Simple and efficient rockwell hardness testing
The Qness 150 CSA+ incorporates the best of all proven concepts and practices: the versatility of an automatic hardness tester and the speed of our Rockwell testers.
A fully automatic XY slide will guarantee high precision hardness testing. It is ideal for fully automatic series and progression tests on parts with identical test heights. However, individual tests can be performed, too.
Productvoordelen
- Large test force range (1kg – 250kg)
- Automatic 3-axis control
- Short cycle times
- Identical sample tests
- Robust, welded steel frame
- Infinitely adjustable test table height
Product Video
De perfecte introductie tot het Rockwell hardheidsmeten
Ingebouwde LED-werkruimteverlichting vereenvoudigt de precieze positionering van het teststuk en verhoogt zo het bedieningscomfort.
Rockwell Hardheidstester QNESS 150 CSA+
Test Methodes & Krachten Bereik
| HBT (not acc. to standards) |
| HVT (not acc. to standards) |
| Plastics |
|---|
DIN EN ISO 2039
| 49.03 N | 132.9 N | 357.9 N | 961 N |
Geïntegreerde conversies: DIN EN ISO 18265, DIN EN ISO 50150, ASTM E140
Volledig geautomatiseerde testcyclus
Elektronische krachttoepassing en closed-loop controle
IoT - Internet of things The platform for remote access to your devices
All QATM hardness testers with QpixControl2 and QpixT2 software seamlessly integrate into the Verder Scientific IoT platform, providing enhanced functionality and seamless connectivity.
- Real-time Monitoring: Monitor your machinery in real time, from anywhere in the world. This data-driven approach empowers you to make informed decisions with ease.
- Live Notifications: Be ahead of the curve with immediate alerts and updates. Real-time notifications ensure you stay informed about your equipment's performance, leading to proactive maintenance.
- Effortless Backup: Simplify your data protection. Whether you need to back up a single device or an entire fleet, our platform streamlines the process, minimizing downtime and data loss.
- Automatic & Free Software Updates: Bid farewell to manual updates! Verder Scientific IoT ensures your customers' machines are consistently equipped with the latest software, optimizing performance and reliability.
Rockwell Hardheidstester QNESS 150 CSA+ Geavanceerde machineconstructie, uiterst eenvoudige bediening
Compact ontwerp - Nieuwste technologie
- Gecontroleerde krachtuitoefening (1kg tot 250kg)
- Machineversies voor alle toepassingen en teststukgrootte
- Direct dieptemetersysteem (0,05μm resolutie)
- Robuust gelast stalen frame en plaatstalen kappen
Verwijderbare neerhouder
- Geen noodzaak voor lange herbewerkingspauzes door ontoegankelijke testpunten. De klemkop kan via 2 schroeven worden verwijderd. Nu zijn zelfs testpunten in moeilijk bereikbare contouren gemakkelijk bereikbaar.
Gemaakt in Oostenrijk
- Ongeëvenaard in zijn klasse! Wij weten hoe belangrijk een apparaat van superieure kwaliteit kan zijn en garanderen uitstekende kwaliteit van onze nieuwe serie Rockwell hardheidsmeters. Ontwikkeld en geproduceerd in Oostenrijk!
Rockwell Hardheidstester QNESS 150 CSA+ Intuïtieve functies en bediening
Hoogteverstelling van de testtafel
The height of the test table is infinitely adjustable (position can be fixed) via the play-free roller-bearing spindle guide - ideal for fully automatic series and progression tests on parts with identical test height. The test sequence is performed without clamping. Individual tests can also be carried out with the patented, swivelling downholder clamp.
Automatische progressies
The automatic XY slide with high-precision positioning drive enables extensive test series and hardness curves. External joystick for controlling the axis. Usable support surface: 180 x 200 mm, Traverse path: X 220 / Y 220 mm.
Volledig geautomatiseerde 3-assige besturing
Fully automatic and robust XY slide with high-precision positioning drive. Dynamic joystick to control all 3 axes (XYZ). Usable support surface 200 x 180 mm.
Identieke monstertests
An entire range of relevant data, such as test patterns, test methods and user fields can be activated via pre-defined sample magazines. QATM can provide the most suitable clamping setup, matrices and cassette systems for every requirement.
