The Qscratch 20 is a fully automatic macro/micro scratch tester for quality control of coatings, functional surfaces, and critical loads. The system combines controlled force application, precise electronic load control, integrated optical evaluation, and guided operation in QpixControl2. This enables reproducible scratch testing with progressive or constant load, including structured evaluation, documentation, and reporting.
With motorized X/Y/Z axes, single and multiple measurements, and an 8-position automatic tool changer, the Qscratch 20 is designed for laboratories that need reliable surface-related decisions every day. It supports scratch tests according to standards such as DIN EN ISO 20502, ASTM C1624, ISO 27307, and ASTM G171. Optional Vickers hardness testing and Qpix Inspect analysis modules make the system a flexible platform for coating evaluation, surface testing, and quality assurance.
Micro / Macro Scratch tester Qscratch 20 Product Advantages
- Fully automatic macro/micro scratch tester for coatings and surfaces
- Single and multiple measurements for efficient test series
- Electronic force control with a test force range of 0.5–200 N
- Constant and progressive load for standards compliant scratch testing
- 8-position automatic tool changer for test modules and lenses
- Motorized X/Y/Z axes with precise positioning
- QpixControl2 software with guided scratch workflow
- Optional hardness upgrade and Qpix Inspect analysis functions
Micro / Macro Scratch tester Qscratch 20 Experience the 3D model in the real world!
Micro / Macro Scratch tester Qscratch 20 Test Methods & Force Range
Method Progressive load
The initial and final loads, as well as the load rate, are defined. The load increases along the scratch length; visible events can be assigned as Lc points at their respective positions.
ISO: PFST - progressive force scratch test
ASTM: PL - progressive load
Lc: Load critical
Method Constant load
The normal force remains constant over the scratch length. This method is suitable for individual measurements, series compa-risons, and recurring test conditions in a quality control setting.
ISO: CFST - constant force scratch test
ASTM: CL - constant load
Lc: Load critical
Test methods Progressive or constant load - tailored to the test requirements
Standards & Procedures
DIN EN ISO 20502 / ASTM C1624 - Determination of adhesion and mechanical failure modes of hard ceramic coatings using a scratch test.
ISO 27307 - Evaluation of the adhesion and cohesion of thermally sprayed ceramic layers on a cross-section using a transverse scratch test.
ASTM G171 - Determination of the scratch hardness of material surfaces using a defined diamond stylus, a constant normal force, and evaluation of the remaining scratch width.
For laboratories that make critical decision every day
Qscratch 20 is a automated macro/micro scratch tester for coatings and functional surfaces. The system combines controlled force application, integrated optical evaluation, and guided software operation and a report generation. It was developed specifically for laboratories that make critical surface-related decisions on a daily basis.
Practical quality assurance & integrated workflows
Designed for quality assurance: The system combines standardized scratch tests with high repeatability, efficient documentation, and intuitive operation. QpixControl2, the integrated workflow, flexible export options, and optional inspection functions turn it into a powerful, all-in-one solution rather than a simple stand-alone tester.
Long-term investment security through QATM expertise
QATM brings many years of experience in hardness testing, metallography, and global service to its scratch testing portfolio, thereby safeguarding your investment in the long term.
Test principle DIN EN ISO 20502 | ASTM C1624 A defined scratch. A controlled load. A clear evaluation.
The principle
In the scratch test, a diamond stylus is moved across the coated surface under a defined normal force. Visible events such as cracking, spalling, or penetration of the coating are localized along the scratch mark and assigned to the corresponding critical load. Thus, the scratch mark not only indicates that a failure is occurring; it also shows where it is occurring—and makes the load at the critical point traceable.
Defining and assigning failure events
Lc1 - Initial cracking / plastic deformation
Lc2 - Spalling
Lc3 - Penetration of the coating down to the substrate
From scratch track to traceable result Ceramic coatings. Evaluation of adhesion and failure modes.
The following interactive section shows how typical failure events along the scratch track are analyzed. Click on the LC points to see how cracking, spalling, and coating penetration are associated with specific positions and loads.
