Ø65x15

QH3200250B

Vickers

HV 20

Steel

250 ±25 HV

Ø65x15

QH3200300B

Vickers

HV 20

Steel

300 ±25 HV

Ø65x15

QH3200350B

Vickers

HV 20

Steel

350 ±25 HV

Ø65x15

QH3200400B

Vickers

HV 20

Steel

400 ±25 HV

Ø65x15

QH3200450B

Vickers

HV 20

Steel

450 ±25 HV

Ø65x15

QH3200500B

Vickers

HV 20

Steel

500 ±25 HV

Ø65x15

QH3200550B

Vickers

HV 20

Steel

550 ±25 HV

Ø65x15

QH3200600B

Vickers

HV 20

Steel

600 ±25 HV

Ø65x15

QH3200650B

Vickers

HV 20

Steel

650 ±25 HV

Ø65x15

QH3200700B

Vickers

HV 20

Steel

700 ±25 HV

Ø65x15

QH3200750B

Vickers

HV 20

Steel

750 ±25 HV

Ø65x15

QH3200800B

Vickers

HV 20

Steel

800 ±25 HV

Ø65x15

QH3200850B

Vickers

HV 20

Steel

850 ±25 HV

Ø65x15

QH3200900B

Vickers

HV 20

Steel

900 ±25 HV

Ø65x15

QH3200950B

Vickers

HV 20

Steel

950 ±25 HV

Ø65x15

QH3201000B

Vickers

HV 20

Steel

1000 ±25 HV

Ø65x15

QH3201050B

Vickers

HV 20

Steel

1050 ±25 HV

Ø65x15

HV 30

QH3210040B

Vickers

HV 30

Aluminum

40 ±25 HV

Ø65x15

QH3210070B

Vickers

HV 30

Aluminum

70 ±25 HV

Ø65x15

QH3210100B

Vickers

HV 30

Aluminum

100 ±25 HV

Ø65x15

QH3210150B

Vickers

HV 30

Aluminum

150 ±25 HV

Ø65x15

QH3210200B

Vickers

HV 30

Steel

200 ±25 HV

Ø65x15

QH3210250B

Vickers

HV 30

Steel

250 ±25 HV

Ø65x15

QH3210300B

Vickers

HV 30

Steel

300 ±25 HV

Ø65x15

QH3210350B

Vickers

HV 30

Steel

350 ±25 HV

Ø65x15

QH3210400B

Vickers

HV 30

Steel

400 ±25 HV

Ø65x15

QH3210450B

Vickers

HV 30

Steel

450 ±25 HV

Ø65x15

QH3210500B

Vickers

HV 30

Steel

500 ±25 HV

Ø65x15

QH3210550B

Vickers

HV 30

Steel

550 ±25 HV

Ø65x15

QH3210600B

Vickers

HV 30

Steel

600 ±25 HV

Ø65x15

QH3210650B

Vickers

HV 30

Steel

650 ±25 HV

Ø65x15

QH3210700B

Vickers

HV 30

Steel

700 ±25 HV

Ø65x15

QH3210750B

Vickers

HV 30

Steel

750 ±25 HV

Ø65x15

QH3210800B

Vickers

HV 30

Steel

800 ±25 HV

Ø65x15

QH3210850B

Vickers

HV 30

Steel

850 ±25 HV

Ø65x15

QH3210900B

Vickers

HV 30

Steel

900 ±25 HV

Ø65x15

QH3210950B

Vickers

HV 30

Steel

950 ±25 HV

Ø65x15

QH3211000B

Vickers

HV 30

Steel

1000 ±25 HV

Ø65x15

QH3211050B

Vickers

HV 30

Steel

1050 ±25 HV

Ø65x15

QH3211180D

Vickers

HV 30

Carbide

1180 ±25 HV

25x25x6

QH3211300D

Vickers

HV 30

Carbide

1300 ±25 HV

25x25x6

QH3211350D

Vickers

HV 30

Carbide

1350 ±25 HV

25x25x6

QH3211420D

Vickers

HV 30

Carbide

1420 ±25 HV

25x25x6

QH3211500D

Vickers

HV 30

Carbide

1500 ±25 HV

25x25x6

QH3211550D

Vickers

HV 30

Carbide

1550 ±25 HV

25x25x6

QH3211600D

Vickers

HV 30

Carbide

1600 ±25 HV

25x25x6

QH3211640D

Vickers

HV 30

Carbide

1640 ±25 HV

25x25x6

QH3211700D

Vickers

HV 30

Carbide

1700 ±25 HV

