Productvoordelen
- Standardized Brinell- and Rockwell methods acc. to EN ISO and ASTM
- Fully automatic hardness testing cycle
- Fully automatic image analysis with brightness control
- Can be used as an inline solution in heavy machine construction
- Fully automatic test point preparation
- Exact milling depth settings
Test Methods Variants Test methods & load application
Brinell Testing Plant Kenmerken
A strong partnership
- Advantages for the customer: All-in-one supplier - "all from one source"
- long standing experience in automation
- long standing experience in hardness testing
- fitted complete solutions - short cycle times
- solution finding with customer
- increased efficiency
- professional service
- made in Austria
Application Area
Industry: smithies, roller plants, tube rolling mills, foundries, hardening shops, stainless steel, automotive, railway, energy, steel, aviation Workpieces: rings, bars, tires, wheels, castings, open die forgings, plates, sheets, steel bottles, motor blocks, rails
Professional Data Management
- Numerous statistic functions: bar graph, progression, histogram
- Exporting of measurement value list as "Excel" (CSV)
- A4 test protocol as PDF / direct print-out
- Data storage on USB stick
- Data link to ERP system and databases
- Order registration
- Target value transfer
- Actual value transfer
Big Test Room Concept
- latest technology, innovative design
- test room for transport and magazine catch developable
- for loading the work pieces from above the test unit moves out of the feeding zone
- work piece loading possible from 5 sides
- test room max. height 1600 mm vertical path 800 mm throat depth 650 mm
Control Software Qpix T12
- Siemens S7-control
- Joystick for manual axis movement
- execution acc. to European CE-directive
- all axis servo controlled
- ringlight in bright- and dark field process
- quick auto focus
- possibility for manual 2nd test
- 12" touch screen display
- Windows 7 integrated
Options
- Marking via pin marker
- Milling chip extraction
- Qdas link
- ERP link
- Upgradeable as inline-solution with conveyor
- Ultrasonic testing, VP testing (spectral analysis)
- Integrated workpiece measuring systems
- Handling manipulators
- Adjustable inspection height
- Multiple inspection points with average values
- Test point can be defined via light point
Qradial Technische Gegevens
| Test belasting bereik | 60 - 3000 kg (589 - 29430 N) |
|---|---|
| Test methodes volgens standaarden | HBW5/750, HBW10/3000, HRC |
| Max. test breedte | 1100 mm |
| Test hoogte / pad | 1600 mm / 800 mm |
| Keeldiepte | 650 mm |
| Data interface | 3x USB, 1x RS232, 1x RJ45 (Ethernet) |
| Gewicht van basismachine | 4800 kg |
| Machine afmetingen | (LxBxH) 2500 x 1900 x 2800 mm |