Select a material and explore the Lc points
Thin, hard ceramic coatings (typically 0.1 - 30 μm)
- Carbide, TiC, CrC
- Nitride TiN, CrN, TiAlN
- Oxide Al₂O₃
- Diamond Diamond coating
- Diamond-like carbon DLC
Thin, hard ceramic and technical coatings (typically ≤ 20 μm)
- PVD TiN
- PACVD DLC
- Arc-discharge DLC
- PVD/PACVD Cr-C
- PVD Al203
- Hard chrome
Micro / Macro Scratch tester Qscratch 20 Revolutionary optic system
The QATM-developed, in-house manufactured lens system sets new standards. As well as providing crystal clear image quality for hardness testing, Koehler illumination uses white LED light and motor-operated aperture shuttering to produce ideal contrast, even for high magnification images.
Experienced metallurgists agree the image quality provided by the Qscratch is comparable in all aspects with that of established sophisticated microscopes. The up-to-date concept and new lenses in the optic system enable the device to completely meet even the strictest physical ‘test system definition’ requirements in compliance with DIN EN ISO6507-1/2:2018.
Micro / Macro Scratch tester Qscratch 20 Innovative Operation
8-position automatic tool changer
The motorized tool changer can accommodate up to three scratch test modules and up to seven lenses. This allows for overview, detailed inspection, and Lc determination to be performed directly within the scratch test sequence—on a single axis and without offset.
Vertical concept with 2 Z-axes
There are decisive benefits in distributing vertical movement across 2 axes. Via the first Z-axis there is dynamic motion control, allowing the indenter to be positioned towards the test surface quickly and conveniently at up to 30mm/s. The additional second Z-axis in the QATM system offers a high-resolution positioning system for greater precision in force application and focusing.
Test space lightning
CAS Technology
Innovative Collision Avoiding System (CAS) technology protects the mechanical parts in the device using predictive 3D motion calculations to visualize the effects of collisions and operation errors.
Digital caliper
The digital caliper is compatible with the Qpix Control2 system and reads the dimensions, height and diameter of components wirelessly and at the push of a button, entering them into the software. The test head height control in the A+ hardness tester enables the test height to be reached completely automatically with no need for manual input.
Illuminated status display Brings light into the dark
The illuminated QATM logo displays the current device status at a glance. The range of flash intervals indicates whether the device is operating automatically or is free to be used for new tasks for staff all around the lab. In addition, the LED test space lighting, installed as standard, ensures that samples and sample holders are positioned correctly.
On the Qscratch 20, it also ensures uniform light intensity for sample imaging.
Micro / Macro Scratch tester Qscratch 20 Pioneering technology - Unique implementation
Evaluable and comparable
The selected loading logic is linked to the scratch mark, position, and result. Methods can be applied to sample series, coating variants, and process comparisons.
Checking the diamond stylus
The diamond tip can be visually inspected directly within the system. This allows the condition of the diamond stylus to be checked before or after the test - an important step for ensuring reproducible results and traceable test conditions.
Universal sample holder
Adjustable clamping jaws allow for the secure holding of various specimen geometries - from flat and angular test pieces to round or very small specimens.
High-resolution sample image (HRI)
If high-quality images of larger areas are required (e.g. for weld seam measurements), the area can be scanned using the HRI function. The Qpix Control 2 software automatically combines the individual images into one large overall image.
Sample image camera
It’s no coincidence that most QATM customers choose the ‘A+’ version with a built-in sample image camera. In a few seconds the image of the sample is shot with the additional camera (field of view 52 x 39 mm). The image provides excellent navigational support within the software, particularly in combination with DOUBLE-VIEW TECHNOLOGY, and aids enhanced documentation in the automatically compiled test report.
Precise distance / Force application
Precise electronic load control ensures that the test load—as a critical test parameter—remains controlled, reproducible, and traceable at all times.
Scratch workflow Easy testing, efficient analysis
QpixControl2 is more than just a user interface: The software combines a patented 3D user concept with a seamless scratch workflow. Tests can be easily created, scratch marks visually positioned, single or multiple measurements processed automatically, and relevant Lc events evaluated in a structured manner. From test definition through image capture and evaluation to data management, export, and standardized reporting, all steps remain integrated within an intuitive software environment. This reduces operational effort, supports reproducible processes, and enables the efficient use of scratch testing in production-oriented quality assurance.
From setup to report 3 Steps to the result
1. Load sample
The sample holder is automatically moved to the correct height, and the sample image is automatically captured.
2. Positioning
Drag and drop the starting point of the scratch test directly to the desired position.
3. Start Test Sequence
The test sequence is fully automatically and in accordance with the Scratch test standards. Subsequently, the failure events can be evaluated and assigned to the respective Lc points.