25x25x6

QH3211740D

Vickers

HV 30

Carbide

1740 ±25 HV

25x25x6

QH3211820D

Vickers

HV 30

Carbide

1820 ±25 HV

25x25x6

HV 50

QH3220040B

Vickers

HV 50

Aluminum

40 ±25 HV

Ø65x15

QH3220070B

Vickers

HV 50

Aluminum

70 ±25 HV

Ø65x15

QH3220100B

Vickers

HV 50

Aluminum

100 ±25 HV

Ø65x15

QH3220150B

Vickers

HV 50

Aluminum

150 ±25 HV

Ø65x15

QH3220200B

Vickers

HV 50

Steel

200 ±25 HV

Ø65x15

QH3220250B

Vickers

HV 50

Steel

250 ±25 HV

Ø65x15

QH3220300B

Vickers

HV 50

Steel

300 ±25 HV

Ø65x15

QH3220350B

Vickers

HV 50

Steel

350 ±25 HV

Ø65x15

QH3220400B

Vickers

HV 50

Steel

400 ±25 HV

Ø65x15

QH3220450B

Vickers

HV 50

Steel

450 ±25 HV

Ø65x15

QH3220500B

Vickers

HV 50

Steel

500 ±25 HV

Ø65x15

QH3220550B

Vickers

HV 50

Steel

550 ±25 HV

Ø65x15

QH3220600B

Vickers

HV 50

Steel

600 ±25 HV

Ø65x15

QH3220650B

Vickers

HV 50

Steel

650 ±25 HV

Ø65x15

QH3220700B

Vickers

HV 50

Steel

700 ±25 HV

Ø65x15

QH3220750B

Vickers

HV 50

Steel

750 ±25 HV

Ø65x15

QH3220800B

Vickers

HV 50

Steel

800 ±25 HV

Ø65x15

QH3220850B

Vickers

HV 50

Steel

850 ±25 HV

Ø65x15

QH3220900B

Vickers

HV 50

Steel

900 ±25 HV

Ø65x15

QH3220950B

Vickers

HV 50

Steel

950 ±25 HV

Ø65x15

QH3221000B

Vickers

HV 50

Steel

1000 ±25 HV

Ø65x15

QH3221050B

Vickers

HV 50

Steel

1050 ±25 HV

Ø65x15

HV 100

QH3240040B

Vickers

HV 100

Aluminum

40 ±25 HV

Ø65x15

QH3240070B

Vickers

HV 100

Aluminum

70 ±25 HV

Ø65x15

QH3240100B

Vickers

HV 100

Aluminum

100 ±25 HV

Ø65x15

QH3240150B

Vickers

HV 100

Aluminum

150 ±25 HV

Ø65x15

QH3240200B

Vickers

HV 100

Steel

200 ±25 HV

Ø65x15

QH3240250B

Vickers

HV 100

Steel

250 ±25 HV

Ø65x15

QH3240300B

Vickers

HV 100

Steel

300 ±25 HV

Ø65x15

QH3240350B

Vickers

HV 100

Steel

350 ±25 HV

Ø65x15

QH3240400B

Vickers

HV 100

Steel

400 ±25 HV

Ø65x15

QH3240450B

Vickers

HV 100

Steel

450 ±25 HV

Ø65x15

QH3240500B

Vickers

HV 100

Steel

500 ±25 HV

Ø65x15

QH3240550B

Vickers

HV 100

Steel

550 ±25 HV

Ø65x15

QH3240600B

Vickers

HV 100

Steel

600 ±25 HV

Ø65x15

QH3240650B

Vickers

HV 100

Steel

650 ±25 HV

Ø65x15

QH3240700B

Vickers

HV 100

Steel

700 ±25 HV

Ø65x15

QH3240750B

Vickers

HV 100

Steel

750 ±25 HV

Ø65x15

QH3240800B

Vickers

HV 100

Steel

800 ±25 HV

Ø65x15

QH3240850B

Vickers

HV 100

Steel

850 ±25 HV

Ø65x15

QH3240900B

Vickers

HV 100

Steel

900 ±25 HV

Ø65x15

QH3240950B

Vickers

HV 100

Steel

950 ±25 HV

Ø65x15

QH3241000B

Vickers

HV 100

Steel

1000 ±25 HV

Ø65x15

QH3241050B

Vickers

HV 100

Steel

1050 ±25 HV

Ø65x15

Hardness test blocks Knoop
(EN ISO 4545-3, ASTM E92)

Material

Value

Dim. (mm)

