The compact fully automatic grinding and polishing robot Qpol 250 BOT combines the complete grinding and polishing process, including ultrasonic cleaning in one machine. 16x disc changer, 6x dosing unit and an integrable sedimentation tank fits perfectly into the System lab.
Intuitive user interface via touch screen and a user friendly fixation system for central force sample holder enable preparation results in shortest time. All parameters can be adjusted during the automatic process.
The benefits of automation with the Qpol 250 BOT:
- Automated Processes: Grinding, polishing, and cleaning are fully automated.
- Flexible Media Selection: Choose customized media tailored to your specific needs.
- High Reproducibility: Ensure consistent results through reliable processes.
Productvoordelen
- Slijp- en polijstsysteem met centrale druk
- Aluminium behuizing, gepoedercoat
- Slijp- en polijstsysteem met centrale druk
- Polijstkop met variabele snelheid
- Variabele snelheid van werkwiel en polijstkop
- Verwijderingsmeting
- Automatische schuurwisselaar
- Reinigingsstation met water, lucht en ethanol
- Ultrasoon reiniger
- 6-voudige doseereenheid (4x diamant suspensie of smeermiddel, 2x fijne polijst suspensie)
- Opberglade voor schuurmiddelen
- Bezinkingstank 45L
Slijp- en polijstrobot Qpol 250 BOT Overtuigende voordelen
Cleaning station
The cleaning station enables a fully automatic multi-step cleaning of the sample with water, air and alcohol. Cleaning times and steps are completely adjustable as needed. The ultrasonic cleaning station provides intermediate or final cleaning.
Settling tank
The insertible settling tank is invisibly integrated into the cabinet with all its connections (option).
- 2-chamber PVC tank 45 liter
- mobile, with insertion mechanism for System Lab cabinets
Disc changer
The storage elevator contains up to 16 different grinding discs, such as SiC paper or Galaxy discs. During cleaning the sample, the foil changer replaces the grinding media and fixes it with the Vacu- Jet system automatically.
Dosing unit
Dosing and bottles depot are easily accessible and clearly arranged in the cabinet. Optional level monitoring and magnetic stirrer.
Slijp- en polijstrobot Qpol 250 BOT Superiority in detail
1. Robust housing
- Robust powder-coated aluminum housing
- Seamless integration into the system laboratory
2. Integrated cleaning station
- Cleaning with ultrasound, water, and ethanol
- Drying via compressed air
- No contamination
3. Media changer
- Up to 16 grinding and polishing media
4. 10" industrial touchscreen
- Intuitive QATM user interface
- Up to 200 user-defined preparation methods
5. Intelligent tool head
- Removal measurement thanks to force sensors
- Variable speed
6. Sophisticated safety concept
- Light barrier prevents access to the danger zone
Dit instrument is ideaal voor geologische en mineralogische toepassingen
Perfect grinding and polishing – Consumables by QATM
Grinding and polishing is more reliable, safe and efficient when processed with the right ingredients: knowledge, care and the right choice of consumables and instruments.
Perfect grinding and polishing – Consumables by QATM
Grinding and polishing is more reliable, safe and efficient when processed with the right ingredients: knowledge, care and the right choice of consumables and instruments.
Slijp- en polijstrobot Qpol 250 BOT Technische Gegevens
| Draaischijven | Ø 250 mm |
|---|---|
| Aandrijfkracht | 1,1 kW S3/40% |
| Monsterhouder-Ø | 160 mm |
| Aandrijfkracht polijstkop | 0,17 kW S1 |
| Snelheid (kop) | 30 - 150 tpm |
| Snelheid (slijper) | 50 - 600 tpm |
| Gecontroleerde verwijderingsmeting (weergave accuraatheid) | 0,1 mm |
| Water connectie | 1x vers water R½" max. 6 bar |
| Water uitlaat | 1x afvalwater DN50 |
| Perslucht aansluiting | 6 bar. koppeling verbinding NG8 |
| B x H x D | 1320 x 1500 x 800 mm |