Software Included features
Software Options
Microscopy & Analysis
Qpix Control2 Innovative software functions
Single and multiple inspections
Single or multiple measurements: Scratch marks can be positioned directly in the software, created with a defined offset, and processed automatically. The Lc results are evaluated for each test as well as as a series mean.
A wide range of setting options
Load definition, crack length, load rate, speed, and lens selection are managed directly within the method. For evaluation, standardbased templates or custom templates can be used and supplemented with limit and target values.
Guided Lc determination
Graphical templates support the consistent classification of typical failure events. This facilitates standard-based procedures and reduces room for interpretation.
Force/Distance graph
The force-distance curve documents the applied load along the scratch track. Anomalies in the curve can be compared with visible failure events and used for Lc evaluation
Lc details
Relevant failure events along the scratch track can be viewed in detail in the image and assigned to the corresponding Lc details. This transforms the visual assessment into a verifiable test result
Report
Test parameters, scratch track, Lc values and evaluation results are compiled into a test report. This simplifies documentation, the comparison of test series, and the dissemination of results within the quality process.
One platform More than just scratch testing
QSCRATCH 20 / QNESS 60 A+ EVO
Qscratch 20 is part of a modular QATM platform. In addition to scratch testing, hardness testing methods, analysis functions, and other coating tests can be optionally integrated. This reduces the need to switch systems, consolidates results in a familiar software environment, and ensures long-term investment security.
Hardness testing
Optional hardness upgrade for Vickers, Knoop, Brinell, and Rockwell - integrated into the QpixControl2 software environment.
Analysis
Optional analysis functions for coating thickness, phases, grain size, and weld seams - for more information from a single system.
Scratch testing
Controlled scratch testing with progressive or constant load - for evaluating coatings, surfaces, and critical loads.
Hardness testing
DIN EN ISO 6507, ASTM E-92, ASTM E-384
| HV 0.00025* | HV 0.0005* | HV 0.001 | HV 0.002 | HV 0.003 | HV 0.005 | HV 0.01 | HV 0.02 | HV 0.025* | HV 0.05 | HV 0.1 | HV 0.2 |
| HV 0.3 | HV 0.5 | HV 1 | HV 2 | HV 2,5 | HV 3 | HV 5 | HV 10 | HV 20 | HV 30 | HV 50 | HV 60* |
DIN EN ISO 4545, ASTM E-92, ASTM E-384
| HK 0.001 | HK 0.002 | HK 0.005 | HK 0.01 | HK 0.015 | HK 0.02 | HK 0.025 |
| HK 0.1 | HK 0.2 | HK 0.3 | HK 0.5 | HK 1 | HK 2 |
DIN EN ISO 6506, ASTM E-10
| HBW 1/1 | HBW 1/2.5 | HBW 1/5 | HBW 1/10 | HBW 1/30 |
| HBW 2.5/6.5 | HBW 2.5/31.25 | HBW 5/62.5 | HBW 5/25 | HBW 5/62.5 |
Integrated conversions: DIN EN ISO 18265, DIN EN ISO 50150, ASTM E140
* not according to standards
Coating inspection made easy Qpix inspect for crater-grinding and rockwell adhesion testing
The optional Qpix Inspect modules expand the Qscratch 20 with practical functions for coating evaluation. Crater-grinding supports microscopic coating thickness measurement in accordance with DIN EN ISO 26423, while the Rockwell adhesion test enables qualitative adhesion evaluation of ceramic coatings in accordance with DIN EN ISO 26443. This allows additional information on coating quality to be captured, evaluated, and documented directly within the familiar QpixControl2 software environment.
Crater-grinding coating thickness measurement
Crater-grinding method for microscopic coating thickness determination as supplementary information for coating evaluation in accordance with DIN EN ISO 26423.
Rockwell indentation test
Rockwell indentation test for qualitative adhesion evaluation of ceramic coatings in accordance with DIN EN ISO 26443.
Structural analysis made easy Qpix Inspect for microscopic evaluations
The intuitive and user-friendly Qpix INSPECT software functionality provides a comprehensive toolbox for microscopic evaluations and result documentation. The multifunctional software can be customized for customer-specific measuring tasks and complemented with add-on modules.