HK 0.01

QH4040040A

Knoop

HK 0.01

Aluminum

40 ±25 HK

Ø30x10

QH4040070A

Knoop

HK 0.01

Aluminum

70 ±25 HK

Ø30x10

QH4040100A

Knoop

HK 0.01

Aluminum

100 ±25 HK

Ø30x10

QH4040150A

Knoop

HK 0.01

Aluminum

150 ±25 HK

Ø30x10

QH4040200A

Knoop

HK 0.01

Steel

200 ±25 HK

Ø30x10

QH4040250A

Knoop

HK 0.01

Steel

250 ±25 HK

Ø30x10

QH4040300A

Knoop

HK 0.01

Steel

300 ±25 HK

Ø30x10

QH4040350A

Knoop

HK 0.01

Steel

350 ±25 HK

Ø30x10

QH4040400A

Knoop

HK 0.01

Steel

400 ±25 HK

Ø30x10

QH4040450A

Knoop

HK 0.01

Steel

450 ±25 HK

Ø30x10

QH4040500A

Knoop

HK 0.01

Steel

500 ±25 HK

Ø30x10

QH4040550A

Knoop

HK 0.01

Steel

550 ±25 HK

Ø30x10

QH4040600A

Knoop

HK 0.01

Steel

600 ±25 HK

Ø30x10

QH4040650A

Knoop

HK 0.01

Steel

650 ±25 HK

Ø30x10

QH4040700A

Knoop

HK 0.01

Steel

700 ±25 HK

Ø30x10

QH4040750A

Knoop

HK 0.01

Steel

750 ±25 HK

Ø30x10

QH4040800A

Knoop

HK 0.01

Steel

800 ±25 HK

Ø30x10

QH4040850A

Knoop

HK 0.01

Steel

850 ±25 HK

Ø30x10

QH4040900A

Knoop

HK 0.01

Steel

900 ±25 HK

Ø30x10

QH4040950A

Knoop

HK 0.01

Steel

950 ±25 HK

Ø30x10

QH4041000A

Knoop

HK 0.01

Steel

1000 ±25 HK

Ø30x10

HK 0.025

QH4070040A

Knoop

HK 0.025

Aluminum

40 ±25 HK

Ø30x10

QH4070070A

Knoop

HK 0.025

Aluminum

70 ±25 HK

Ø30x10

QH4070100A

Knoop

HK 0.025

Aluminum

100 ±25 HK

Ø30x10

QH4070150A

Knoop

HK 0.025

Aluminum

150 ±25 HK

Ø30x10

QH4070200A

Knoop

HK 0.025

Steel

200 ±25 HK

Ø30x10

QH4070250A

Knoop

HK 0.025

Steel

250 ±25 HK

Ø30x10

QH4070300A

Knoop

HK 0.025

Steel

300 ±25 HK

Ø30x10

QH4070350A

Knoop

HK 0.025

Steel

350 ±25 HK

Ø30x10

QH4070400A

Knoop

HK 0.025

Steel

400 ±25 HK

Ø30x10

QH4070450A

Knoop

HK 0.025

Steel

450 ±25 HK

Ø30x10

QH4070500A

Knoop

HK 0.025

Steel

500 ±25 HK

Ø30x10

QH4070550A

Knoop

HK 0.025

Steel

550 ±25 HK

Ø30x10

QH4070600A

Knoop

HK 0.025

Steel

600 ±25 HK

Ø30x10

QH4070650A

Knoop

HK 0.025

Steel

650 ±25 HK

Ø30x10

QH4070700A

Knoop

HK 0.025

Steel

700 ±25 HK

Ø30x10

QH4070750A

Knoop

HK 0.025

Steel

750 ±25 HK

Ø30x10

QH4070800A

Knoop

HK 0.025

Steel

800 ±25 HK

Ø30x10

QH4070850A

Knoop

HK 0.025

Steel

850 ±25 HK

Ø30x10

QH4070900A

Knoop

HK 0.025

Steel

900 ±25 HK

Ø30x10

QH4070950A

Knoop

HK 0.025

Steel

950 ±25 HK

Ø30x10

QH4071000A

Knoop

HK 0.025

Steel

1000 ±25 HK

Ø30x10

HK 0.05

QH4080040A

Knoop

HK 0.05

Aluminum

40 ±25 HK

Ø30x10

QH4080070A

Knoop

HK 0.05

Aluminum

70 ±25 HK

Ø30x10

QH4080100A

Knoop

HK 0.05

Aluminum

100 ±25 HK

Ø30x10

QH4080150A

Knoop

HK 0.05

Aluminum

150 ±25 HK

Ø30x10

QH4080200A

Knoop

HK 0.05

Steel

200 ±25 HK

Ø30x10

QH4080250A

Knoop

HK 0.05

Steel

250 ±25 HK

Ø30x10

QH4080300A

Knoop

HK 0.05

Steel

300 ±25 HK

Ø30x10

QH4080350A

Knoop

HK 0.05

Steel

350 ±25 HK

Ø30x10

QH4080400A

Knoop

HK 0.05

Steel

400 ±25 HK

Ø30x10

QH4080450A

Knoop

HK 0.05

Steel

450 ±25 HK

Ø30x10

QH4080500A

Knoop

