The Qpress 50 is a modular hot mounting press for fast and simultaneously independent mounting of different materialographic specimens. Due to its modularity the Qpress 50 can be configured ideally to the specific customer’s needs; e.g. the specimens can differ in size and material.
The 7“ industrial touchscreen with intuitive software contains user account management, preinstalled recipes and user-defined maintenance tasks and more. The device combines fast mounting and high energy efficiency in a robust powder-coated steel case.
Преимущества оборудования
- 7” industrial touchscreen user interface with intuitive QATM user software
- Sliding closure with comfortable one-hand operation
- Dust Guard removes fine dust to improve safety
- Fast mounting
- High modularity for both simultaneous and independently controlled mounting
- User account management with different access rights
- Pre-installed preparation methods and consumables
- Powder coated steel housing
Прессы горячего прессования Qpress 50 Особенности
Improved sliding closure
One-hand sliding closure with integrated suction nozzle. When the mould is closed, excess granulate is pushed into a removable compartment (dirt trap). The sliding closure can be lifted off to clean the upper flask.
User safety
An integrated exhaust device (Dust Guard) protects the operator from inhaling expired fine dust during filling the moulds with mounting resin.
Easy to operate
The multi-functional button indicates the selected mounting unit, the operation state of the pressing unit and facilitates the operation of the whole unit. The 7“ industrial touchscreen with control software consists of pre-installed mounting methods, consumables and offers the storage of more than 200 user-defined mounting methods.
Fast mounting cycle
The Qpress 50 is designed for fast mounting including a pre-heat function and safes significantly time compared to other hot mounting presses.
Highlights
- High modularity to meet specific customer needs
- Dust Guard removes fine dust to improve safety
- Innovative design of heating/cooling unit guarantees precise and energy-efficient mounting process
- Basic unit supports all additional pressing units
- Pre-heat function reduces cycle time
- Adjustable cooling power and a choice of cooling modes reduce water consumption
For up to 4 mounts simultaneously Excellent modularity to meet your needs
Qpress 50-2 - for medium quantity of mounts
The Qpress 50-2 is the perfect choice for small and medium quantities of mounts. The basic unit includes one pressing unit and can be extended with one additional mounting unit at any time. The units are operated independently and simultaneously.
Qpress 50-4 - for large quantity of mounts
Up to 4 mounts can be done simultaneously and independently from each other. The basic unit includes one pressing unit and is extendable by 1, 2 or 3 additional mounting units. The diameter of the mount of each pressing unit is chosen individually by 25.2 mm, 30 mm, 1 ¼“ (~32 mm), 1 1/2“ (~38 mm), 40 mm and 50 mm - each diameter with or without chamfer.
Прессы горячего прессования Qpress 50 Mounting in 4 easy steps
1. Fill the mould with the respective mounting material
2. Close the sliding closure by one-hand operation
3. Clean dirt trap as excess mounting material is automatically pushed towards it
4. Start the mounting method with multifunctional button
Clear, robust design made in Germany Superiority in detail
1. Sliding closure
- One-hand operation
- Innovative design
- Safety closure under pressure
- Easy to operate
- Removable for cleaning upper ram
- Includes dirt trap
2. Mounting
- Fast mounting
- 4 different pressure modes
- Highly precise temperature control
- Adjustable heating/ cooling power
3. Modularity
- Up to three different mount sizes
- Simultaneous mounting
- Independently controlled
- Status indication by the multifunctional button
4. Control interface
- 7” color industrial touchscreen
- Intuitive control software
- Pre-installed preparation methods for QATM consumables
- Smart control modularity
- Assistance function for easy use of the additional pressing units
5. Pre-heat function
- Pre-heating of mould
- Reduces cycle time
- Pre-heat temperature can be set manually
6. Dust Guard
- Vacuums fine dust of mounting material
- Integrated in design of sliding closure
Прессы горячего прессования Qpress 50 Аксессуары
Recirculation cooling unit
- Powerful cooling with adjustable water temperature
- Resource-saving circulation system instead of fresh water
- Low maintenance, as the coolant circulates in a closed circuit, thus reducing limescale deposits
Also available as system cooling with the following advantages:
- Convenient mobile slide-in mechanism
- Can be fully integrated into the QATM system laboratory (system drawer 21 HT)
Mould assembly
Available with or without chamfer in these sizes:
Ø 25.2 mm, Ø 30 mm, Ø 1¼“ (~32 mm), Ø 1½“ (~38 mm), Ø 40 mm, Ø 50 mm
Perfect mounting – Consumables by QPREP
запрессовка надежнее, безопаснее и эффективнее, если она выполняется с использованием правильного оборудования: знания, осторожность и правильный выбор расходных материалов и оборудования имеют решающее значение.
Прессы горячего прессования Qpress 50 Характеристики
| Максимальное количество модулей прессования | 2/4|Qpress 50-2: до 2|Qpress 50-4: до 4 |
|---|---|
| Размер пресс-формы | Ø 25,2 - 50 мм (6 различных размеров) |
| Система закрытия | скользящая крышка |
| Регулируемая температура | 50-200°C |
| Время нагрева | регулируется |
| Время охлаждения | регулируется |
| Макс. давление в цилиндре формы, в зависимости от размера формы | 250-350 бар |
| Мощность подключения (базовый модуль) | 1,6 кВА |
| Мощность подключения (дополнительные модули) | 1,5 кВА |
| ШхВхГ (базовый модуль) | 402 x 382 x 563 мм |
| ШхВхГ (дополнительный модуль) | 187 x 382 x 449 мм |
| Вес | ~ 50 кг |