Inspect phase analysis
- Automatic image object dimensioning
- Evaluation of phase fractions according to DIN 9042, ASTM E-562 and ASTM E-1245
- Provides analytics results as percentage proportions of a surface or as nominal surface values as tables or diagrams
Inspect
layer thickness measurement
- Determination of layer thickness according to DIN EN ISO 1463
- Semi-automated gauging of horizontal, vertical and radial layers
- Provision of layer thickness as statistical values for lengths as tables or diagrams
Inspect
particle size determination
- Particle size determined according to DIN EN ISO 643 and ASTM E-112 via linear or circular section method
- Results of the analysis provided as tables or diagrams
- Documentation of statistical characteristics of particle size and segment lengths cutting through the particles
Inspect
weld seam measurement
- Standardised measurement and evaluation of weld seams
- Prefabricated templates with all relevant measuring tools suchas throat thickness, weld reinforcement, penetration depth, etc.
- Automatic good/bad evaluation and report generation.
IoT - Internet of things The platform for remote access to your devices
All QATM hardness testers with QpixControl2 and QpixT2 software seamlessly integrate into the Verder Scientific IoT platform, providing enhanced functionality and seamless connectivity.
- Real-time Monitoring: Monitor your machinery in real time, from anywhere in the world. This data-driven approach empowers you to make informed decisions with ease.
- Live Notifications: Be ahead of the curve with immediate alerts and updates. Real-time notifications ensure you stay informed about your equipment's performance, leading to proactive maintenance.
- Effortless Backup: Simplify your data protection. Whether you need to back up a single device or an entire fleet, our platform streamlines the process, minimizing downtime and data loss.
- Automatic & Free Software Updates: Bid farewell to manual updates! Verder Scientific IoT ensures your customers' machines are consistently equipped with the latest software, optimizing performance and reliability.
Industry 4.0 Qconnect for connected tomorrows
Qconnect is the interface in QATM Qpix Control2 software, providing customers with a full portfolio of inter-device connectivity - from serial production, open XML interfaces (bi-directional) and pre-specified plug-in solutions, such as the QDAS Plug-In+, through to customer-specific connectivity solutions implemented completely by QATM. We have a professional solution for every applicational requirement.
Available functionalities & formats:
REPORT, PRINT, PDF, XML IE, CSV, TXT, WORD, EXCEL, AUTO EXPORTER, MAIL, Q-DAS, AMS IE, IOT, LIMS, OPCUA, PCI IE (ERP, BABTEC, ORACLE, SAP)
Approved quality Data exchange & monitoring
Report & Auto-Export
Test results, Lc results, scratch track information, and test parameters can be documented in a structured format and exported. Standardized test reports and flexible export options facilitate the transfer of results to quality assurance, documentation, or higher-level systems.
Barcode/QR code/DMC reader
Qpix software platforms support the use of barcode and QR code readers, simplifying workflows for inspectors and preventing operator error. Populating header data is simple (standard), and readers can be fully integrated to automatically select templates or retrieve data from higher-level systems (optional).
Login via NFC
The Qpix Control 2 software supports user login using an external NFC reader. Depending on the NFC tag/card, the customer‘s existing access cards can also be programmed in, for example.
Micro / Macro Scratch tester Qscratch 20 Technical Data
| Test force range | 0.5* - 200 N |
|---|---|
| Constant load | Single and multiple measurements |
| Progressive load | Single and multiple measurements |
| Z-axis | Dynamic, automated (CAS-Technic), Travelling distance Z 150 mm (5.91“) |
| Tool positions | 8-fold motorized tool changer (max. 3 testing modules, max. 7 lenses) |
| Included basic equipment | Rockwell diamond; 5x, 20x, 50x Lenses |
| Lens types | Standard (Achromat) and High Quality (Semi-apochromat) for hardness testing and microscopy |
| Sample image camera | 5 Mpixel - CMOS color, USB3.0 52 x 39 mm (2.05 x 1.54“) |
| Cross slide | Motorized X/Y axis |
| Table size | 150 x 120 mm (5.91 x 4.72“) |
| Positioning accuracy | X/Y-axis +/- 0.2 μm |
| Traverse path | X 150, Y 150 mm (5.91 x 5.91“) |
| Control elements | Emergency stop, Start button, Joystick X/Y/Z |
| Max. workpiece weight | 50 kg (110 lbs) |
| Weight of basic device | 60 kg (132.3 lbs) |
| Optional | Hardness Upgrade and Qpix Inspect Module |
* 0.5 N and 1 N > 1% accuracy