HK 0.05

Steel

500 ±25 HK

Ø30x10

QH4080550A

Knoop

HK 0.05

Steel

550 ±25 HK

Ø30x10

QH4080600A

Knoop

HK 0.05

Steel

600 ±25 HK

Ø30x10

QH4080650A

Knoop

HK 0.05

Steel

650 ±25 HK

Ø30x10

QH4080700A

Knoop

HK 0.05

Steel

700 ±25 HK

Ø30x10

QH4080750A

Knoop

HK 0.05

Steel

750 ±25 HK

Ø30x10

QH4080800A

Knoop

HK 0.05

Steel

800 ±25 HK

Ø30x10

QH4080850A

Knoop

HK 0.05

Steel

850 ±25 HK

Ø30x10

QH4080900A

Knoop

HK 0.05

Steel

900 ±25 HK

Ø30x10

QH4080950A

Knoop

HK 0.05

Steel

950 ±25 HK

Ø30x10

QH4081000A

Knoop

HK 0.05

Steel

1000 ±25 HK

Ø30x10

HK 0.1

QH4090040A

Knoop

HK 0.1

Aluminum

40 ±25 HK

Ø30x10

QH4090070A

Knoop

HK 0.1

Aluminum

70 ±25 HK

Ø30x10

QH4090100A

Knoop

HK 0.1

Aluminum

100 ±25 HK

Ø30x10

QH4090150A

Knoop

HK 0.1

Aluminum

150 ±25 HK

Ø30x10

QH4090200A

Knoop

HK 0.1

Steel

200 ±25 HK

Ø30x10

QH4090250A

Knoop

HK 0.1

Steel

250 ±25 HK

Ø30x10

QH4090300A

Knoop

HK 0.1

Steel

300 ±25 HK

Ø30x10

QH4090350A

Knoop

HK 0.1

Steel

350 ±25 HK

Ø30x10

QH4090400A

Knoop

HK 0.1

Steel

400 ±25 HK

Ø30x10

QH4090450A

Knoop

HK 0.1

Steel

450 ±25 HK

Ø30x10

QH4090500A

Knoop

HK 0.1

Steel

500 ±25 HK

Ø30x10

QH4090550A

Knoop

HK 0.1

Steel

550 ±25 HK

Ø30x10

QH4090600A

Knoop

HK 0.1

Steel

600 ±25 HK

Ø30x10

QH4090650A

Knoop

HK 0.1

Steel

650 ±25 HK

Ø30x10

QH4090700A

Knoop

HK 0.1

Steel

700 ±25 HK

Ø30x10

QH4090750A

Knoop

HK 0.1

Steel

750 ±25 HK

Ø30x10

QH4090800A

Knoop

HK 0.1

Steel

800 ±25 HK

Ø30x10

QH4090850A

Knoop

HK 0.1

Steel

850 ±25 HK

Ø30x10

QH4090900A

Knoop

HK 0.1

Steel

900 ±25 HK

Ø30x10

QH4090950A

Knoop

HK 0.1

Steel

950 ±25 HK

Ø30x10

QH4091000A

Knoop

HK 0.1

Steel

1000 ±25 HK

Ø30x10

HK 0.2

QH4100040A

Knoop

HK 0.2

Aluminum

40 ±25 HK

Ø30x10

QH4100070A

Knoop

HK 0.2

Aluminum

70 ±25 HK

Ø30x10

QH4100100A

Knoop

HK 0.2

Aluminum

100 ±25 HK

Ø30x10

QH4100150A

Knoop

HK 0.2

Aluminum

150 ±25 HK

Ø30x10

QH4100200A

Knoop

HK 0.2

Steel

200 ±25 HK

Ø30x10

QH4100250A

Knoop

HK 0.2

Steel

250 ±25 HK

Ø30x10

QH4100300A

Knoop

HK 0.2

Steel

300 ±25 HK

Ø30x10

QH4100350A

Knoop

HK 0.2

Steel

350 ±25 HK

Ø30x10

QH4100400A

Knoop

HK 0.2

Steel

400 ±25 HK

Ø30x10

QH4100450A

Knoop

HK 0.2

Steel

450 ±25 HK

Ø30x10

QH4100500A

Knoop

HK 0.2

Steel

500 ±25 HK

Ø30x10

QH4100550A

Knoop

HK 0.2

Steel

550 ±25 HK

Ø30x10

QH4100600A

Knoop

HK 0.2

Steel

600 ±25 HK

Ø30x10

QH4100650A

Knoop

HK 0.2

Steel

650 ±25 HK

Ø30x10

QH4100700A

Knoop

HK 0.2

Steel

700 ±25 HK

Ø30x10

QH4100750A

Knoop

HK 0.2

Steel

750 ±25 HK

Ø30x10

QH4100800A

Knoop

HK 0.2

Steel

800 ±25 HK

Ø30x10

QH4100850A

Knoop

HK 0.2

Steel

850 ±25 HK

Ø30x10

QH4100900A

Knoop

HK 0.2

Steel

900 ±25 HK

Ø30x10

QH4100950A

Knoop

HK 0.2

Steel

950 ±25 HK

Ø30x10

QH4101000A

Knoop

HK 0.2

Steel

1000 ±25 HK

Ø30x10

HK 0.3

QH4110040A

Knoop

HK 0.3

Aluminum

40 ±25 HK

Ø30x10