Monsterbeeldcamera
Ultimate ease of use with 5 megapixel colour camera for recording the entire sample for a perfect overview and documentation in the protocol. It is standard in the CSA+ versions to record the entire table surface as sample image.
Maximale klembescherming
High-performance induction motor facilitates an ideal workpiece clamping force. Clamping power is adapted to the test method and is automatically set to be greater than the test force. Operators do not need to set levels and can rely on the device to guarantee safe, optimized adaption.
Special clamping devices
QATM is the right stop for advice on complex requirements and clamping devices! It would be our pleasure to advise, devise, customize and implement a solution for you. Only the right component clamping solution can guarantee reliable results.
Maximale QATM precisie
QATM configureert de Rockwell hardheidsmeter Qness 150 CS ECO met een direct, ultra-precies HEIDENHAIN diepte-meetsysteem, exact gepositioneerd op de as van het indringlichaam. Hierdoor zijn meetonnauwkeurigheden door vervorming in het systeem uitgesloten. Een ander onovertroffen voordeel: de indringdiepte kan direct - en absoluut - worden gemeten en kan eenvoudig worden gekalibreerd volgens de nieuwste Rockwell-normen ASTM E 18:2020 en DIN EN ISO 6508.
Bediening via extern PC-systeem Revolutionair 3D bedieningsconcept
Intuitive, clearly organized and professional: Qpix Control2 next-generation hardness testing software, developed based on customer feedback and input for maximum user-friendliness. 3D imaging and a whole range of easily understood control elements and views included in the software. It sets new standards in hardness testing.
Klant-specifieke monsterhouder
Identieke monsters kunnen in de software op schaal ingesteld worden als 3D model.
Save time with optimum stop
Time-saving test mode ‘Complete all indentations – then evaluate’ and ‘Optimum Stop’ to complete test series as soon as the lower hardness limit has been undercut.
Industrie 4.0 Qconnect voor een verbonden toekomst
Qconnect is de interface in QATM Qpix Control2 software, waarmee gebruikers werken men een volledig pakket voor onderling gekoppelde apparatuur, gaande van reeks-verwerking, open XML interfaces (bi-directioneel) en vooraf gespecifieerde plug-in oplossing, zoals de QDAS Plug-In+, langs klantspecifieke connectiviteitsoplossingen, volledig door QATM geïmplementeerd. We hebben een professionele oplossing voor elke toepassing.
Perfecte hardheidstesten - Verbruiksmaterialen van QATM
Hardness testing is more reliable, safe and efficient when processed with the right ingredients: knowledge, care and the right choice of consumables and instruments.
Rockwell Hardheidstester Configure Your Hardness Tester to Match Your Application
With the QATM Configurator, you can easily tailor your hardness tester to your individual requirements. Select the appropriate device version, equipment, and accessories, and submit your configuration directly as a non-binding request for quotation to QATM.
Your benefits at a glance:
- Configure individually: Select the device, equipment, and accessories to match your application
- Simple & clear: Step by step to your desired device configuration
- Request directly: Submit your configuration easily as a free and non-binding request for quotation
- Personal support: QATM experts assist you in selecting the right solution
Alternatively, you can also submit your inquiry directly via our contact form.
Rockwell Hardheidstester Qness 150 CSA+ Technische Gegevens
| Bereik testkracht | 1 - 250 kg (9,81 - 2450 N) |
|---|---|
| Gereedschap posities | 1 |
| Software | QPIX CONTROLE 2 |
| Hoogteregeling | gemotoriseerd |
| Testhoogte | 140 mm |
| Keeldiepte | 238 mm |
| Testtafel | 180 x 200 mm |
| Dwars pad | X 220 / Y 220 mm |
| Max. hoogte werkstuk | 100 kg |
| Gewicht van basisapparaat | 140 kg |
| beeldscherm | - |
| Testvolgorde | volautomatisch / elektronische krachttoepassing |
| Besturingssysteem / harde schijf | Windows 10 IoT / 128 GB SSD |
| Poorten | 1x RJ45 (Ethernet) |