QH4110070A

Knoop

HK 0.3

Aluminum

70 ±25 HK

Ø30x10

QH4110100A

Knoop

HK 0.3

Aluminum

100 ±25 HK

Ø30x10

QH4110150A

Knoop

HK 0.3

Aluminum

150 ±25 HK

Ø30x10

QH4110200A

Knoop

HK 0.3

Steel

200 ±25 HK

Ø30x10

QH4110250A

Knoop

HK 0.3

Steel

250 ±25 HK

Ø30x10

QH4110300A

Knoop

HK 0.3

Steel

300 ±25 HK

Ø30x10

QH4110350A

Knoop

HK 0.3

Steel

350 ±25 HK

Ø30x10

QH4110400A

Knoop

HK 0.3

Steel

400 ±25 HK

Ø30x10

QH4110450A

Knoop

HK 0.3

Steel

450 ±25 HK

Ø30x10

QH4110500A

Knoop

HK 0.3

Steel

500 ±25 HK

Ø30x10

QH4110550A

Knoop

HK 0.3

Steel

550 ±25 HK

Ø30x10

QH4110600A

Knoop

HK 0.3

Steel

600 ±25 HK

Ø30x10

QH4110650A

Knoop

HK 0.3

Steel

650 ±25 HK

Ø30x10

QH4110700A

Knoop

HK 0.3

Steel

700 ±25 HK

Ø30x10

QH4110750A

Knoop

HK 0.3

Steel

750 ±25 HK

Ø30x10

QH4110800A

Knoop

HK 0.3

Steel

800 ±25 HK

Ø30x10

QH4110850A

Knoop

HK 0.3

Steel

850 ±25 HK

Ø30x10

QH4110900A

Knoop

HK 0.3

Steel

900 ±25 HK

Ø30x10

QH4110950A

Knoop

HK 0.3

Steel

950 ±25 HK

Ø30x10

QH4111000A

Knoop

HK 0.3

Steel

1000 ±25 HK

Ø30x10

HK 0.5

QH4120040A

Knoop

HK 0.5

Aluminum

40 ±25 HK

Ø30x10

QH4120070A

Knoop

HK 0.5

Aluminum

70 ±25 HK

Ø30x10

QH4120100A

Knoop

HK 0.5

Aluminum

100 ±25 HK

Ø30x10

QH4120150A

Knoop

HK 0.5

Aluminum

150 ±25 HK

Ø30x10

QH4120200A

Knoop

HK 0.5

Steel

200 ±25 HK

Ø30x10

QH4120250A

Knoop

HK 0.5

Steel

250 ±25 HK

Ø30x10

QH4120300A

Knoop

HK 0.5

Steel

300 ±25 HK

Ø30x10

QH4120350A

Knoop

HK 0.5

Steel

350 ±25 HK

Ø30x10

QH4120400A

Knoop

HK 0.5

Steel

400 ±25 HK

Ø30x10

QH4120450A

Knoop

HK 0.5

Steel

450 ±25 HK

Ø30x10

QH4120500A

Knoop

HK 0.5

Steel

500 ±25 HK

Ø30x10

QH4120550A

Knoop

HK 0.5

Steel

550 ±25 HK

Ø30x10

QH4120600A

Knoop

HK 0.5

Steel

600 ±25 HK

Ø30x10

QH4120650A

Knoop

HK 0.5

Steel

650 ±25 HK

Ø30x10

QH4120700A

Knoop

HK 0.5

Steel

700 ±25 HK

Ø30x10

QH4120750A

Knoop

HK 0.5

Steel

750 ±25 HK

Ø30x10

QH4120800A

Knoop

HK 0.5

Steel

800 ±25 HK

Ø30x10

QH4120850A

Knoop

HK 0.5

Steel

850 ±25 HK

Ø30x10

QH4120900A

Knoop

HK 0.5

Steel

900 ±25 HK

Ø30x10

QH4120950A

Knoop

HK 0.5

Steel

950 ±25 HK

Ø30x10

QH4121000A

Knoop

HK 0.5

Steel

1000 ±25 HK

Ø30x10

HK 1

QH4130040A

Knoop

HK 1

Aluminum

40 ±25 HK

Ø30x10

QH4130070A

Knoop

HK 1

Aluminum

70 ±25 HK

Ø30x10

QH4130100A

Knoop

HK 1

Aluminum

100 ±25 HK

Ø30x10

QH4130150A

Knoop

HK 1

Aluminum

150 ±25 HK

Ø30x10

QH4130200A

Knoop

HK 1

Steel

200 ±25 HK

Ø30x10

QH4130250A

Knoop

HK 1

Steel

250 ±25 HK

Ø30x10

QH4130300A

Knoop

HK 1

Steel

300 ±25 HK

Ø30x10

QH4130350A

Knoop

HK 1

Steel

350 ±25 HK

Ø30x10

QH4130400A

Knoop

HK 1

Steel

400 ±25 HK

Ø30x10

QH4130450A

Knoop

HK 1

Steel

450 ±25 HK

Ø30x10

QH4130500A

Knoop

HK 1

Steel

500 ±25 HK

Ø30x10

QH4130550A

Knoop

HK 1

Steel

550 ±25 HK

Ø30x10

QH4130600A

Knoop

HK 1

Steel

600 ±25 HK

Ø30x10

QH4130650A

Knoop

HK 1

Steel

650 ±25 HK

Ø30x10

QH4130700A

Knoop

HK 1

Steel

700 ±25 HK

Ø30x10

QH4130750A

Knoop

HK 1

Steel

750 ±25 HK

Ø30x10

QH4130800A

Knoop

HK 1

Steel

800 ±25 HK

Ø30x10

QH4130850A

Knoop

HK 1

Steel

850 ±25 HK

Ø30x10

QH4130900A

Knoop

HK 1

Steel

900 ±25 HK

Ø30x10

QH4130950A

Knoop

HK 1

Steel

950 ±25 HK

Ø30x10

QH4131000A

Knoop

HK 1

Steel

1000 ±25 HK

Ø30x10

HK 2

QH4140040A

Knoop

HK 2

Aluminum

40 ±25 HK

Ø30x10

QH4140070A

Knoop

HK 2

Aluminum

70 ±25 HK

Ø30x10

QH4140100A

Knoop

HK 2

Aluminum

100 ±25 HK

Ø30x10

QH4140150A

Knoop

HK 2

Aluminum

150 ±25 HK

Ø30x10

QH4140200A

Knoop

HK 2

Steel

200 ±25 HK

Ø30x10

QH4140250A

Knoop

HK 2

Steel

250 ±25 HK

Ø30x10

QH4140300A

Knoop

HK 2

Steel

300 ±25 HK

Ø30x10

QH4140350A

Knoop

HK 2

Steel

350 ±25 HK

Ø30x10

QH4140400A

Knoop

HK 2

Steel

400 ±25 HK

Ø30x10

QH4140450A

Knoop

HK 2

Steel

450 ±25 HK

Ø30x10

QH4140500A

Knoop

HK 2

Steel

500 ±25 HK

Ø30x10

QH4140550A

Knoop

HK 2

Steel

550 ±25 HK

Ø30x10

QH4140600A

Knoop

HK 2

Steel

600 ±25 HK

Ø30x10

QH4140650A

Knoop

HK 2

Steel

650 ±25 HK

Ø30x10

QH4140700A

Knoop

HK 2

Steel

700 ±25 HK

Ø30x10

QH4140750A

Knoop

HK 2

Steel

750 ±25 HK

Ø30x10

QH4140800A

Knoop

HK 2

Steel

800 ±25 HK

Ø30x10

QH4140850A

Knoop

HK 2

Steel

850 ±25 HK

Ø30x10

QH4140900A

Knoop

HK 2

Steel

900 ±25 HK

Ø30x10

QH4140950A

Knoop

HK 2

Steel

950 ±25 HK

Ø30x10

QH4141000A

Knoop

HK 2

Steel

1000 ±25 HK

Ø30x10

Test diamonds MaCro

• with DAkkS/ASTM Certificate

Length

QER28000EA

Test diamond Rockwell

28 mm

6.5 mm

QER28400EA

Test diamond Rockwell

28 mm

3.8 mm

QEV28000EA

Test diamond Vickers

≥HV0.01

28 mm

6.5 mm

QEV28000EZ

Test diamond Vickers

≥HV5

28 mm

6.5 mm only with DAkkS Certificate

QEK28000EA

Test diamond Knoop

28 mm

6.5 mm

Ball holders with pressed-in ball – MaCro

• with DAkkS/ASTM Certificate

QEB28010EA Ball holder with 1 mm ball, pressed-in

QEB28025EA Ball holder with 2.5 mm ball, pressed-in

QEB28050EA Ball holder with 5 mm ball, pressed-in

QEB28100EA Ball holder with 10 mm ball, pressed-in

QEB28116EA Ball holder with 1/16" ball, pressed-in

QEB28108EA Ball holder with 1/8" ball, pressed-in

QEB28104EA Ball holder with 1/4" ball, pressed-in

QEB28102EA Ball holder with 1/2" ball, pressed-in

Ball holders with exchangeable ball – MaCro

• with DAkkS/ASTM Certificate

QEB28025AA Ball holder with 2.5 mm ball - exchangeable

QEB28050AA Ball holder with 5 mm ball - exchangeable

QEB28100AA Ball holder with 10 mm ball - exchangeable

QEB28108AA Ball holder with 1/8" ball - exchangeable

QEB28104AA Ball holder with 1/4" ball - exchangeable

QEB28102AA Ball holder with 1/2" ball - exchangeable

Carbide balls for ball holders with exchangeable ball – MaCro

• with DAkkS/ASTM Certificate

QKG010025A Carbide balls 2.5 mm

QKG010050A Carbide balls 5 mm

QKG010100A Carbide balls 10 mm

QKG011108A Carbide balls 1/8"

QKG011104A Carbide balls 1/4"

QKG011102A Carbide balls 1/2"

Test diamonds MiCro

• with DAkkS/ASTM Certificate

QEV05000EA Test diamond Vickers

QEK05000EA Test diamond Knoop

QER05000EA Test diamond Rockwell

QEB05010EA Ball holder with 1 mm ball, pressed-in

QEB05025EA Ball holder with 2.5 mm ball, pressed-in

QEB05050EA Ball holder with 5 mm ball, pressed-in

QEB05116EA Ball holder with 1/16" ball, pressed-in

Poster of hardness comparison table

95016705 Poster of hardness comparison table

Consumables Overview

With the list below, you may request a free, non-binding quote.

We're here to assist you!

Silicon carbide precision cut-off wheels

• for non-ferrous metals

Reduction ring

Aluminum oxide precision cut-off wheels

Fine-grained• for universal application of materials of higher hardness• precise cuts and high surface quality• optimal for delicate samples and sensitive materials

Coarse-grained• for universal use with lower hardness materials• ideal for rough geometries and mounted sample material• fast and efficient cuts

Diamond precision cut-off wheelsBond: Bronze

• for universal application and carbides

• for glass, minerals, rock as well as brittle and hard ceramic materials

• for hard metals and hard ceramic materials

• for assembled printed circuit boards and filigree component geometries

• for mounted samples, composites, CFRP, GFRP and plastics

CBN precision cut-off wheelsBond: Bronze

• for composites and rigid materials

Saw blade precision cut-off wheel

• for plastics, non-ferrous metals

Silicon carbide cut-off wheelsBond: Resin

Type NF-A, Purple• for non-ferrous metals (30-300HV)

Type Ti-A, Pink • for titanium and alloys, refractory metals (30-300 HV)

Aluminum oxide cut-off wheelsBond: Resin

Type FS-A, Red• for soft steel (30-300HV), non-ferrous metals, polymer (e.g., PMMA, PEEK, PTFE) due to hard bonding

Type I • ideal for cutting structural steel (e.g., S235JR, S355J2, C45) and cast materials (e.g., ductile iron, gray cast iron, cast steel) (60-350 HV)

Type FS-B, Orange • for medium soft steel (200-450HV) e.g. unalloyed structural steels and low-alloy steels

Type FS-C, Yellow• for medium hard steel (300-550HV), case hardened, nitrided steels

Type D• universally applicable for medium material hardness and case-hardened steels (350-600 HV), e.g., tempered steel 42CrMo4, CuSn8

Type FS-D, Green • for hard steels (400-700HV), annealed, carburised steels

Type C• universally applicable for materials of high and very high hardness (>600 HV), e.g., martensitic stainless steels, WC-Co, carbide

Type FS-E, Blue • for very hard steels (>650 HV), e.g., CrV, manganese steel

Type A, Brown• universal wheel, soft and hard metals, superalloys (50-500 HV)

Type B, Black • for high-speed steels, heat-treated steels, non-corrosive steels (400-700 HV)

Fabric reinforced premium aluminum oxide cut-off wheelsBond: Resin

Type FS-FR, fabric reinforced• for medium soft to hard steels (250-600 HV)• > 30% wear reduction• ideal for manual cutting

Premium diamond cut-off wheelsBond: Bronze

• for ceramic materials

• for composite materials (hard/soft combinations)

Premium diamond cut-off wheelsBond: Resin

• for hard metals, for materials with high hardness (>700 HV)

Premium CBN cut-off wheelsBond: Bronze

• for Nickel and Cobald based alloys

ATM-CoolCut, environment- and user-friendly

Anti corrosion coolant for polymers and composites

Anti corrosion coolant, standard

Cooling agent additives

ATM-CoolAdd CU

Defoaming agent

ATM-PreClean

Accessories for maintenance and care of coolants

Maintenance and testing set

Accessories for maintenance and testing set

Accessories for maintenance and care of cut-off machines

Corrosion protection- and care spray

Anti-fog spray

Accessories for cut-off wheels

Dressing stone

Filter inserts for recirculation cooling system for floor-standing cut-off machines, 140 Ltr.

for Brillant 255 / Qcut 400 A (Brillant 265) / Brillant 270 / Qcut 500 A (Brillant 275) / Brillant 280

for recirculation cooling system for benchtop cut-off machines, 45 Ltr. (until year of construction 2012)

for recirculation cooling system for benchtop cut-off machines, 45 Ltr. (from year of construction 2013)

Filter Basket

hanging basket made of stainless steel for the collection of the chip abrasion• can be hooked into 45 liter recirculating cooling unit

Filter fleece for belt filter systems

for belt filter system BFA 285

for belt filter system BFA 100/130

for Qcut 600 A (Brillant 285)

for recirculation cooling system 15 Ltr.

Mounting Consumables

Hot mounting material

Hot mounting material EPO black

Hot mounting material EPO-Max

Hot mounting material Duroplast black

Hot mounting material Thermoplast

Hot mounting material Bakelit black

Hot mounting material Bakelit green

Hot mounting material Bakelit Red

Hot mounting accessories

Clip for aligning thin samples in mould

Accessories for Hot Mounting presses

Fine-grained
• for universal application of materials of higher hardness
• precise cuts and high surface quality
• optimal for delicate samples and sensitive materials

Coarse-grained
• for universal use with lower hardness materials
• ideal for rough geometries and mounted sample material
• fast and efficient cuts

Diamond precision cut-off wheels
Bond: Bronze

CBN precision cut-off wheels
Bond: Bronze

Silicon carbide cut-off wheels
Bond: Resin

Type NF-A, Purple
• for non-ferrous metals (30-300HV)

Type Ti-A, Pink
• for titanium and alloys, refractory metals (30-300 HV)

Aluminum oxide cut-off wheels
Bond: Resin

Type FS-A, Red
• for soft steel (30-300HV), non-ferrous metals, polymer (e.g., PMMA, PEEK, PTFE) due to hard bonding

Type I
• ideal for cutting structural steel (e.g., S235JR, S355J2, C45) and cast materials (e.g., ductile iron, gray cast iron, cast steel) (60-350 HV)

Type FS-B, Orange
• for medium soft steel (200-450HV) e.g. unalloyed structural steels and low-alloy steels

Type FS-C, Yellow
• for medium hard steel (300-550HV), case hardened, nitrided steels

Type D
• universally applicable for medium material hardness and case-hardened steels (350-600 HV), e.g., tempered steel 42CrMo4, CuSn8

Type FS-D, Green
• for hard steels (400-700HV), annealed, carburised steels

Type C
• universally applicable for materials of high and very high hardness (>600 HV), e.g., martensitic stainless steels, WC-Co, carbide

Type FS-E, Blue
• for very hard steels (>650 HV), e.g., CrV, manganese steel

Type A, Brown
• universal wheel, soft and hard metals, superalloys (50-500 HV)

Type B, Black
• for high-speed steels, heat-treated steels, non-corrosive steels (400-700 HV)

Fabric reinforced premium aluminum oxide cut-off wheels
Bond: Resin

Type FS-FR, fabric reinforced
• for medium soft to hard steels (250-600 HV)
• > 30% wear reduction
• ideal for manual cutting

Premium diamond cut-off wheels
Bond: Bronze

Premium diamond cut-off wheels
Bond: Resin

Premium CBN cut-off wheels
Bond: Bronze

for recirculation cooling system for benchtop cut-off machines, 45 Ltr.
(until year of construction 2012)

for recirculation cooling system for benchtop cut-off machines, 45 Ltr.
(from year of construction 2013)

hanging basket made of stainless steel for the collection of the chip abrasion
• can be hooked into 45 liter recirculating cooling unit

• blue, opaque
• 2-component system: powder + liquid (1.5:1 [Vol.-%])

• feasibility of transparent embeddings by means of pressure unit
• 2-component system: powder + liquid (2:1 [Vol.-%])

• green, semi-transparent
• 2-component system: powder + liquid (2:1 [Vol.-%])

• light green, opaque
• 2-component system: powder + liquid (1.5:1 [Vol.-%])

• copper-brown, free of blowholes by using a pressure device
• 2-component system: powder + liquid (20 g : 13 g)

• red, MMA-free
• 2-component system: powder + liquid (2:0.9 [weight-%])

• transparent, suitable for vacuum infiltration
• 2-components-system: resin + hardener (2:1 [weight-%])

• transparent, suitable for vacuum infiltration
• 2-components-system: resin + hardener (100:23.2 [weight-%])

• transparent, suitable for vacuum infiltration
•2-components-system: resin + hardener (100:26 [weight-%])

• transparent, suitable for vacuum infiltration
• 2-components-system: resin + hardener (2:1 [weight-%])

• transparent, suitable for vacuum infiltration
• 2-components-system: resin + hardener for 40 mm = 100/50, for ≤ 30 mm 100/56 [weight-%]

• for cold mounting, pouring and hardening using vacuum
• recommended for Qpox epoxy resins

• transparent
• 1-component system

• transparent
• 1-component system

• suitable for light curing
• with exchangeable bottom

• suitable for light curing
• with exchangeable bottom

• not suitable for light curing
• with exchangeable bottom

• not suitable for light curing
• with exchangeable bottom

• suitable for light curing
• with exchangeable bottom

• not suitable for light curing
• with exchangeable bottom

• not suitable for light curing
• with exchangeable bottom
